1986-1987 Hyundai Excel Tail Light: A Buyer's Guide to Sedan & Hatchback Fitment
This guide clarifies the critical differences between sedan and hatchback tail lights for the first-generation Hyundai Excel and what to inspect before you buy.
- The single most important factor is body style: tail lights for the 4-door sedan and the hatchback models are NOT interchangeable.
- A used OEM tail light is your most realistic option, with prices typically between $20 and $50.
- When buying used, check for cracks, internal moisture, and intact mounting points to avoid a bad part.
- Replacement is a very easy DIY job that takes less than 30 minutes with basic tools.
Key Differences: Sedan vs. Hatchback
The most important factor when buying a replacement tail light for a 1986-1987 Hyundai Excel is your vehicle's body style. The tail lights for the 4-door sedan are not interchangeable with those for the 3-door or 5-door hatchback models. They have different shapes and mounting points to match the distinct body lines of each version.
Warning: Always verify you are purchasing the correct tail light for your specific body style. A sedan light will not fit a hatchback, and vice-versa. Check photos and part numbers carefully before ordering.
Symptoms of a Failing Tail Light
Tail light problems are usually easy to spot. A non-working tail light is a safety hazard that can earn you a traffic ticket, so it's important to address any issues immediately. Here are the most common signs of failure:
- Light Not Working: The most obvious symptom is a bulb that doesn't light up at all, either as a running light, brake light, or turn signal. This is often just a burnt-out bulb.
- Dim or Flickering Light: A light that appears dimmer than the one on the other side or flickers intermittently often points to a bad electrical connection, corrosion in the socket, or a failing bulb.
- Condensation Inside the Lens: Seeing moisture, fog, or water droplets inside the tail light means the seal has failed. This moisture will quickly corrode the bulb sockets and reflective surfaces, leading to electrical problems and complete failure of the assembly. 🎬 Watch: How to solve moisture and condensation in your lights
- Cracked or Hazy Lens: Physical damage like cracks or chips can allow moisture in. A cloudy or hazy lens reduces the light's brightness, making your vehicle harder to see.
- Blown Fuses: If a new bulb doesn't fix the problem, check the vehicle's fuse box. If the fuse for the tail light circuit blows repeatedly, it indicates a short circuit in the wiring that needs to be diagnosed. 🎬 Watch: How to diagnose faulty tail lights yourself
Buying a Used 1986-1987 Excel Tail Light
Given the age of the Hyundai Excel, a used Original Equipment (OEM) tail light is the most likely, and often only, option available. New OEM parts are generally no longer produced, and aftermarket support is scarce. A good used OEM part offers the best fit and quality. Here’s what to inspect before buying:
Physical Inspection Checklist
- Check for Cracks and Chips: Carefully examine the entire lens for any cracks, even small hairline fractures. Pay special attention to the corners and edges. A cracked lens will leak water.
- Look for Internal Moisture or Haze: Hold the light up and look for any signs of water staining, fogging, or a white, hazy film on the inside of the lens. This indicates the seal has already failed and there may be hidden corrosion.
- Inspect All Mounting Points: Turn the assembly over and check that all plastic mounting studs and tabs are intact and not cracked or broken. A tail light with broken mounting points will not install securely.
- Examine the Bulb Sockets: Look inside the bulb sockets for any signs of rust, corrosion, or melted plastic. Green or white crusty buildup is a major red flag for electrical issues.
- Verify the Wiring Harness and Connector: If the tail light comes with a wiring pigtail, ensure the connector is not damaged and the wires are not cut or frayed.
Pro Tip: Ask the seller for clear, well-lit photos of the front, back, and all sides of the assembly. If buying locally from a salvage yard, take a moment to compare it directly to the old part from your car to confirm the shape and mounting locations.
Known Issues, Recalls, and TSBs
While there are no recalls specifically for the tail lights on the 1986 Hyundai Excel, the vehicle was subject to two significant safety recalls that owners should be aware of.
- Brake System Recall (March 1986): Shortly after its U.S. launch, Hyundai recalled early 1986 Excel models for a potential brake failure. The issue involved a missing or damaged cotter pin in the linkage between the brake pedal and the master cylinder, which could lead to a total loss of braking.
- Engine Fire Risk Recall (December 1991): A later recall affected all 1986-1989 Excel models. Deteriorated engine components could allow hot exhaust gases to melt the air filter, potentially causing an engine compartment fire.
These recalls are not related to the lighting system, but they highlight known safety issues with the vehicle platform.
Cost of a 1986-1987 Hyundai Excel Tail Light
Pricing for a replacement tail light assembly is generally low, reflecting the age of the vehicle. Your primary source will be used OEM parts.
| Part Type | Estimated Cost |
|---|---|
| New OEM | Not Generally Available |
| New Aftermarket | Very Rare / Not Generally Available |
| Used OEM | $20 - $50 |
| Shop Labor for Installation | $50 - $125 |
Replacement Information
Replacing the tail light on a first-generation Hyundai Excel is a straightforward job that most DIYers can complete with basic hand tools.
- Difficulty: 1 out of 5 (Very Easy)
- Estimated Time: 15-30 minutes
- Tools Needed: Socket set or nut driver.
The tail light assembly is typically held in place by a few nuts accessible from inside the trunk. After opening the trunk, pull back the carpet or interior liner behind the light to expose the mounting studs and nuts. Disconnect the single electrical connector, remove the nuts, and the entire assembly can be pulled out from the rear of the car. Installation is the reverse of removal.
🎬 Watch: See this step-by-step tail light replacement walkthroughFrequently Asked Questions (FAQ)
Do I need to buy a tail light for the sedan or hatchback?
Yes, this is critical. The 4-door sedan and the 3/5-door hatchback models use different tail lights that are not interchangeable. You must buy the part that matches your car's body style.
Is it okay to drive with a cracked tail light?
While the light may still work, a cracked lens is illegal in most places and is a safety risk. The crack will allow moisture to enter, which will eventually cause the bulb and socket to fail. It should be replaced as soon as possible.
My tail light is out. Should I replace the bulb or the whole assembly?
Always start by replacing the bulb, as it's the most common point of failure and the cheapest fix. If a new bulb doesn't work, or if the lens is cracked or full of moisture, you should replace the entire tail light assembly.
What do the OEM part numbers mean?
Based on parts listings, Hyundai part numbers for this era often follow a pattern. Numbers starting with 92401- typically denote the driver's side (Left), while those starting with 92402- denote the passenger's side (Right). For example, 92402-21010 is a passenger-side light. The numbers that follow indicate the specific application, like sedan or hatchback.
Helpful Videos
Technical Specifications
OEM Part Numbers: 92402-21010 (Passenger Side / Right) 92401-21030 (Driver Side / Left, Sedan)
Bulb Type: Incandescent (standard)
