2016-2022 BMW 7-Series Bowers & Wilkins Speaker Cover: Fixing Rattles and Damage
This guide covers diagnosis, inspection, and replacement for the premium rear parcel shelf speaker covers on G11 and G12 BMW 7-Series models.
- This speaker cover is ONLY for 2016-2022 BMW 7-Series with the premium Bowers & Wilkins sound system, not the standard or Harman Kardon systems.
- Rattles from the rear shelf are common but are often caused by the entire parcel shelf vibrating, not just the speaker cover. Try adding foam padding before attempting a replacement.
- Replacement is a complex job (Difficulty 4/5) requiring removal of the rear seats, C-pillars, and the entire parcel shelf assembly. This is not a simple pry-off part.
- When buying used, the most important things to check are the mounting tabs on the underside; if they are broken, the part will rattle.
Symptoms of a Failing Speaker Cover
While a speaker cover is a simple trim piece, its failure can create annoying problems. Because it's part of a high-performance sound system, symptoms are often audible.
- Rattling or Buzzing Noises: This is the most common symptom. The cover, or the parcel shelf it's mounted to, may vibrate at certain bass frequencies, creating a distracting buzz or rattle. This can be caused by loose mounting clips, broken tabs, or warping of the cover itself.
- Physical Damage: Cracks, dents, or warping can occur from items placed on the rear shelf or from sun exposure over time. The grille mesh can be pushed in, which may interfere with the speaker cone's movement.
- Cosmetic Flaws: The metal finish can become scratched, discolored, or faded due to UV exposure from the rear window. This detracts from the vehicle's premium interior aesthetic.
Known Issues: Rear Parcel Shelf Rattle
A persistent rattle from the rear of the car is a widely discussed issue on many BMW models, including the G11/G12 7-Series. While the speaker cover can be the source, the problem often originates from the larger plastic parcel shelf panel vibrating against the metal body structure or the rear glass. This is especially noticeable with bass-heavy music or even Active Sound Design (engine noise played through the speakers).
Pro Tip: Before replacing the speaker cover for a rattle, try to diagnose the source. With the audio system playing a bass-heavy track, gently press on the speaker cover and then on different areas of the surrounding parcel shelf. If pressing on the shelf stops the noise, the issue is the shelf itself. Many owners have successfully fixed this by strategically placing foam tape or pieces of a pool noodle between the plastic shelf and the metal body through the trunk access holes, which dampens the vibration.
Buying a Used Speaker Cover: What to Check
A used OEM speaker cover is an excellent value, as a new one can be costly. However, careful inspection is key to getting a good part.
1. Verify Bowers & Wilkins (B&W) Compatibility
Warning: This speaker cover (part number 65139365198) ONLY fits vehicles with the optional Bowers & Wilkins sound system. It will not fit the standard or Harman Kardon systems, which use different, typically black plastic, speaker grilles.
Before buying, confirm your vehicle has the B&W system. The easiest way to tell is by looking at the speaker covers. B&W covers are made of metal with a distinctive, intricate hole pattern. Many also feature integrated ambient lighting that makes the speakers glow. The standard Harman Kardon grilles are plain black plastic.
2. Physical Inspection
- Mounting Tabs: Flip the cover over and inspect all mounting tabs and clips. These are the most critical part. Ensure none are cracked, broken off, or brittle. A cover with broken tabs will not sit securely and will almost certainly rattle.
- Grille Condition: Check the metal grille for any dents, dings, or scratches. Make sure the mesh is not pushed in or separated from the frame.
- No Warping: Lay the cover on a flat surface to ensure it is not warped. A warped cover will not sit flush on the parcel shelf, creating gaps and potential rattles.
Replacement Overview and Difficulty
Replacing the rear speaker cover on a G11/G12 7-Series is a complex job. Unlike older vehicles where grilles often pop off, this cover is integrated into the rear parcel shelf assembly. Accessing it requires removing a significant portion of the rear interior.
The general process involves:
- Removing the rear seat bottom cushion.
- Removing the rear seat side bolsters.
- Removing the C-pillar interior trim panels.
- Disconnecting any wiring for speakers, sunshades, or lighting.
- Releasing numerous clips and fasteners holding the parcel shelf in place.
- Lifting the entire parcel shelf assembly out of the vehicle. 🎬 Watch this step-by-step 7-Series interior disassembly and speaker upgrade video
Once the shelf is out, the speaker cover can be unclipped and replaced from the underside. Due to the number of delicate trim pieces and hidden clips, this job carries a high risk of breaking plastic parts if done incorrectly.
- Installation Difficulty: 4 out of 5
- DIY Feasible: For experienced technicians or very confident DIYers only. Plastic trim tools are mandatory.
Cost Comparison
| Part Type | Estimated Cost |
|---|---|
| New OEM | $175 - $215 |
| New Aftermarket (with LEDs) | $200 - $450 |
| Used OEM | $25 - $50 |
| Shop Labor | $300 - $600 |
Frequently Asked Questions (FAQ)
Is this speaker cover the same for the left and right side?
Yes, the same part number (65139365198) is used for both the driver's side and passenger's side rear shelf speakers.
Will this fit my 7-Series with the Harman Kardon sound system?
No. This is a common compatibility mistake. This specific cover is only for the upgraded Bowers & Wilkins system. The Harman Kardon system uses a different, less ornate plastic cover.
Can I just pry the old cover off from the top?
It is strongly advised not to. On the G11/G12 chassis, the cover is secured by clips from underneath the parcel shelf. Attempting to pry it from the top will likely break the cover and its mounting points. Proper replacement requires removing the entire rear parcel shelf.
My speaker cover is fine, but I have a rattle. What should I do?
The rattle is likely coming from the parcel shelf panel vibrating against the car's body. Before attempting a difficult replacement, try adding foam damping material between the shelf and the metal structure underneath. This can often be done through the trunk without removing the interior.
Helpful Videos
Technical Specifications
OEM Part Numbers: 65139365198 9365198
Material: Metal. Location: Rear Package Tray / Parcel Shelf. Compatibility: Bowers & Wilkins sound system only.
