2009-2014 Nissan Cube Rear Finish Panel: Cracks, Fading, and Replacement Guide
Learn how to spot common damage on the Cube's unique rear center panel and what to check before buying a used replacement.
- Failure of this panel is purely cosmetic, typically cracks or fading; it does not affect vehicle operation.
- Replacement is an extremely simple DIY job, requiring only a screwdriver and about 15-20 minutes.
- When buying a used panel, the most critical inspection is to check that the rear mounting tabs and the two square fasteners are intact.
- New OEM panels are costly, making a quality used OEM part a significant value, as aftermarket versions are not readily available.
Symptoms of a Failing Rear Finish Panel
Since this is a cosmetic panel, all symptoms of failure are visual. There are no mechanical functions, and a damaged panel will not trigger any warning lights or diagnostic trouble codes. Look for these common signs of wear or damage:
- Cracks or Chips: The most common issue is physical damage. This can range from small stress cracks around the mounting points to large cracks or chips from a minor impact.
- Fading or Discoloration: Over time, exposure to UV rays from the sun can cause the red plastic to fade, becoming dull or pinkish. This can detract from the vehicle's appearance.
- Loose Fit or Rattling: The panel is held on by clips and two quarter-turn fasteners. If these mounting points are broken, the panel can become loose and may rattle or vibrate while driving.
- Damaged or Missing Emblem: The 'CUBE' lettering is an integrated part of the panel. The chrome or silver finish on the letters can peel, or in rare cases, the emblem itself could be damaged.
Pro Tip: A cracked finish panel can sometimes allow water to seep behind it, which could potentially lead to moisture issues around the tail light seals over a long period. It's best to replace a significantly damaged panel.
Buying a Used 2009-2014 Cube Finish Panel: What to Inspect
Given the high cost of a new OEM panel, a used one is an excellent value. However, careful inspection is key to getting a good part. Aftermarket options are not commonly available, making a quality used OEM part the best choice for fit and color match.
Before purchasing, check the following:
- Inspect for Cracks: Carefully examine the entire surface for cracks, no matter how small. Pay special attention to the edges and corners. Minor surface scratches are common on used parts, but deep cracks compromise the part.
- Check All Mounting Points: This is the most critical inspection step. Flip the panel over. There are two square-shaped, quarter-turn fasteners that secure the panel to the tailgate. Ensure these are present and not broken. Also, check that all other plastic clips and tabs around the perimeter are intact. Broken tabs will result in a loose fit.
- Look for UV Damage: Check for even color across the panel. Compare it to photos of other Cubes to ensure it hasn't severely faded from sun exposure.
- Examine the 'CUBE' Emblem: Ensure the emblem is present and the finish is in good condition, without peeling or significant damage.
Known Issues, Recalls, and TSBs
There are no recalls or Technical Service Bulletins (TSBs) issued by Nissan or the NHTSA for the rear body panel finish panel on the 2009-2014 Nissan Cube. Any damage to this part is considered cosmetic and a result of normal wear, sun exposure, or physical impact. While there are recalls for the Cube for issues like fuel system integrity after a rear impact, these do not pertain to the cosmetic finisher itself.
Cost of Replacing the Rear Finish Panel
The cost for this part can vary significantly between new and used options. Labor costs are minimal due to the simplicity of the job.
| Part Source | Estimated Cost |
|---|---|
| New OEM | $160 - $265 |
| New Aftermarket | Not Commonly Available |
| Used OEM | $35 - $110 |
| Shop Labor | $50 - $100 |
Installation Guide (Difficulty: 1/5)
Replacing the rear finish panel is a very easy DIY job that requires minimal tools and can be completed in about 15-20 minutes.
Tools Needed:
- Flathead screwdriver
- Trim removal tool (optional, but recommended)
Step-by-Step Replacement: 🎬 Watch: Step-by-step tailgate trim removal video
- Open the Rear Door: Open the main rear tailgate to access the panel.
- Remove Top Trim Cover: 🎬 See how to remove the bottom trim and valance Locate the small black trim piece directly above the red finish panel. There are two plastic pop-rivets holding it in place. Use a flathead screwdriver or trim tool to gently pry the center pin of each rivet up, then pull the entire rivet out.
- Release the Finish Panel: With the top trim removed, you will see two black, square-shaped plastic fasteners. Use a large flathead screwdriver to turn each fastener 90 degrees (a quarter turn). They are not screws, so do not try to turn them continuously.
- Remove the Old Panel: Once the fasteners are released, gently pull the panel away from the tailgate. It is also held in by clips, so you may need to apply steady pressure to pop it free.
- Install the New Panel: Align the clips on the back of the new panel with the holes in the tailgate and press it firmly into place. Turn the two square fasteners 90 degrees to lock it.
- Reinstall Top Trim: Place the top trim cover back on and push the two pop-rivets back into their holes to secure it.
Frequently Asked Questions (FAQ)
Is the rear finish panel difficult to replace myself?
No, this is one of the easiest parts to replace. It requires only a screwdriver and can be done in under 20 minutes. The difficulty is rated 1 out of 5.
Does the rear finish panel have any lights in it?
No, the panel itself is just a red plastic reflector and trim piece. It does not contain any bulbs or wiring.
Will a finish panel from any 2009-2014 Cube fit my car?
Yes, the rear finish panel is the same for all trim levels (Base, S, SL, Krom) of the Nissan Cube from model years 2009 through 2014.
Why did my panel crack?
Cracking is almost always caused by a physical impact, such as backing into an object, or from stress due to flexing, like slamming the tailgate shut repeatedly over many years. The plastic can also become more brittle with age and sun exposure.
Helpful Videos
Technical Specifications
OEM Part Numbers: 90810-1FA0A 908101FA1B 908951FA0A
Material: Plastic. Color: Red with chrome/silver 'CUBE' emblem.
