2015-2024 Toyota Camry Quarter Panel: BSM, Build Location & Replacement Guide
Learn the critical differences between US/Japan builds and models with or without Blind Spot Monitors before buying a replacement quarter panel for your Camry.
- The most critical factor is compatibility: 2015-2017 and 2018-2024 Camry quarter panels are not interchangeable.
- For 2018-2024 models, you must verify if your car has the Blind Spot Monitor (BSM) system, as the quarter panels are different.
- Check your VIN to determine if your Camry was built in the US (starts with '4') or Japan (starts with 'J') as part numbers can vary.
- Replacement is a complex, professional-level job requiring cutting, welding, and paint blending; it is not a DIY task.
Key Generations and Interchangeability
The 2015-2024 Toyota Camry spans two distinct generations, and their quarter panels are not interchangeable. It is crucial to identify your vehicle's generation before searching for a replacement part.
- XV50 Generation (2015-2017): This is a facelift of the previous generation. The body lines and dimensions are unique to these model years.
- XV70 Generation (2018-2024): This generation marked a complete redesign on Toyota's New Global Architecture (TNGA) platform. The quarter panels are entirely different from the previous generation.
Symptoms of a Damaged Quarter Panel
Since a quarter panel is a non-moving body part, "failure" is always the result of external factors like collisions or corrosion.
- Visible Damage: The most obvious symptom is visible damage, such as dents, dings, deep scratches, or creases from an impact.
- Rust and Paint Peeling: Look for bubbling paint or visible orange/brown rust, especially around the wheel arch, along the bottom edge, and near the fuel door. Toyota issued a technical service bulletin (TSB) for certain models with Blizzard Pearl (070) or Super White (040) paint that could experience peeling. 🎬 Watch: Overview of the Toyota paint peeling program
- Misaligned Trunk or Rear Door: A significant impact to the quarter panel can shift its position, causing the trunk lid or the rear door to be difficult to open or close, or to show uneven gaps.
- Wind Noise or Water Leaks: If the panel is bent or separated from the chassis, it can break the seal around the trunk or door, leading to excessive wind noise while driving or water leaking into the trunk or cabin.
Known Issues, Recalls, and TSBs
While there are no specific recalls for the quarter panel itself, there are related vehicle issues to be aware of:
- Paint Peeling TSB (ZKG): Toyota issued a Customer Support Program for 2015-2024 Camrys (and other models) with Blizzard Pearl (070) and Super White (040) paint colors that could exhibit peeling. If inspecting a used panel in one of these colors, check carefully for any signs of delamination.
- Recalls: NHTSA has issued several recalls for the 2015-2024 Camry, but none pertain directly to the quarter panel structure. Issues have included brake systems, fuel filler pipes, and electronic power steering.
Warning: The most significant issue for buyers is part compatibility. There are multiple versions of the quarter panel depending on the vehicle's generation, build location, and options. Ordering the wrong part will result in it not fitting.
Buying a Used 2015-2024 Camry Quarter Panel: A Buyer's Guide
A used OEM quarter panel is often the best choice for repairs, offering superior fit and material quality compared to aftermarket options. However, careful verification is essential.
Step 1: Identify Your Camry's Build Location
Toyota builds Camrys for the North American market in both the United States and Japan. While many parts are the same, some body panels can differ. Check the first character of your Vehicle Identification Number (VIN).
- VIN starts with '1', '4', or '5': Your Camry was built in the U.S.
- VIN starts with 'J': Your Camry was built in Japan.
When ordering a part, specify the build location. Part numbers often vary for US-built vs. Japan-built vehicles.
Step 2: Check for Blind Spot Monitor (BSM) System (2018-2024 Models)
For the 2018-2024 (XV70) generation, the most critical variant is whether the vehicle has a Blind Spot Monitor (BSM) system. The BSM radar sensors are mounted behind the quarter panels. Panels for BSM-equipped cars may have specific mounting provisions or be made of a material that does not interfere with the radar signals. Using the wrong panel can cause the BSM system to malfunction.
🎬 See: What the blind spot monitor sensor looks like- With BSM: Part numbers like 61602-06310 are for Japan-built models WITH Blind Spot Monitor.
- Without BSM: Part numbers like 61601-06320 are for Japan-built models WITHOUT Blind Spot Monitor.
Pro Tip: Always double-check your vehicle's options. BSM became more widely available on LE and SE trims as an option and was standard on XLE and XSE trims in later years. Confirm if your car has the feature before ordering.
Step 3: Physical Inspection Checklist
When inspecting a used quarter panel, look for:
- Previous Repairs: Look at the back of the panel for signs of body filler (Bondo), sanding marks, or non-factory welds. A magnet can help detect thick areas of filler.
- Hidden Rust: Check the inner flanges, wheel arch lip, and any seams for signs of corrosion. Surface rust can be treated, but deep or perforated rust is a deal-breaker.
- Bent Edges or Seams: Ensure all factory edges where the panel will be welded are straight and undamaged. A bent flange can make installation much more difficult.
- Overall Condition: Minor dents and scratches are acceptable as the panel will be prepped and painted anyway. Avoid panels with deep creases or significant structural damage.
Replacement Overview and Difficulty
Replacing a quarter panel is a major auto body repair that should only be performed by a professional technician. It is not a DIY-friendly job.
- Process: The job involves drilling out dozens of factory spot welds, cutting the panel at specific seams (often at the roof pillar and rocker panel), and removing the damaged panel. The new panel is then carefully fitted, welded into place (using a combination of spot welds and stitch welds), and the seams are sealed.
- Specialized Tools: Requires spot weld cutters, MIG welders, grinders, panel-flanging tools, and professional painting equipment. 🎬 Watch: Full step-by-step quarter panel replacement walkthrough
- Painting: After installation, the panel must be primed, painted, and clear-coated. The new paint must be blended into the adjacent door and trunk lid to ensure a perfect color match.
Cost Comparison
The largest expense in a quarter panel replacement is almost always the labor, not the part itself.
| Part/Service | Estimated Cost |
|---|---|
| New OEM Quarter Panel | $530 - $930 |
| New Aftermarket Quarter Panel | $150 - $400 |
| Used OEM Quarter Panel | $250 - $500 |
| Shop Labor & Paint (Estimate) | $1,500 - $3,000+ |
Part Number Reference
The following are examples of OEM part numbers. Always verify the exact part number with a dealer using your VIN.
| Part Number | Description | Generation |
|---|---|---|
| 61601-06100 | Right Quarter Panel | 2015-2017 |
| 61602-06100 | Left Quarter Panel | 2015-2017 |
| 61601-06320 | Right Quarter Panel (Japan Built, w/o BSM) | 2018-2024 |
| 61602-06310 | Left Quarter Panel (Japan Built, w/ BSM) | 2018-2024 |
| 61602-06320 | Left Quarter Panel | 2018-2024 |
Frequently Asked Questions (FAQ)
Can I replace just the rusted or damaged section of my quarter panel?
Yes. Body shops can use a "patch panel" or a "quarter panel skin" to repair a smaller area of damage, typically the lower section or wheel arch. This involves cutting out only the bad metal and welding in a new piece. This is less invasive and can be more cost-effective than replacing the entire panel.
Why is a used OEM panel better than a new aftermarket one?
Used OEM panels are made from the original factory tooling with the correct steel thickness and composition, ensuring a precise fit. Aftermarket panels can vary in quality, often use thinner metal, and may require significant extra work (bending, cutting, drilling) to fit properly, which can increase labor costs and compromise the final repair quality.
Will replacing the quarter panel affect my car's resale value?
A professionally repaired vehicle will always hold its value better than a damaged one. However, a record of the repair on a vehicle history report can lower the perceived value. The key is the quality of the repair. A high-quality repair with proper documentation is much better than a poor repair or unrepaired damage.
Does the entire car need to be repainted?
No, but to get a perfect match, the paint must be "blended" onto adjacent panels. The body shop will paint the new quarter panel and then spray a light coat of the new paint and clear coat onto the edge of the rear door and trunk lid. This gradual transition makes the color difference invisible to the naked eye.
Helpful Videos
Technical Specifications
OEM Part Numbers: 61601-06100 61602-06100 61601-06310 61601-06320 61601-33410 6160106320 6160133410 61602-06310 61602-06320 61602-33260 61602-33290
Material: Stamped Steel. Installation method: Weld-on. Variants exist for vehicle generation (2015-2017 vs 2018-2024), build location (US vs Japan), and options (with/without Blind Spot Monitor).
