A Ford F-150 Owner's Guide to the Engine Timing Chain Kit (2016-2022)
Understanding the common timing chain and cam phaser issues in your 2016-2022 Ford F-150.
- The most common symptom is a rattling noise on cold startup, especially on 3.5L EcoBoost engines, indicating failing cam phasers or a stretched chain.
- This is a complex, labor-intensive repair; professional installation is strongly recommended over attempting it as a DIY project.
- Always replace the complete kit, including chains, guides, tensioners, and cam phasers, to ensure a lasting repair.
- High-quality aftermarket brands like Cloyes and INA offer a reliable alternative to more expensive OEM parts.
Is Your F-150's Timing Chain a Ticking Time Bomb?
If you own a 2016-2022 Ford F-150, especially one with a 3.5L EcoBoost engine, you've likely heard about timing chain and cam phaser issues. The most common complaint is a distinct rattling noise from the engine during a cold start, which may only last a few seconds. This isn't just an annoying sound; it's an early warning sign that the timing components are wearing out.
What is a Cam Phaser?
Cam phasers are part of the variable valve timing (VVT) system. They adjust the timing of the camshafts on the fly to improve performance and fuel economy. In many F-150s, particularly the 3.5L EcoBoost, the phasers themselves are a primary point of failure, causing the infamous "startup rattle." When replacing the timing chain, it is almost always recommended to replace the cam phasers as well.
Known Issues, Recalls, and Technical Service Bulletins (TSBs)
For the 2016-2022 F-150, the most significant issue is the cam phaser rattle, primarily affecting the 3.5L EcoBoost engine. Ford has released several communications about this. Customer Satisfaction Program 21N03 extended the warranty coverage for cam phasers on certain 2017-2020 F-150s. This was often preceded by a software update under program 21B10, which attempted to solve the noise by changing engine parameters. However, many owners found that a full mechanical replacement was the only permanent solution. While these are not formal recalls for this specific part, they acknowledge a widespread problem. No major recalls for the timing chain itself were found on the NHTSA website for this year range.
Choosing the Right Aftermarket Timing Kit
When your truck needs a timing job, you have a choice between OEM (Motorcraft) and aftermarket parts. Given that even the original OEM parts are known to fail, a high-quality aftermarket kit can be a smart and cost-effective choice. Here’s a look at the brands available:
- Premium Aftermarket (OEM-Quality): Brands like INA and Cloyes are often considered to be on par with, or even suppliers to, original manufacturers. Cloyes is a well-respected name in timing components, and many professional mechanics trust their kits for this specific repair. INA is a major German manufacturer known for high-quality engine parts. These kits are your best bet for a reliable, long-lasting repair.
- Reputable Aftermarket: Gates is a well-known brand, famous for belts, but their timing kits are also a solid choice for a balance of quality and price. They are a trusted name in the aftermarket industry.
- Budget-Friendly: Brands like Skyward fall into the budget category. While the lower price is tempting, the quality of materials and manufacturing tolerances can be a gamble. For a repair this labor-intensive, saving a few hundred dollars on the parts could lead to another, much more expensive, failure down the road. Caution is advised with lower-cost, lesser-known brands.
Pro Tip: Always Replace the Full Kit
When tackling this job, always replace all timing components: the chains, tensioners, guides, sprockets, and especially the cam phasers. It's also a great time to replace the water pump, as it's driven by the timing chain on some engines and must be removed for access anyway. A high-volume oil pump, like those from Melling, is also a popular and recommended upgrade to ensure proper lubrication and pressure for the new components.
Cost of Replacing an F-150 Timing Chain Kit
This is not a cheap repair, primarily due to the high labor cost. The front of the engine must be disassembled to access the timing components.
| Part/Service | Estimated Cost |
|---|---|
| New OEM (Motorcraft) Kit | $600 - $1,500+ |
| New Aftermarket Kit | $197 - $1473 |
| Shop Labor | $1,500 - $2,500+ |
| Total Professional Job | $2,000 - $4,500+ |
Note: Prices are estimates and can vary significantly based on your location, the specific engine in your F-150, and the shop's labor rates. Some quotes, especially from dealerships, can exceed $6,000.
Frequently Asked Questions (FAQ)
How long should a timing chain last on a 2016-2022 F-150?
A timing chain is designed to last the life of the engine, often 150,000 miles or more. However, issues with tensioners and cam phasers on the 3.5L EcoBoost and even some 5.0L V8s can cause premature wear, requiring replacement much sooner. Regular oil changes with high-quality oil are critical to maximizing its lifespan.
Can I drive my F-150 with a rattling timing chain?
You can, but it's a big risk. The rattle is a sign of slack in the chain. If the slack becomes too great, the chain can jump a tooth on the sprockets, throwing off engine timing. This will cause poor running, loss of power, and eventually a no-start condition. In a worst-case scenario, the chain breaks or jumps enough for the pistons to hit the valves, causing catastrophic engine failure.
Is replacing the timing chain a DIY job?
For most people, no. This is a very complex and labor-intensive job, rated as high difficulty. It requires specialized tools to hold the camshafts in place, a deep understanding of engine mechanics, and 10-15+ hours of work. It is highly recommended to have this repair performed by a qualified professional mechanic.
Do I have to replace the cam phasers with the timing chain?
Yes, it is highly recommended. The cam phasers are a known failure point on these engines and are often the root cause of the noise. Given that the labor to get to them is the same, not replacing them while you're in there is a huge gamble that will likely lead to doing the entire job over again.
Helpful Videos
Technical Specifications
OEM Part Numbers: ML3Z-6C525-A HL3Z-6L266-A HL3Z-6M280-A HL3Z-6L266-C BR3Z-6020-A XW4Z-6700-AA ML3Z-6584-G HL3Z-6584-A
Kits typically include primary and secondary timing chains, camshaft and crankshaft sprockets, tensioners, and guides. For F-150s, it is critical that the kit also includes the four variable valve timing (VVT) solenoids, also known as cam phasers, which are a primary failure point.
