Mercedes-Benz ML450 (2010-2011) Engine Crankshaft Position Sensor Guide
Experiencing stalling or a no-start condition in your ML450 Hybrid? The crankshaft position sensor is a likely culprit.
- A failing crankshaft sensor is a top cause of stalling and no-start issues in the ML450.
- Symptoms like stalling are a critical safety issue and should be addressed immediately.
- For best results, choose high-quality aftermarket brands like Hella, Bremi, Delphi, or NGK.
- The replacement is DIY-possible but requires patience due to the sensor's tight location on the back of the engine.
Is Your ML450 Stalling or Refusing to Start?
If your 2010-2011 Mercedes-Benz ML450 suddenly stalls while driving or cranks but won't start, a failed engine crankshaft position sensor is a very common cause. This sensor provides vital data for engine operation, and when it fails, it can leave you stranded. Symptoms often appear when the engine is warm and may not be present during a cold start. Recognizing the signs early can prevent a breakdown.
Warning: Stalling is a Safety Hazard
A failing crankshaft position sensor can cause your engine to shut off without warning while driving. This results in a loss of power steering and brakes, increasing the risk of an accident. Do not ignore stalling issues.
Choosing the Right Aftermarket Sensor
When replacing a critical sensor on a Mercedes-Benz, part quality matters. While an OEM sensor from a dealer is always an option, high-quality aftermarket brands can offer similar performance for less money. Cheap, unproven brands should be avoided, as they have a high failure rate and can leave you with the same problem in a short amount of time.
Brand Quality Tiers for Your ML450
- Top Tier (OEM Equivalents): Brands like Hella and Bremi are often original equipment suppliers to German automakers. Choosing one of these is the closest you can get to dealer quality. Delphi and NGK (NTK) are also reputable manufacturers known for reliable sensors.
- Mid-Tier (Proven Aftermarket): Brands like Standard Ignition (SMP) and Walker Products offer a balance of quality and price. They are generally reliable for daily drivers.
- Economy Tier (Use with Caution): Lower-cost brands may be tempting, but for a critical sensor like this, it's often a gamble. Failure can mean being stranded again, making the initial savings insignificant.
Pro Tip: Many Mercedes owners and mechanics recommend sticking to OEM or German-made aftermarket brands like Hella or Bremi for critical electronic components to ensure longevity and proper function.
Cost of Replacing the Crankshaft Position Sensor
The total cost depends on whether you do the job yourself or take it to a shop. The part itself is not expensive, but labor can add up due to the sensor's tight location.
| Part/Service | Estimated Cost |
|---|---|
| New Aftermarket Part | $26 - $87 |
| Shop Labor | $73 - $107 |
| Total Estimated Cost (Shop) | $99 - $194 |
Frequently Asked Questions
Can I replace the ML450 crankshaft sensor myself?
Yes, this is a DIY-feasible job for someone with basic mechanical skills. However, the sensor is in a very tight location on the back of the engine, near the transmission bell housing on the driver's side. You will need a long extension for your ratchet, a universal joint, and an E8 external Torx socket. Patience is key, as it's difficult to see and reach.
Where is the crankshaft position sensor located?
On the 2010-2011 ML450, the sensor is located on the driver's side of the engine, at the rear where the engine meets the transmission. It is held in by a single E8 Torx bolt. Access is from underneath the vehicle or sometimes from the top with very long extensions.
What happens if I don't replace a failing sensor?
Ignoring a failing crankshaft position sensor will lead to more frequent and severe problems. The intermittent stalling will likely become a complete no-start condition, leaving you stranded. In the worst-case scenario, the engine will stall while driving at speed, creating a serious safety risk.
Are there any recalls for this part?
As of late 2025, there are no specific recalls from Mercedes-Benz or NHTSA for the crankshaft position sensor on the 2010-2011 ML450. However, there was a recall for some 2006-2012 ML models related to brake booster corrosion, which is unrelated but good to be aware of.
Technical Specifications
OEM Part Numbers: A0041539628 0041539628
The sensor is a Hall effect type, held in by a single E8 external Torx bolt, and is located on the driver's side rear of the engine block near the transmission bell housing.
