A Home Mechanic's Guide to the 2008-2022 Chevrolet Silverado 1500 Universal Joint
That clunking or vibration from your Silverado's driveline is a common issue you can fix by choosing the right replacement U-joint.
- A clunk when shifting or a vibration at highway speed are the most common signs of a failing U-joint on a Silverado.
- Choose a non-greasable U-joint from a premium brand like Dana/Spicer for a strong, maintenance-free repair.
- If you have a 2014-2019 model with the "Chevy Shake," worn U-joints should be inspected as a potential cause.
- While DIY replacement is possible, a U-joint press or large bench vise is required to avoid damaging the new part.
Is Your Silverado's U-Joint Failing?
A bad U-joint gives clear warning signs. The most common symptom is a distinct noise. You might hear a squeaking or chirping that speeds up as you drive, which can sometimes be mistaken for a bad belt. Another classic sign is a loud "clunk" or ringing sound when you shift from Park into Drive or Reverse. As the wear gets worse, you'll likely feel a vibration throughout the truck, especially at highway speeds. If you look under your truck, you might even see a stripe of grease slung onto the underbody above the driveshaft, which is a sure sign the U-joint's seals have failed.
Known Issue: The "Chevy Shake"
Many owners of 2014-2019 Silverado 1500s report a persistent vibration at highway speeds, often called the "Chevy Shake." While GM issued a Technical Service Bulletin (TSB PI1354I) related to driveshaft balance and other factors, a worn U-joint can cause nearly identical symptoms. If you feel a vibration, inspecting the U-joints is a crucial diagnostic step, even if you suspect the broader driveshaft issue.
Choosing the Right Aftermarket U-Joint
When your original U-joints wear out, you have a choice to make. Factory U-joints are often "non-greasable," meaning they are sealed and cannot be serviced. Aftermarket parts give you the option between non-greasable and greasable designs.
- Non-Greasable (Sealed) U-Joints: These are stronger because the internal cross is solid steel. They are maintenance-free and a great "install and forget" option, ideal for high-torque applications or for owners who prefer not to do regular maintenance.
- Greasable U-Joints: These have a small fitting (zerk) that allows you to pump in fresh grease. If you are diligent about greasing them with every oil change, they can potentially outlast sealed joints by flushing out moisture and dirt. However, the channel for the grease makes the joint slightly less strong than a solid one.
Pro Tip: For most Silverado owners, a high-quality non-greasable U-joint from a premium brand offers the best combination of strength and reliability without requiring ongoing maintenance. If you frequently drive in mud or deep water, a greasable joint that you service regularly may be a better choice.
Aftermarket Brand Tiers for Your Silverado
Not all aftermarket parts are created equal. Based on owner experiences and mechanic recommendations, brands generally fall into these tiers:
- Premium (OEM or Better): Brands like Dana/Spicer and SKF are top-tier choices. Spicer is often the original equipment manufacturer for many trucks and is highly regarded for its strength and durability, especially its non-greasable line.
- OE-Style / Heavy Duty: Moog and ACDelco fall here. Moog is known for its "problem solver" parts, though some users report inconsistent quality in recent years. ACDelco is GM's official parts brand and offers reliable, factory-spec replacements. Yukon Gear also offers heavy-duty options tailored for performance and off-road use.
- Standard Aftermarket: GMB is a common manufacturer that produces parts that meet or exceed OEM specifications and are a solid, budget-friendly choice.
Cost of Replacing a Silverado 1500 U-Joint
| Part Type | Estimated Cost |
|---|---|
| New Aftermarket U-Joint (Single) | $19.69 - $237.75 |
| Shop Labor | $157 - $230 |
| Total Professional Replacement (1 Joint) | $213 - $521+ |
Frequently Asked Questions
Can I replace just one bad U-joint?
Yes, you can replace only the failing U-joint. However, if your truck has high mileage, the other joints have experienced the same amount of wear. It is often cost-effective and good preventative maintenance to replace all the U-joints on the driveshaft at the same time.
Do I need to balance my driveshaft after replacing U-joints?
If the replacement is done carefully and you mark the driveshaft's orientation before removal, balancing is not usually required. However, if you still have a vibration after the repair, the driveshaft may be out of balance and should be checked by a specialty shop.
What tools are needed for a DIY replacement?
You will need standard wrenches to remove the driveshaft. To press the old U-joint out and the new one in, you need a heavy-duty bench vise, a large C-clamp, or a dedicated ball joint/U-joint press tool. Using a hammer can damage the new joint's delicate needle bearings.
Was there a recall for Silverado U-joints?
There was a specific recall (NHTSA 20V-650) for a small number of 2019-2020 Silverado 1500s for an improperly welded driveshaft joint, not the U-joint itself. This could cause the driveshaft to separate. Most U-joint failures are due to normal wear and tear and are not part of a recall.
Helpful Videos
Technical Specifications
Chevrolet Silverado 1500 trucks typically use U-joints from the 1350 or 1410 series, or a GM-specific 3R/S44 series. It is critical to measure your original U-joint's cap diameter and width or use your vehicle's specific sub-model information to ensure you purchase the correct size, as multiple driveshaft configurations were used across this long model run.
