2022-2025 Lucid Air Power Seat Problems: Software Glitches and Module Failure
This guide covers the common software-related seat adjustment failures, symptoms of a bad control module, and what to know before buying a replacement.
- Many power seat issues on the Lucid Air are software glitches that may be fixed with a vehicle reboot or software update.
- A replacement module, whether new or used, will almost certainly require programming by a Lucid Service Center to function.
- There are no active recalls for the front power seat control module, but there was a recall for rear seat heaters overheating due to a software bug.
- Before buying a replacement, always confirm your original module's part number (e.g., P11-M50108) to ensure compatibility.
Common Symptoms of Power Seat System Failure
Many reported issues with the 2022-2025 Lucid Air's power seats appear to be software-related rather than a complete hardware failure of the control module. Owners frequently report intermittent problems that can sometimes be temporarily fixed by rebooting the vehicle's main display. If you experience these issues, it's important to first try a system reboot before assuming a part needs to be replaced.
Software-Related Glitches
- Delayed or Unresponsive Controls: The seat adjustment controls may be completely unresponsive when you first get in the car, only starting to work after driving for a minute or two.
- Inconsistent Memory Functions: The seat may fail to automatically adjust to the saved position 🎬 See how to adjust and set your seat memory profiles for your driver profile. When using the on-screen "Restore" button, it might get stuck halfway, requiring multiple presses to move to the correct position.
- Erratic Easy Entry/Exit: The feature that automatically moves the seat back for easier entry and exit may work only intermittently or stop working altogether.
- Problems After Software Updates: Some owners report that seat adjustment issues began or became more frequent after an over-the-air (OTA) software update.
Potential Hardware/Module Failure
- Complete Loss of a Function: One specific seat adjustment, such as height or recline, stops working entirely while others still function.
- No Response from Any Function: None of the power seat controls work at all, and a vehicle reboot does not solve the problem. This could point to a loss of power or ground to the module, a blown fuse, or a failed module.
Known Issues, Recalls, and Technical Service Bulletins (TSBs)
As of mid-2026, there are no official NHTSA recalls or Technical Service Bulletins (TSBs) specifically for the front power seat control module or its software on the 2022-2025 Lucid Air. Most issues are addressed by Lucid Service on a case-by-case basis, often through software updates or individual component replacement under warranty.
Related Recall: Rear Seat Heaters
There was a recall for some 2022-2023 Lucid Air models concerning the rear seat heaters. A software issue could cause the temperature monitoring to fail, leading to the seats overheating and posing a burn risk. The fix for this issue was an over-the-air (OTA) software update. While this recall does not involve the front seat control module, it highlights how software can impact seat-related functions in the vehicle.
Pro Tip: Before assuming the module has failed, check the vehicle's main fuse box for the power seat fuse. You can also try a full vehicle reboot by holding the Air logo under the 'About' section 🎬 Watch this guide to perform a full system reset in the settings menu. This can often resolve temporary software glitches.
Buying a Used Lucid Air Power Seat Control Module
Due to the high cost of new electronic components, a used OEM module is a practical option. However, there are critical factors to consider for a complex vehicle like the Lucid Air.
1. Verify the Part Number
Part numbers are essential. A module with the wrong number may not communicate correctly with the vehicle. The known OEM part number is P11-M50108. Another number, P11C22200, has also been seen on rebuilt units for the Lucid Air. Always match the part number from your original module to the one you are purchasing. Remove the module to read the number directly if necessary.
2. Physical Inspection
When your used part arrives, inspect it carefully before installation:
- Connectors: Check that all connector pins are straight and free of corrosion or damage.
- Casing: Look for any signs of water damage, such as white or green residue, which can destroy the internal circuit board. Also check for cracks or heat damage.
3. The Programming Requirement
Warning: A replacement power seat control module, even a used OEM one, will likely require programming to function correctly in your vehicle. This process, often called 'vehicle configuration' or 'software calibration', links the module to your car's specific VIN and options. This is not something that can be done at home and will require a visit to a Lucid Service Center or a qualified independent shop with Lucid-specific diagnostic tools.
Failure to program the module can result in it not working at all, or only having partial functionality. You must factor the cost and logistics of programming into the total cost of the repair.
Replacement Information
Replacing the power seat control module is a task for an experienced DIYer or a professional, primarily due to the software programming required.
- Location: The module is typically located under the driver or passenger seat, attached to the seat frame.
- Procedure: Accessing it usually involves removing plastic trim panels around the seat base. In some cases, the seat may need to be unbolted from the floor to provide enough room to work. Once accessed, the module is held by a few screws and has one or more electrical connectors.
- Final Step: After the new module is physically installed, the vehicle must be taken for software programming.
| Specification | Details |
|---|---|
| Installation Difficulty | 4 out of 5 (High - due to mandatory post-installation programming) |
| Estimated Time | 1.0 - 1.5 hours for physical installation |
| DIY Feasible? | Physical installation is feasible; programming is not. |
Cost to Replace a Power Seat Control Module
Prices for Lucid-specific parts can be high and difficult to source. The following are general estimates; expect Lucid parts and labor to be at the higher end of these ranges or more.
| Item | Estimated Cost |
|---|---|
| New OEM Module (Part Only) | $500 - $800+ (Lucid-specific pricing unavailable) |
| Used OEM Module (Part Only) | $150 - $400 |
| Shop Labor (Physical Install) | $114 - $167 |
| Shop Labor (Programming) | $100 - $250 (Typically 1-1.5 hours of labor) |
| Total Professional Replacement (Used Part) | $364 - $817+ |
Frequently Asked Questions (FAQ)
Can I install a used seat control module myself?
You can physically install the part, which involves removing trim and swapping the module. However, the car will then need to be taken to a Lucid Service Center or a specialized shop for software programming to make the module work.
My seat adjustments are just glitchy. Do I need a new module?
Not necessarily. Many issues are caused by software bugs. Try performing a soft reboot of the infotainment system first. If that doesn't work, check with Lucid service to see if there is an available OTA update that might address the problem before you consider replacing hardware.
Is a faulty power seat control module a safety issue?
Generally, no. A failed module is a convenience issue. It will not prevent you from driving the car safely, provided the seat is locked in a position that allows you to operate the vehicle properly. The main safety systems, like airbags and seat belts, are not typically controlled by this specific module.
Why do I have to program a new seat module?
Modern cars use a networked system where modules communicate with each other. Programming, or coding, assigns the new module to your car's specific Vehicle Identification Number (VIN). This tells the car's main computer that the module is a legitimate part and allows it to share data for features like driver profiles, memory functions, and diagnostics.
Helpful Videos
Technical Specifications
OEM Part Numbers: P11-M50108 P11C22200
The module controls multiple DC motors for seat adjustment and communicates with the vehicle's main body control unit over a network bus.
