2014-2020 Mitsubishi Outlander Kick Panel: Fuse Box Guard and Trim Guide
This guide covers the function, common damage, and replacement of the interior kick panels on the 2014-2020 Mitsubishi Outlander, focusing on what to inspect when buying a used part.
- The kick panel's most important job is protecting the interior fuse box and wiring on the driver's side.
- When buying a used panel, the condition of the mounting clips on the back is more important than minor surface scuffs.
- Driver (LH) and passenger (RH) side panels are different parts and cannot be swapped.
- Replacement is a very simple DIY task that can be done in minutes with minimal or no tools.
Symptoms of a Damaged Kick Panel
As a simple plastic trim piece, kick panel failures are always physical. The consequences of the damage, however, can range from cosmetic annoyance to creating a risk for the vehicle's electrical system.
- Loose or Rattling Panel: The most common issue is broken mounting clips. This will cause the panel to feel loose and may create rattling or buzzing sounds as you drive, especially over rough roads.
- Visible Cracks and Scuffs: Heavy use, accidental kicks from heavy boots, or improper removal can cause the plastic to crack or become heavily scuffed. While often just a cosmetic issue, severe cracks can compromise the panel's ability to protect what's behind it.
- Exposed Fuse Box or Wiring: If the panel is completely missing or broken to the point that it no longer covers the area, it leaves the interior fuse box and critical wiring harnesses exposed. This is the most serious symptom, as it makes these components vulnerable to damage from feet, spilled liquids, or moisture tracked into the vehicle, which can lead to serious electrical problems.
Pro Tip: If you find evidence of moisture behind the kick panel, such as water stains or corrosion on the wiring it covers, it may indicate a leak from a windshield seal, door seal, or a blocked A/C drain tube. This issue should be investigated further, as a new kick panel won't solve the underlying water intrusion problem.
Buying a Used 2014-2020 Outlander Kick Panel
Buying a used OEM kick panel is a smart way to save money, as aftermarket replacements are generally not available. However, a careful inspection is essential to ensure you get a part that fits securely and looks right.
Key Inspection Points for a Used Panel:
- Check All Mounting Points: This is the most critical step. Carefully flip the panel over and inspect every single mounting tab and clip receptacle. Look for any that are cracked, stressed, or broken off completely. A panel with even one broken clip may not sit flush and could rattle after installation.
- Inspect for Cracks: Flex the panel slightly to reveal any hairline cracks that might not be obvious at first glance. Pay close attention to the areas around screw holes or sharp bends, as these are common stress points.
- Verify Color and Texture: Mitsubishi may have used slightly different interior colors and textures across different trim levels and years. Compare the used panel to your vehicle's interior in good lighting to ensure it's a good match.
- Confirm the Correct Side: The driver's side (LH) and passenger's side (RH) kick panels are not interchangeable. They are mirror images of each other and have different shapes and part numbers. Ensure you are buying the specific side you need.
- Look for Water Damage: Check for any chalky residue, discoloration, or a musty smell, which could indicate the donor vehicle had a water leak. Avoid parts that show signs of prolonged moisture exposure.
Known Issues, TSBs, and Recalls
As of mid-2026, there are no specific recalls, Technical Service Bulletins (TSBs), or common widespread issues reported for the kick panels on the 2014-2020 Mitsubishi Outlander. Problems with this part are typically related to normal wear and tear or accidental damage rather than a manufacturing or design defect.
Cost of Replacing a 2014-2020 Outlander Kick Panel
Replacement costs are modest, making it an easy repair to justify. Since the job is simple, DIY is the most cost-effective route.
| Part Type | Estimated Cost |
|---|---|
| New OEM | $45 - $70 |
| Used OEM | $25 - $50 |
| New Aftermarket | Not commonly available |
| Shop Labor | $20 - $50 |
Kick Panel Replacement Overview
Replacing the kick panel is a straightforward job that most DIYers can complete in under 15 minutes with basic tools.
- Difficulty: 1 out of 5
- Estimated Time: 0.2 hours
- Tools Needed: Possibly a small flathead screwdriver or trim removal tool. 🎬 Watch: How to safely remove car panels
Basic Steps:
- Remove the Door Sill Plate: The plastic trim plate on the floor of the door opening (the sill plate) often overlaps the kick panel. Gently pull straight up on this plate to release its clips.
- Remove Fasteners: Check for a plastic push-pin or screw holding the kick panel in place. If present, remove it.
- Pull the Panel: Grasp the edge of the kick panel nearest the door opening and pull it firmly but carefully toward the rear of the vehicle or toward the center console 🎬 See this cabin filter and panel removal walkthrough to release the hidden clips.
- Install the New Panel: Align the clips on the new panel with the corresponding holes in the vehicle's body and press it firmly into place until the clips snap in. Reinstall any screw or push-pin and then reinstall the door sill plate by pressing it back down.
Frequently Asked Questions (FAQ)
What is the main purpose of the Outlander's kick panel?
Its main purpose is to protect the interior fuse box (driver's side) and other important wiring from being damaged by your feet, moisture, or dirt.
Is the driver's side kick panel the same as the passenger's side?
No, they are different parts and are not interchangeable. They are shaped differently to fit each specific side of the footwell.
Can a broken kick panel cause electrical problems?
Indirectly, yes. While the panel itself is just plastic, if it's broken or missing, it leaves sensitive electronics like the fuse box and wiring connectors exposed. Water, dirt, or a direct kick to these components could cause short circuits or damage modules.
Why can't I find an aftermarket kick panel?
Interior trim pieces like kick panels are often slow-selling and have low demand, so aftermarket companies typically do not manufacture them. For this part, your only options are usually new OEM from a dealer or a used OEM part from a recycler.
Helpful Videos
Technical Specifications
OEM Part Numbers: 7217A020XB (Right Side) 7217A130XA (Right Side, superseded by 7217A020XB) 7217A018XB (Right Side)
Material: Molded plastic. Color: Typically black or dark gray to match the interior trim.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
