2022-2025 Genesis GV70 Kick Panel: Color Matching and Illuminated Sill Guide

Symptoms of a Failing Kick Panel

Since a kick panel is a static piece of plastic trim, "failure" almost always refers to physical damage rather than a mechanical or electrical problem. However, if your GV70 has the optional illuminated door sills, failure can include electrical issues.

• Visible Cracks, Scuffs, or Gouges: The most common issue is cosmetic damage from passengers' feet hitting the panel upon entering or exiting the vehicle. While minor scuffs are normal, deep scratches or cracks can be unsightly.
• Rattling or Loose Fit: Over time or after being removed for service, the plastic mounting clips can break or weaken. This will cause the panel to fit loosely and may create rattling or buzzing sounds, especially on rough roads or when the stereo is on.
• Panel Falls Off: If enough mounting clips are broken, the kick panel may detach completely, exposing the wiring and components underneath.
• (Illuminated Sills Only) Light Not Working: For GV70 models equipped with optional illuminated door sills, the light may flicker 🎬 Watch: How to install illuminated LED door sills or fail to turn on. This could be an issue with the LED element itself, the wiring connection behind the panel, or a related fuse.
🎬 See this guide to finding and checking your fuses

Known Issues, Recalls, and Technical Service Bulletins (TSBs)

While there are no recalls or TSBs that specifically target the kick panels themselves, several official communications for the 2022-2025 Genesis GV70 involve components located near or behind them. A technician performing these repairs would need to remove the kick panel for access.

• NHTSA Recall 25V-809 (Side Curtain Airbag): A recall was issued for improperly installed side curtain airbags, which could deploy abnormally. Reinstalling the airbag correctly requires removing upper interior trim panels, and often the lower kick panels as well for a complete inspection.
• NHTSA Recall 020G (Transmission Control Harness): Certain 2024 models were recalled for potential water leaks into the transmission control harness, which could cause a short circuit. Inspecting and repairing this harness may require access through the vehicle's interior footwell area.
• Other Recalls: Other safety campaigns for this generation include issues with fuel pumps and seat belt pretensioners. While less likely to require kick panel removal, any major interior or electrical work increases the chance of these panels being removed and potentially damaged if not handled carefully.

Buying a Used 2022-2025 GV70 Kick Panel

Buying a used OEM kick panel is often the best choice, as aftermarket replacements are generally not available and a new factory part can be costly. A used original part ensures a perfect fit and color match. Here’s what to look for.

1. Verify All Mounting Tabs Are Intact

This is the most critical inspection point. Flip the panel over and carefully examine every mounting tab and clip slot. Look for stress marks (thin white lines in the plastic) or outright cracks. Even one broken tab can cause a poor fit and lead to rattles. A good used part should have all its mounting points intact and free of damage.

2. Match the Interior Color EXACTLY

The Genesis GV70 was offered with a wide and complex array of interior colors, including two-tone schemes. Common options include Obsidian Black, Vanilla Beige, Sevilla Red, Ultramarine Blue, and Havana Brown. Do not rely on photos alone, as lighting can be deceptive. The best way to ensure a match is to verify the part number or confirm the color name from the donor vehicle's specifications.

3. Check for Illuminated Sill Compatibility

Genesis offered optional illuminated door sills as a dealer-installed accessory. These are not simple covers; they are complete replacement units that integrate with the kick panel and door sill area. If your vehicle has these, you must buy a replacement compatible with the illuminated version. If it does not, a standard panel is required. Inspect the used part for any wiring harnesses or transparent sections for lighting that would indicate it's for an illuminated setup.

4. Inspect for Cosmetic Damage

Check the face of the panel for deep gouges, heat warping, or chemical stains that won't come out with a simple cleaning. Minor scuffs are typical for a used kick panel and can often be minimized with a quality interior detailing product, but deep scratches are permanent.

Installation Guide

Replacing a kick panel is a straightforward job suitable for a DIYer with basic tools. The process typically takes less than 30 minutes.

Difficulty: 1 out of 5
Estimated Time: 0.5 Hours

Tools Needed:

• Plastic Trim Removal Tool Kit
• Phillips Head Screwdriver (if applicable)
• Needle-Nose Pliers (if applicable)

Step-by-Step Process:

1. Remove the Door Sill Plate: The door sill plate (the trim piece you step over) often overlaps the kick panel. Using a plastic trim tool, gently pry upwards along the edge of the sill plate to release its clips. Start from one end and work your way across. Lift it up and set it aside.
2. Locate Fasteners: Look for any visible screws or plastic push-pin clips holding the kick panel in place. These are sometimes hidden under small plastic covers that can be popped off with a small flathead screwdriver or trim tool. Remove any fasteners you find.
3. Pry the Panel Loose: Insert a plastic trim tool between the kick panel and the vehicle's body, usually along the edge where the weatherstripping is. Gently pry to release the hidden metal or plastic clips. You will hear them pop as they release. Work your way around the panel until it feels loose.
4. Disconnect Electrical Components (if any): If the panel has a light for an illuminated sill or is near a component like a hood release lever, be careful not to pull it away too quickly. Disconnect any wiring harnesses by pressing the release tab on the connector and pulling it apart.
5. Install the New Panel: Align the new kick panel's clips with the corresponding holes in the vehicle's body. If there was a wiring connector, plug it back in first. Give the panel a firm push with the palm of your hand over each clip location to snap it into place. Reinstall any screws or push-pins.
6. Reinstall the Door Sill Plate: Align the clips on the door sill plate with their holes and press down firmly to secure it.

Cost Comparison

The cost for a replacement kick panel varies significantly between new OEM, used OEM, and labor.
