2020-2025 Jeep Gladiator RF Hub Failure: Solving the 'Key Fob Not Detected' Mystery

Symptoms of a Failing RF Hub

When the RF Hub in a Jeep Gladiator begins to fail, the symptoms are often sudden and can be confusing. The most common issue is the vehicle failing to recognize the key fob.

• "Key Fob Not Detected" Message: The most frequent symptom is a message on the instrument cluster stating "Key Fob Not Detected" when you try to start the vehicle.
• No-Start Condition: The engine will not start when you press the start button with your foot on the brake. All you might hear is a click.
• All Key Fobs Stop Working: A primary clue that the RF Hub is the problem, rather than a key fob battery, is that all of your vehicle's key fobs will stop working at the same time.
• Remote Functions Fail: The buttons on the key fob for locking, unlocking, remote start, and the panic alarm will become unresponsive, even though the small LED light on the fob may still blink.
• Intermittent Operation: The failure may start intermittently. It might work one moment and fail the next, often becoming more frequent over time.

Known Issues, TSBs, and Recalls

Known Issue: Rear Window Leaks

A well-documented cause of RF Hub failure in the Jeep Gladiator is water intrusion from a leaking rear window. The RF Hub module is located on the back interior wall of the cab, behind the driver's-side rear passenger seat. Water can leak from the window seal and drip directly onto the module and its electrical connectors, causing corrosion and short-circuiting the unit. If you are replacing an RF Hub, it is critical to inspect for signs of water damage in this area and repair any leaks to prevent the new module from failing as well.

Technical Service Bulletins (TSBs)

Jeep has issued several TSBs related to the keyless entry system that may involve reprogramming the RF Hub:

• TSB S2208000138: Addresses complaints of decreased range for remote start and Remote Keyless Entry (RKE).
• TSB 18-040-24 REV. A: Pertains to intermittent or non-working RKE functions and issues with programming new keys.
• TSB 9004531: A general bulletin referencing the "RECEIVER, Hub".
• Software Updates: Other bulletins exist that call for reprogramming (flashing) the RF Hub with updated software to resolve various bugs, including no-start conditions or poor passive entry response.

Vehicle Recalls

There are no active recalls specifically for the RF Hub module. However, owners should be aware of a major safety recall for a potential fire risk.

CRITICAL: Programming and Installation

Replacing the RF Hub is not a simple plug-and-play repair. The RF Hub is a core security component of the vehicle's immobilizer system.

A new or used RF Hub MUST be professionally programmed to your vehicle. Without programming, the vehicle will not start.

The programming process involves several steps:

1. Module Installation: The new or used hub is physically installed in the vehicle.
2. VIN Programming: A diagnostic tool is used to write your vehicle's unique 17-digit Vehicle Identification Number (VIN) to the module. If this is not done, a VIN mismatch will prevent the engine from continuing to run.
3. Key Programming: All existing key fobs must be re-learned and programmed to the new RF Hub. Any fobs not present during the programming session will no longer work.

This procedure requires a dealer-level diagnostic tool, such as Mopar's wiTECH software, and access to the vehicle's security PIN code. A well-equipped independent auto repair shop or a licensed automotive locksmith with advanced tools (like Autel or AlfaOBD) and experience with Chrysler's Secure Gateway Module may also be able to perform the programming. Attempting to program the module with incorrect tools or procedures can permanently damage, or "brick," the module.

Buying a Used Keyless Entry Receiver (RF Hub)

Purchasing a used RF Hub is a cost-effective option, but you must follow specific steps to ensure it will work in your Gladiator. Because this is a security module, you cannot simply install it and expect it to work.

• Match the Part Number Exactly: The single most important rule is to match the Mopar part number on the replacement hub with your vehicle's original part. Part numbers can vary based on vehicle options. Using a hub with a different part number will likely fail.
• Inspect for Corrosion: Given the known water leak issue, carefully inspect any used module for signs of corrosion on the casing, pins, or connectors. Do not buy a part that shows any evidence of water damage.
• Plan for Programming: Before you buy, have a plan for programming. Your options are:
  1. Professional Installation: Have a dealership or qualified independent shop source the used part and perform the installation and programming.
  2. Cloning Service: This is an excellent option for DIY replacement. You mail your original (faulty) RF Hub and the replacement (used) RF Hub to a specialized service. They will copy the security data from your old module to the replacement one. The cloned module is then returned to you and becomes plug-and-play, requiring no further programming. This is only possible if your original module can still be read.
• Why Used OEM is a Good Choice: For a complex electronic module like the RF Hub, a used OEM part is often more reliable than a new, unbranded aftermarket part. The OEM module was designed and tested specifically for your vehicle's systems, ensuring proper communication and function once programmed.

Cost to Replace a Jeep Gladiator RF Hub

Costs can vary based on your location and the parts/service you choose. Labor typically involves removing interior trim panels behind the rear seat, which takes around 1-1.5 hours.
