2019 Nissan Murano Rear Interior Grab Bar: A Guide for Sunroof-Equipped Models
This guide covers the specific rear interior grab bar required for 2019 Nissan Murano models with a sunroof, including common issues and replacement tips.
- This rear grab bar (part number 739409UF0A) is only for 2019 Nissan Murano models that have a sunroof.
- Failure is almost always physical (cracks, looseness) and does not present a driving safety issue.
- Replacement is a very easy DIY task, typically taking less than 15 minutes with basic tools.
- When buying used, check for stress cracks near the mounting points and ensure the bolt covers are included.
Symptoms of a Failing Interior Grab Bar
As a non-mechanical part, failure of an interior grab bar is typically physical and easy to spot. The symptoms are straightforward and usually do not require professional diagnosis.
- Cracked or Broken Handle: The most common failure is physical breakage. The plastic may become brittle over time and crack or snap under pressure. Look for hairline fractures, especially around the mounting points.
- Loose or Rattling Handle: The bolts securing the handle to the roof structure can become loose, causing the handle to feel wobbly or make a rattling noise while driving. This can happen from normal use or if the handle was improperly installed.
- Missing or Damaged Mounting Covers: Small plastic caps cover the mounting bolts. These can break, fall off, or be lost during removal, leaving the mounting hardware exposed.
Known Issues, TSBs, and Recalls
As of this writing, there are no specific recalls or Technical Service Bulletins (TSBs) from Nissan related to the interior grab bars for the 2019 Murano. General owner forums and complaint databases do not indicate a widespread or common problem with these handles breaking under normal use. 🎬 Watch: Common issues to check before buying a 2019 Murano The most significant issue is ensuring you purchase the correct part for your specific vehicle configuration.
Compatibility Warning: The part number 739409UF0A is specifically for the two REAR roof grab handles on 2019 Murano models equipped WITH a sunroof. The presence of the sunroof assembly changes the roof liner and mounting points, requiring a specific handle. Do not assume handles from non-sunroof models or from the front positions are interchangeable.
Buying a Used 2019 Murano Interior Grab Bar
A used OEM grab bar is an excellent, cost-effective option, as it's a simple part that doesn't typically wear out. However, there are a few key things to inspect before purchasing.
- Verify the Part Number: Insist on verifying the OEM part number: 739409UF0A. This is the best way to ensure you are getting the correct part for your sunroof-equipped Murano.
- Inspect for Stress Fractures: Closely examine the entire handle, paying special attention to the areas where the handle curves and connects to the mounting points. Look for tiny white or light-colored lines in the plastic, which indicate stress and potential future failure.
- Check the Mounting Points: Ensure the plastic around the bolt holes is intact and not cracked or broken. This is where the most force is applied.
- Confirm Color and Finish: Interior trim colors can vary. Make sure the color of the used handle matches your vehicle's interior. Check for significant fading or discoloration from sun exposure.
- Include the Covers: Make sure the small plastic covers that hide the mounting bolts are included. These are often lost and can be difficult to source separately.
Replacement Information
Replacing a rear grab bar on a 2019 Murano is a simple DIY task that requires minimal tools and time.
Step-by-Step Guide:
- Expose the Bolts: Using a small, flat-head screwdriver or a plastic trim removal tool, carefully pry open the small covers on each end of the grab handle. They are typically hinged on one side.
- Remove the Bolts: You will see a bolt inside each mounting point (usually a 10mm hex head). Use a socket wrench to remove both bolts. Be prepared to support the handle as you remove the second bolt.
- Install the New Handle: Position the new handle over the mounting holes. Hand-thread both bolts to ensure they are not cross-threaded.
- Tighten and Finish: Tighten the bolts until they are snug. Do not overtighten, as this can crack the plastic handle or strip the threads. Snap the mounting covers closed.
Installation Details
- Difficulty: 1 out of 5 (Beginner)
- Estimated Time: 10-15 minutes
- Tools Required: Small flat-head screwdriver or trim tool, socket wrench (likely 10mm socket).
Cost Comparison
Prices for interior components can vary. This table provides an estimated cost breakdown.
| Part Type | Estimated Cost |
|---|---|
| New OEM (Dealer) | $75 - $95 |
| New Aftermarket | Not commonly available |
| Used OEM (Salvage) | $20 - $45 |
| Shop Labor | $25 - $50 (most shops have a minimum charge) |
Frequently Asked Questions (FAQ)
Will this grab handle fit a Murano without a sunroof?
No. This specific part, 739409UF0A, is confirmed for models with a sunroof. The roof structure and headliner are different on non-sunroof models, requiring a different part.
Are the front and rear grab handles the same on a 2019 Murano?
No, they often have different part numbers and shapes due to the curvature of the roof and headliner. This part number is specifically for the rear positions.
Why did my original grab handle break?
Failures are rare but can happen. The most common causes are excessive force (e.g., using it to pull oneself into the vehicle repeatedly over years), degradation of the plastic from extreme heat cycles, or an unseen manufacturing defect.
Can I just glue a cracked handle?
It is not recommended. A grab handle is a safety and convenience item that needs to support a person's weight. Glue is unlikely to provide the necessary strength, and the handle will likely fail again, possibly at an inconvenient time.
Helpful Videos
Technical Specifications
OEM Part Numbers: 739409UF0A
Rear roof-mounted interior grab handle for models with a sunroof.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
