2014-2016 Cadillac ELR Hood: Aluminum Repair, Part Numbers, and Replacement

Symptoms of a Damaged Hood

Since the hood is a non-moving body panel, 'failure' typically means physical damage or issues with its related components. Here’s what to look for:

• Visible Damage: Dents, dings, creases, and scratches from collisions or impacts are the most common issues. Aluminum is more prone to sharp creases and is more difficult to repair than steel.
🎬 Watch: How paintless dent removal works on aluminum hoods
• Poor Alignment: A hood that doesn't line up correctly with the fenders and bumper can indicate previous accident damage to the hood itself or the underlying support structure. Uneven gaps are a major red flag.
• Latch Problems: Difficulty opening or closing the hood can point to a faulty latch mechanism or misalignment. If the secondary safety latch is damaged, the hood could unexpectedly fly open while driving.
• Vibration or Fluttering: If the hood vibrates at speed, it may not be properly latched, the bump stops may be missing or misadjusted, or the panel itself could have structural damage.
• Engine Start Issues: The ELR's gas engine may start if the vehicle detects the hood is open as a safety precaution. A faulty hood latch sensor could cause the engine to run when it otherwise wouldn't, impacting your electric range.

Known Issues, TSBs, and Recalls

As of mid-2026, there are no specific recalls or Technical Service Bulletins (TSBs) issued by GM or the NHTSA for the hood panel of the 2014-2016 Cadillac ELR.

However, the 2014 model year was subject to two unrelated safety recalls:

• NHTSA Recall 14V144000: Addressed an issue with the Electronic Stability Control (ESC) software, which could fail to warn the driver if the system was degraded. The fix was a software recalibration by the dealer.
• NHTSA Recall 14V446000: Related to an incomplete weld on the seat hook bracket assembly, which could prevent the front seats from staying secured in a crash.

These recalls do not affect the hood, but it's wise to ensure they have been performed on any used ELR you are considering.

Buying a Used 2014-2016 ELR Hood: What to Check

Given that new OEM hoods are becoming difficult to find and no aftermarket alternatives exist, a used OEM hood is often the only practical option. Here is a detailed guide for inspecting a recycled hood.

Inspection Checklist:

• Check for Hidden Repairs: Since the hood is aluminum, a magnet will not stick to it. Bring a small flashlight to inspect the surface from a low angle. Look for 'waves', ripples, or changes in texture that indicate body filler. Pay close attention to the underside for signs of hammer marks or repair work.
• Examine Edges and Seams: Look at the factory seams along the edges of the hood. If they are cracked, flaking, or look like they've been redone, the hood has likely been repaired.
• Inspect the Structure: Check the underlying frame of the hood. Look for any cracks, especially around the hinge and latch mounting points. Damage here can compromise the hood's structural integrity.
• Verify Fitment: The ELR was produced for model years 2014 and 2016, with no 2015 models sold in the US. All hoods from 2014-2016 are physically interchangeable. The OEM part number 23435413 was superseded by 23235158. Both will fit.
• Assess Overall Condition: Look for deep scratches that may require significant prep work. Minor surface scratches are acceptable, as the hood will need to be repainted anyway. Avoid hoods with significant corrosion, especially where steel bolts or latches attach to the aluminum panel.

Cost of Replacing a 2014-2016 Cadillac ELR Hood

Replacing the hood on an ELR involves several costs. Because the hood is aluminum, painting and prep costs can be higher than for a standard steel hood.

Installation Tips & Difficulty

• Difficulty: 3/5 (Moderate)
• DIY Feasible: Yes, but not recommended without experience.
• Estimated Time: 1.5 - 2.5 hours (not including paint).

While the physical act of unbolting and bolting on the hood is straightforward, the challenge lies in proper handling and alignment. Professional installation is highly recommended.

Key Steps & Considerations:

1. Use Two People: The aluminum hood is lighter than steel but large and awkward. Attempting to handle it alone will almost certainly result in damage to the hood, fenders, or windshield.
2. Protect Surrounding Areas: Use painter's tape and blankets to cover the fenders, bumper, and windshield to prevent scratches during removal and installation.
3. Scribe Hinge Locations: Before loosening the bolts that attach the hood to the hinges, use a marker to trace around the hinge plates. This will give you a starting point for aligning the new hood.
4. Transfer Components: The hood insulator, bump stops, and windshield washer nozzles will need to be transferred from the old hood to the new one.
5. Alignment is Key: After loosely installing the new hood, close it slowly to check the gaps with the fenders and bumper. Adjust the hood at the hinge bolts until the gaps are even on all sides. This is a time-consuming process of small adjustments.
🎬 Watch: Step-by-step guide to aligning car hood panels
