2018-2025 Range Rover Velar Headlight Guide: DRL Failures, Recalls, and Facelift Changes

Headlight Variations: The Most Important Check Before You Buy

The Range Rover Velar was offered with several different headlight systems across its life, and they are NOT interchangeable. The most significant change occurred with the 2024 model year facelift. Failure to identify the correct headlight for your vehicle will result in a part that does not fit physically or work electronically.

2018-2023: Pre-Facelift Models

Vehicles from these years were primarily equipped with two main types of all-LED headlights:

• Premium LED: This was a common configuration, featuring a distinct LED Daytime Running Light (DRL) signature.
• Premium LED with Auto High Beam (AHB): An upgraded version that automatically dips the high beams for oncoming traffic. This is a software and hardware feature, and the assemblies are specific.
• Matrix LED: An optional upgrade on higher trims, this system uses multiple LED segments to shape the light beam, blanking out sections to avoid dazzling other drivers without turning off the high beams completely.

2024-2025: Post-Facelift Models

For the 2024 model year, the Velar received a major update, including a redesigned front end.

• Pixel LED: These headlights are physically slimmer and feature a new, jewel-like DRL signature. They offer more advanced adaptive capabilities than the previous Matrix system.

Known Issues, TSBs, and Recalls

Recall N556: Auto High Beam Indicator

For 2018-2020 Range Rover Velar vehicles, a recall was issued because the instrument cluster would not display the 'AUTO' text when the Auto High Beam (AHB) feature was active. This did not affect the headlight's operation but failed to comply with federal safety standards. The fix is a simple software update performed by a dealer and does not require any parts to be replaced.

TSB SSM75648: Moisture in Headlamp

Land Rover issued a Technical Service Bulletin regarding moisture or condensation inside the headlamp lens. While the official position is that minor fogging is normal for cooler-running LED lights and should clear on its own, persistent condensation or water droplets point to a failed seal in the assembly.

Common Problem: Daytime Running Light (DRL) Failure

The most widely reported issue with Velar headlights is the failure of the signature LED DRL strip. Owners report that the DRL will either fail to illuminate completely, appear dim, or turn off after a few seconds. This is typically caused by a faulty internal electronic module or driver chip, not a "burnt-out bulb." 🎬 Watch: How to repair the internal DRL control module Because the headlight is a sealed unit, the official repair is to replace the entire assembly, which is extremely expensive.

Symptoms of a Failing Headlight Assembly

• Dim or Non-Functioning DRL: The signature LED strip is out on one side. This is the most common failure.
• Intermittent Operation: The DRL or main headlight flickers or works only some of the time.
• Warning Lights: A headlight failure message may appear on the dashboard.
• Persistent Condensation: Large water droplets or a constant fog inside the lens that does not clear after driving with the lights on for 30 minutes. This indicates a breach in the housing seal.
• Adaptive Feature Malfunction: Auto High Beam or auto-leveling features stop working correctly.
• Discoloration: The LED light output appears yellow or off-color compared to the other side.

Buying a Used Headlight Assembly: What to Check

Given the high cost of new OEM headlights, a used OEM assembly is a popular choice. However, you must be extremely careful to get the right part in good condition.

1. Verify Compatibility Above All Else

• Model Year: Is it for a 2018-2023 or a 2024-2025 model? This is the most important check.
• Features: Does your Velar have Auto High Beam (AHB)? The part must match. Check the seller's description for terms like "Premium" or "With Auto High Beam."
• Part Number: If possible, match the OEM part number from your old headlight to the new one. Numbers are often found on a sticker on the top or back of the housing.

2. Physical Inspection

• All Mounting Tabs Intact: This is the most common damage on used headlights. The plastic tabs are brittle and easily snap in minor impacts or during removal. Look for any signs of cracking, stress, or plastic-welded repairs. A part with repaired tabs is less secure than one with all original tabs intact.
• Inspect the Lens: Check for deep scratches, rock chips, and especially "crazing" — a network of fine cracks in the lens surface. Minor hazing can be polished, but deep crazing requires professional lens replacement.
🎬 See how a damaged headlight lens is professionally replaced
• Check for Moisture Signs: Look for a "water line" or mineral deposits on the inside of the lens or on the chrome/black plastic interior. This is a clear sign the unit had a bad seal and should be avoided.
• Connector Integrity: Ensure the main electrical connector and all pins are clean, straight, and not broken or corroded.

3. Included Components

Replacement and Calibration

Replacing a Velar headlight is a complex job rated as difficult for a DIY mechanic.

• Bumper Removal: The front bumper cover must be partially or fully removed to access the lower and side mounting bolts of the headlight. This involves removing screws in the wheel wells, under the engine, and on top of the grille.
🎬 Watch: Step-by-step guide to removing the bumper and headlights
• Aiming is Required: After installation, the headlights must be properly aimed to ensure correct road illumination and to avoid blinding other drivers. This is a legal requirement.
• Calibration May Be Necessary: For vehicles with adaptive features, the new headlight module may need to be electronically calibrated by a dealer or a qualified independent shop with the correct diagnostic tools for the auto-leveling and Auto High Beam systems to function correctly.

Cost Comparison

Frequently Asked Questions (FAQ)
