2020 Jaguar XE Headlight: Facelift LED Types, Faults, and Replacement

2020 Jaguar XE Headlight Variants

For the 2020 model year, the Jaguar XE received a significant facelift which included an update to the headlight design and technology. All trims now come standard with full LED headlights, but there are different versions that are not interchangeable. It is critical to identify the correct type for your vehicle before purchasing a replacement.

• Premium LED Headlights with Signature DRL: This was the standard headlight on most 2020 XE models, including the S and R-Dynamic S trims. It features a distinct 'J-Blade' Daytime Running Light (DRL) signature.
• Matrix LED Headlights with Signature DRL: This was an available upgrade, often bundled in higher trim packages. These headlights offer advanced features like adaptive lighting that can shape the beam to avoid dazzling other drivers while maximizing illumination.

Symptoms of Failure

While the LED units are designed for longevity, failures can still occur, often in the electronic components rather than the LEDs themselves.

• Dim or Flickering Light Output: This can indicate a problem with the internal LED driver or a failing LED chip.
• One or More Lights Completely Out: This could be a failure of the low beam, high beam, or the DRL strip. Since the LEDs are integrated, the entire assembly usually needs to be replaced.
• "Adaptive Front Lighting Fault" Message: For cars equipped with adaptive or Matrix LED headlights, this dashboard warning points to a failure in the leveling motors, control module, or the sensors that provide data to the system.
• Moisture or Condensation Inside the Lens: While small amounts of fine mist may be normal under certain atmospheric conditions and should clear on their own, large water droplets or pooling water indicate a failed seal. This can lead to corrosion and premature failure of the internal electronics.

Buying a Used Headlamp Assembly

Purchasing a used OEM headlamp is a cost-effective way to replace a damaged unit, often providing better quality and fit than new aftermarket alternatives. Here’s what to inspect:

• Verify the Part Number: This is the most critical step. Match the part number from your old headlight to the replacement. Part numbers like LX73-13W029-BB (Right) and LX73-13W030-DB (Left) are common, but the final two letters are crucial as they denote the specific technology (e.g., standard LED vs. Matrix). Do not rely on visual appearance alone.
• Inspect the Lens: Look for deep scratches, rock chips, and signs of hazing or UV damage (yellowing). Minor surface scratches can often be polished, but deep gouges or internal crazing cannot be fixed.
• Check All Mounting Tabs: Carefully inspect every mounting tab and bracket on the top, bottom, and sides. These are often made of brittle plastic and can easily crack or break during a minor collision or even during removal. A broken tab can cause the headlight to vibrate or be misaligned.
• Examine the Housing: Check the black plastic rear housing for any cracks or signs of repair (e.g., plastic welding, epoxy). A crack can compromise the seal and allow moisture to enter.
• Confirm Modules are Included: LED headlights have one or more control modules bolted to the housing. These are essentially the 'ballasts' for the LEDs. Confirm whether the used assembly includes these modules. Sometimes they are sold separately, and your original modules may or may not be compatible with the replacement assembly.

Known Issues, TSBs, and Recalls

As of this writing, there are no specific recalls or widespread Technical Service Bulletins (TSBs) directly related to headlight failure on the 2020 Jaguar XE in the North American market.

• Condensation: Jaguar has released general bulletins for other models explaining that a light mist on the inside of the lens can be normal and will dissipate with use. However, if you see large water droplets or water pooling at the bottom, the headlight seal has failed and the unit should be replaced to prevent electrical damage. This can be caused by impact damage or improper installation of the rear service covers.
• Recalls: There are recalls for the 2020 Jaguar XE related to the rearview camera wiring and rear body structure, but none for the headlights themselves.

Replacement Process Overview

Replacing the headlamp assembly on a 2020 Jaguar XE is a moderately difficult job that typically requires removing the front bumper cover.

1. Disconnect the negative battery terminal.
2. Raise the front of the vehicle and remove the front wheels.
3. Remove the fender liners to access the hardware securing the bumper to the fenders.
4. Remove the upper radiator cover and all screws and clips holding the top and bottom of the bumper cover.
5. Carefully disconnect any sensor or washer-fluid harnesses and pull the bumper cover away from the vehicle.
🎬 Watch this step-by-step guide on removing the front bumper
6. With the bumper removed, you will have clear access to the bolts (typically 3-4) holding the headlamp assembly in place.
7. Disconnect the main electrical connector from the back of the headlight and remove the assembly.
8. Installation is the reverse of removal.

Cost Comparison

Prices for a single 2020 Jaguar XE LED headlamp assembly can vary significantly.

Note: Labor costs are for replacement only and do not include potential calibration for adaptive systems. Aftermarket quality can be inconsistent regarding light output, beam pattern, and long-term durability.
