2009-2014 Toyota Matrix Grille: A Guide to Trims, Part Numbers, and Replacement

Grille Variations by Year and Trim Level

Finding the right grille for a 2009-2014 Toyota Matrix requires paying close attention to both the model year and the trim level. Toyota updated the front-end styling in 2011, and different trims (Base, S, and XRS) often used distinct grille designs.

2009-2010 Models

For the first two years of this generation, the Matrix had a consistent design across its trims, but with subtle differences.

• Base/XR/AWD: These models typically used a simple black grille with a horizontal bar pattern. The OEM part number for this upper grille is often cited as 53111-02420.
• S & XRS: The sportier S and XRS trims featured a more aggressive mesh-style grille to set them apart.

2011-2014 Models (Post-Facelift)

In 2011, Toyota refreshed the Matrix's front bumper and grille. Parts from 2009-2010 models are not interchangeable with 2011-2014 models without swapping the entire front bumper assembly.

• Base: The base model continued with a standard grille design, though updated for the new bumper shape.
• S (Sport Package): The 'S' trim, or models with the sport package, received a unique grille, identified by OEM part number 53111-02620.

There are also upper and lower grilles. The main upper grille houses the emblem, while a separate lower grille is integrated into the bumper cover. An example of a lower grille part number is 53112-02110.

Symptoms of a Damaged Grille

Grille failure is almost always due to physical damage rather than mechanical wear. Here’s what to look for:

• Cracks, Holes, and Missing Pieces: This is the most common symptom, usually caused by impacts from road debris, animals, or minor front-end collisions. Large holes can expose the radiator and A/C condenser to damage.
• Loose Fit or Rattling: The plastic mounting tabs and clips that hold the grille to the bumper cover can become brittle and break over time. A loose grille may vibrate or rattle, especially at higher speeds.
• Faded or Peeling Finish: Over years of exposure to sun and weather, the plastic can fade from black to gray, or any chrome plating can start to peel and corrode.

Buying a Used Grille: What to Inspect

A used OEM grille is often a better choice than a cheap aftermarket one because it guarantees a perfect fit and uses higher-quality, more durable plastic. However, a thorough inspection is critical before buying.

1. Confirm the Exact Model and Year: Double-check that the grille comes from a Matrix of the same year range (2009-2010 or 2011-2014) and trim level (Base, S, etc.) as yours. A grille from an 'S' model might not fit a Base bumper correctly.
2. Inspect All Mounting Tabs: This is the most important check. Carefully examine the back of the grille. Turn it over and look at every single clip and mounting point. Even one broken tab can cause a poor fit or rattling. If any tabs are cracked or missing, it's best to pass on the part.
3. Check for Hidden Cracks: Look for hairline fractures in the plastic, especially around screw holes and the edges. What looks like a small scratch could be a crack that will spread once installed.
4. Examine the Finish: Check for deep gouges, peeling chrome, or heavy sun fading. While some fading can be restored with plastic trim restorer, deep damage is permanent.
5. Verify the Emblem Status: See if the Toyota emblem is included and in good condition. Sometimes they are sold separately. If you plan to transfer your old emblem, make sure the mounting points on the new grille are intact.

Replacement Difficulty and Cost

Replacing the grille on a 2009-2014 Toyota Matrix is a straightforward job suitable for a DIYer with basic tools.

• Difficulty: 2 out of 5
• Estimated Time: 0.5 - 1 hour
• Tools Needed: 10mm socket, ratchet, flathead screwdriver, and a plastic trim removal tool to avoid scratching the paint.

Basic Replacement Steps

While the exact procedure varies slightly between pre- and post-facelift models, the general process is similar. On some models, the entire bumper cover must be loosened or removed to access the grille's rear clips and screws.

1. Open the hood and remove the plastic radiator sight shield by popping out the plastic retaining clips.
2. Remove any screws or bolts at the top of the grille, typically using a 10mm socket.
3. Carefully release the clips holding the grille to the bumper cover. This is where a trim removal tool is helpful to gently pry without causing damage.
4. Once all clips are released, the grille can be pulled forward and removed.
5. If you are reusing your emblem, carefully release its clips from the back of the old grille and snap it into the new one.
6. Installation is the reverse of removal. Align the new grille, press firmly to engage all the clips, and reinstall the screws and radiator cover.

Cost Comparison

Prices for grilles can vary significantly based on the source and type.

Known Issues, Recalls, and TSBs

A search of the National Highway Traffic Safety Administration (NHTSA) database shows no recalls or technical service bulletins (TSBs) specifically for the grille on the 2009-2014 Toyota Matrix. Any issues with the grille are related to cosmetic wear or physical damage from use, not a manufacturing defect.

While there have been several recalls for this generation of Matrix, they pertain to issues like airbags, accelerator pedals, and power window switches, not the grille itself.
