1991-1993 Mercury Cougar Grille: Chrome LS vs. Painted XR7 Guide
Avoid buying the wrong part; this guide clarifies the critical differences between the chrome LS and body-colored XR7 grilles for the 1991-1993 Cougar.
- The most critical detail is the trim level: LS models use a chrome grille (F1WY8200D), while XR7 models use a body-color painted grille.
- For 1993, the LS trim was dropped, but the base XR7 model often used the chrome LS-style grille.
- When buying a used grille, the most important inspection is for intact mounting tabs on the back; they are commonly broken and essential for proper fit.
- New OEM grilles are no longer produced by Ford, making used OEM parts the most common replacement option.
Key Differences: LS vs. XR7 Grilles (1991-1993)
The single most important factor when buying a grille for a 1991-1993 Mercury Cougar is understanding the difference between the trim levels. Choosing the wrong one will result in a part that doesn't match your car's original appearance.
1991-1992 Models
- LS (Luxury Sport): The LS trim came standard with a chrome grille. This grille features vertical chrome slats with a black background and a chrome outer frame. The correct OEM part number for this grille is F1WY8200D.
- XR7 (Performance): The sport-oriented XR7 trim featured a body-colored grille. This grille has the same shape but was painted to match the exterior color of the car, giving it a more uniform, monochromatic look. The part number for the XR7 grille varies by color but can include F1WB-B200-BDW or F1WY8200E.
The Confusing 1993 Model Year
For 1993, Mercury dropped the LS trim level and badged all Cougars as XR7. However, the base model 1993 XR7 was essentially a de-contented version of the previous performance XR7, effectively replacing the old LS. This means:
- A base 1993 Cougar XR7 (with the standard 3.8L V6) likely came with the chrome LS-style grille.
- An upgraded 1993 Cougar XR7 (especially those with the optional 5.0L V8) would have the body-colored grille to maintain its sporty positioning.
Pro Tip: The best way to know which grille your 1993 Cougar had is to check its original features or look for evidence of the original grille. If you're unsure, the chrome grille was far more common overall.
Symptoms of a Damaged Grille
Since a grille has no moving parts, failure is always visual and the result of physical damage. Here’s what to look for:
- Cracks or Missing Pieces: The most obvious sign of failure is impact damage from road debris, animals, or a minor collision. The plastic can become brittle with age, making it more susceptible to cracking.
- Peeling or Pitted Chrome: On LS models, the chrome plating can bubble, peel, or become pitted over time due to weather exposure and road salt.
- Broken Mounting Tabs: The plastic tabs that hold the grille to the car are a common failure point. If they break, the grille can become loose, rattle, or even fall off.
- Clogged Fins: While less common, an accumulation of bugs, leaves, and dirt can block airflow through the grille, potentially contributing to higher engine temperatures.
Buying a Used 1991-1993 Cougar Grille
New OEM grilles from Ford have been discontinued for many years. Your best option is a high-quality used OEM part or a new aftermarket part. Given the age of the vehicle, used OEM parts are far more common.
Inspection Checklist for a Used Grille:
- Check All Mounting Tabs: This is the most critical inspection point. Flip the grille over and carefully inspect every single mounting tab and clip location. Even one broken tab can cause fitment issues or rattling. Ask the seller for clear photos of the back of the grille. A grille with all tabs intact is rare and valuable. 🎬 See how to repair broken plastic tabs
- Examine the Chrome (LS Grille): Look closely for any signs of pitting, bubbling, or peeling. Minor pitting might be acceptable, but peeling chrome is difficult to repair and looks bad.
- Inspect for Cracks (XR7 Grille): For body-colored grilles, check for stress cracks, especially around the mounting points. Also, check if the paint is original or a cheap respray that could flake off.
- Verify the Emblem: Many used grilles are sold without the Mercury cat head emblem. Confirm if the emblem is included and in good condition. If not, you will have to source one separately or transfer it from your old grille.
- Confirm the Trim Style: Double-check whether you are buying a chrome LS grille or a painted XR7 grille. Do not rely on the listing title alone; look at the photos carefully.
Cost Comparison
Prices for these grilles can vary based on condition and availability. Since New OEM parts are no longer made, the market consists of used OEM and new aftermarket units.
| Part Type | Estimated Price Range | Notes |
|---|---|---|
| New OEM | N/A | This part is no longer available new from Ford. |
| New Aftermarket | $120 - $160 | Primarily available for the more common chrome LS style. Fit and finish may not be identical to OEM. |
| Used OEM | $70 - $150 | Price depends heavily on condition, especially the integrity of the mounting tabs and chrome. |
| Shop Labor | $50 - $150 | Most shops will charge their minimum rate, typically 0.5 to 1 hour of labor. |
Installation Guide
Replacing the grille on a 1991-1993 Cougar is a straightforward job that most DIY mechanics can complete with basic hand tools.
- Difficulty: 1/5 (Very Easy)
- Estimated Time: 30 minutes
- Tools Needed: Screwdriver set, possibly a small socket set.
Basic Steps:
- Open the hood to access the top of the grille.
- Locate and remove the screws or fasteners along the top edge of the grille that secure it to the radiator support or header panel.
- Carefully pull the top of the grille forward. The bottom is likely held in by clips.
- Gently but firmly pull the grille upward and outward to release the bottom clips from their slots in the bumper cover. Be careful not to break the old, brittle plastic.
- If you are reusing your emblem, carefully remove it from the old grille and install it on the new one.
- To install the new grille, align the bottom clips with the slots in the bumper and push them into place.
- Align the top of the grille and reinstall the mounting screws. Do not overtighten them.
Warning: The plastic on these 30+ year old cars is brittle. Work slowly and carefully when releasing the clips to avoid breaking them on the grille or the bumper.
Frequently Asked Questions (FAQ)
Will an XR7 grille fit on an LS model, or vice-versa?
Yes, the physical mounting points for both the chrome LS and painted XR7 grilles are identical for the 1991-1993 model years. You can swap them, but the appearance will be different from the original factory look for that trim.
Can I paint my chrome LS grille to look like an XR7 grille?
Yes, but it requires proper preparation. You would need to scuff the chrome thoroughly with sandpaper or a scuff pad, apply an adhesion promoter or self-etching primer designed for shiny surfaces, and then apply your color and clear coat. Simply spraying paint over smooth chrome will result in it peeling off quickly.
🎬 Watch: How to paint over chrome successfullyIs a broken grille a safety inspection failure?
Generally, no. A cracked or cosmetically damaged grille is not considered a safety item and is unlikely to cause a failed inspection. However, if the grille is so broken that it is loose and in danger of falling off the vehicle, it could be cited as a hazard.
Where can I find the part number on my old grille?
The Ford part number is typically molded into the plastic on the back side of the grille. It will likely start with a prefix like 'F1WB' or 'F1WY'.
Helpful Videos
Technical Specifications
OEM Part Numbers: F1WY8200D (LS Chrome Grille) F1WY8200E (XR7 Grille) F1WB-B200-BDW (XR7 Grille)
Material: Plastic with chrome plating (LS) or paint finish (XR7)
