2013-2022 Range Rover L405 Grille: A Buyer's Guide to Facelifts, Trims, and Fitment
This guide details the critical compatibility differences between model years and trim levels for the 2013-2022 Land Rover Range Rover (L405) front grille.
- Crucially verify year compatibility: grilles for pre-facelift (2013-2017) and facelift (2018-2022) models are not interchangeable.
- Confirm trim level: Grilles for standard models do NOT fit SV, SVO, or SVAutobiography trims, and vice-versa.
- For 2022 models, ensure the part is for the L405 'Classic' body style, not the redesigned L460.
- When buying a used grille, the most important inspection is to check that all plastic mounting tabs on the back are intact.
Critical Compatibility Warnings: Read This Before Buying
The most common mistake when buying a grille for a 2013-2022 Range Rover is purchasing one that does not fit. There are three major compatibility traps to be aware of. Always verify the year and trim of the donor vehicle before purchasing a used part.
1. Pre-Facelift (2013-2017) vs. Facelift (2018-2022)
Warning: Grilles from 2013-2017 models are NOT interchangeable with grilles from 2018-2022 models. The facelift in 2018 introduced new headlights and a new front bumper, which changed the shape and mounting points of the grille. While many aftermarket companies sell '2018-style' grilles designed to fit the older 2013-2017 models, an original OEM grille from a 2018+ vehicle will not fit a 2013-2017 vehicle without an expensive and complex front-end conversion.
2. Standard vs. SV, SVO, and SVAutobiography Trims
Special Vehicle Operations (SVO) models, including SV and SVAutobiography, feature a unique, more aggressive grille design. These grilles have a different mesh pattern and are shaped to fit the exclusive SVO front bumper. A grille from a standard, HSE, or Vogue model will NOT fit an SV, SVO, or SVAutobiography model, and vice-versa.
3. The 2022 Model Year Split: L405 'Classic' vs. L460 'New Style'
For the 2022 model year, Land Rover sold two different Range Rovers simultaneously. The outgoing L405 body style (often referred to as the 'Classic') and the all-new, redesigned L460 model. The grilles for these two vehicles are completely different and in no way compatible. This guide exclusively covers the L405 generation grille, which includes the 2022 'Classic' models.
Symptoms of a Bad or Failing Grille
Failure of a grille is almost always due to physical or cosmetic damage rather than mechanical breakdown.
- Physical Damage: Cracks in the frame, broken mesh, or shattered pieces from a front-end collision or impact with road debris are the most obvious signs of failure.
- Broken Mounting Tabs: The grille is secured by several plastic tabs and clips. If these break, the grille can become loose, rattle while driving, or sit unevenly in the bumper opening.
- Cosmetic Finish Failure: Over time, the finish can degrade. Common issues include peeling chrome, bubbling paint, or a 'scabbing' look on the silver or grey painted surfaces. This is often caused by harsh cleaning chemicals or road salt.
- Front Camera or Sensor Faults: While the grille itself is not electronic, it may house the front-view camera or provide a clear line of sight for the Adaptive Cruise Control (ACC) radar sensor. Damage or an improper fit can block or misalign these systems, causing warning messages on the dashboard.
Pro Tip: Behind the main grille is a separate component called the Active Grille Shutter assembly. If you see a Check Engine Light with codes like P05A0 or P059F, or notice the engine overheating in traffic, the issue is likely with the shutter system, not the cosmetic grille itself.
Buying a Used Grille: What to Inspect
A used OEM grille is often a better choice than a cheap aftermarket alternative due to superior fit, finish, and material durability. However, careful inspection is key.
- Check Every Mounting Tab: This is the most critical inspection point. Lay the grille on a flat surface and carefully check every single mounting point and clip receiver around the perimeter. Even one broken tab can lead to a poor fit, gaps, or rattling.
- Inspect the Frame for Cracks: Look for hairline cracks, especially around the mounting points and corners where stress is highest. A cracked frame will not be secure.
- Examine the Finish: Check for deep scratches, peeling paint, or chemical staining. Some minor delamination on the lower edges is common, but widespread peeling means the part will need to be repainted.
- Verify Camera/Sensor Mounts: If your vehicle has a front camera, ensure the mounting bracket on the grille is intact and not damaged.
- Confirm the Part Number: If possible, match the part number on the back of the used grille to your original part to guarantee correct fitment for your specific year and trim.
Replacement Overview
Replacing the front grille on the L405 Range Rover is a straightforward job suitable for a DIYer with basic tools.
🎬 Watch this quick walkthrough of the 2017 grille replacement process.- Difficulty: 1 out of 5
- Estimated Time: 15-20 minutes
- Tools Needed: Flathead screwdriver, plastic trim removal tool.
Basic Steps:
- Open the hood.
- Locate the four plastic fasteners/clips along the top edge of the grille.
- Use a screwdriver or trim tool to carefully pry up the center pin of each fastener, then remove the entire fastener.
- With the top fasteners removed, gently but firmly pull the grille straight forward. It is held in at the bottom by two locating lugs that will pop out of their grommets.
- To install the new grille, align the bottom lugs and push them into place, then reinstall the four fasteners at the top.
Cost Comparison
| Part Type | Estimated Price Range |
|---|---|
| New OEM | $600 - $800+ |
| New Aftermarket | $100 - $250 |
| Used OEM | $50 - $350 |
| Shop Labor | $75 - $150 |
OEM Part Numbers
This list contains known OEM part numbers for the 2013-2022 Range Rover L405 grille. Note that different finishes (e.g., Atlas Grey, Gloss Black) and model years will have different part numbers. Always verify compatibility with a VIN. Some numbers may supersede others.
- CK52BA163
- GK52-8200-AA
- JK52-8200-CD
- LR034245
- LR034246
- LR046748
- LR046749
- LR055879
- LR055880
- LR077427
- LR077428
- LR098082
- LR098084
Frequently Asked Questions (FAQ)
Can I install a 2018+ facelift grille on my 2014 Range Rover?
No, not without extensive modification. An OEM 2018+ grille requires the corresponding 2018+ front bumper and headlights to fit correctly. However, several aftermarket companies make grilles in the '2018 style' that are designed to be a direct fit for the 2013-2017 models.
Will a grille from an SVAutobiography model fit my standard Range Rover?
No. The SV, SVO, and SVAutobiography models use a unique grille and front bumper design. The parts are not interchangeable with standard models.
My grille is loose and rattles. What is the cause?
The most likely cause is one or more broken mounting tabs or clips. The grille is held in by four fasteners at the top and two locating pins at the bottom. If any of these attachment points are broken, the grille will not be secure.
Are there any recalls for the Range Rover grille?
No, there are no known safety recalls or technical service bulletins (TSBs) issued by Land Rover for the cosmetic front grille on 2013-2022 Range Rover models.
Helpful Videos
Technical Specifications
OEM Part Numbers: CK52BA163 GK52-8200-AA JK52-8200-CD LR034245 LR034246 LR046748 LR046749 LR055879 LR055880 LR077427 LR077428 LR098082 LR098084
Material: Primarily ABS plastic. Finishes vary by trim and year, including Atlas Grey, Gloss Black, and Chrome.
