2019-2021 Genesis G70 Glove Box: Diagnosing Rattles, Latches, and Replacement
A complete guide to fixing common Genesis G70 glove box problems and choosing a quality used replacement assembly.
- The most common failures are physical: rattling, a broken soft-open damper, and latch/handle issues.
- When buying a used part, it is essential to match the color code (e.g., NNB for Black) to your car's interior.
- Replacement is a simple DIY task, rated 1/5 difficulty, and can be done in under 30 minutes with basic tools.
- There are no recalls for the glove box, but a critical fire-risk recall exists for the ABS module on all 2019-2021 G70s that owners must address.
Symptoms of a Failing Glove Box Assembly
Failures in the G70's glove box are typically mechanical and related to its moving parts. Here are the most common symptoms to watch for.
1. Rattling or Buzzing Noises
One of the most frequent complaints for the G70 involves interior rattles. If you hear a persistent buzzing or rattling from the passenger side of the dashboard, the glove box is a primary suspect. This can be caused by a poor fit against the dashboard, worn rubber bumpers, a loose latch, or items vibrating inside the compartment. Sometimes, applying felt tape to contact points can resolve minor rattles.
🎬 Watch: Diagnose dashboard and glove box rattles2. Glove Box Door Slams Open
The G70 glove box is equipped with a small damper arm that allows the door to open slowly and smoothly. This damper is a common failure point. If your glove box door drops or slams open when you unlatch it, the damper has likely failed or become disconnected. This component is typically integrated into the main glove box housing and is not sold separately, meaning the entire assembly often needs to be replaced.
3. Latch Failure: Won't Close or Stay Shut
A broken latch mechanism will prevent the glove box door from staying closed. You may find that the door pops open on its own, especially when driving over bumps. In other cases, the handle may feel loose or fail to spring back to its flush position after being used, which can indicate a broken internal spring. This not only looks untidy but can be a distraction while driving.
4. Loose or Fallen Lock Cylinder
Some owners have reported the lock cylinder on the latch becoming loose or falling out completely. While it can sometimes be pushed back into place, it may not sit flush or function correctly. The physical key to operate this lock is typically hidden inside the smart key fob.
Vehicle Safety Recall Notice: While there are no recalls for the glove box itself, the 2019-2021 Genesis G70 is under a critical safety recall for its Anti-Lock Brake System (ABS) module. This module can short circuit and cause an engine compartment fire, even when the vehicle is parked and turned off. Owners are strongly advised to park their vehicles outside and away from structures until this free recall repair has been performed by a dealer.
Buying a Used Glove Box Assembly: What to Check
A used OEM glove box is an excellent, cost-effective alternative to a new part, as aftermarket options are generally not available. However, careful inspection is key to getting a quality part.
- Verify the Color and Trim: This is the most critical step. Genesis offered different interior colors. Part numbers for the glove box assembly end in a code that specifies the color, such as NNB for Black. Always confirm the part's color matches your vehicle's interior before purchasing. An eBay listing for part number 84510G9000RJS described it as grey.
- Inspect the Outer Door Surface: Carefully examine photos for any deep scratches, scuffs, or discoloration on the front face of the glove box door. The textured soft-touch surface is difficult to repair, so cosmetic condition is paramount.
- Check the Latch and Handle: Ask the seller to confirm that the latch clicks shut securely and that the handle operates smoothly and returns to its resting position.
- Confirm the Damper Works: The damper is the small arm on the side of the glove box. If possible, ask the seller to verify that it provides resistance, which indicates it will allow the door to open slowly. A freely moving arm means the damper is broken.
- Examine Hinges and Mounting Points: Look for any cracks or stress marks in the plastic around the lower hinge pins and the upper screw mounting points. Damaged mounting points will result in a poor fit and potential rattles.
Pro Tip: Many recycled parts sellers list the Vehicle Identification Number (VIN) of the donor car. You can use a VIN decoder to confirm the original interior color and trim level to ensure a perfect match.
Cost Comparison for a 2019-2021 G70 Glove Box Assembly
The price can vary based on color and condition. Here is a general cost estimate:
| Part Type | Estimated Cost |
|---|---|
| New OEM | $235 - $335 |
| New Aftermarket | Not Generally Available |
| Used OEM | $100 - $175 |
| Shop Labor | $60 - $120 |
Installation Guide
Replacing the glove box assembly is a straightforward job that most DIY mechanics can complete in under an hour. The process is also necessary for accessing the cabin air filter and HVAC blower motor.
🎬 See how to access this area step-by-stepDifficulty: 1 out of 5 (Very Easy)
Estimated Time: 20-30 minutes
Tools Needed:
- Phillips head screwdriver
- Trim removal tool (optional, but helpful)
Step-by-Step Instructions:
- Empty the Glove Box: Remove all contents.
- Detach the Damper Arm: Open the glove box. On the right side, you will see a small damper arm connected to the side of the assembly. Gently unhook it from its mounting pin.
- Remove the Stops: With the damper detached, push in on both sides of the glove box housing to clear the rubber stops. This will allow the door to swing down completely, providing access to the hinges and mounting screws.
- Disconnect the Light: Locate the electrical connector for the glove box light and disconnect it.
- Remove Mounting Screws: You will now see several Phillips head screws along the top and bottom (hinge area) of the glove box assembly that secure it to the dashboard. Remove all of them.
- Remove the Assembly: With all screws removed, the entire glove box assembly can be carefully pulled straight out of the dashboard.
- Install the New Assembly: Installation is the reverse of removal. Position the new assembly, start all the screws by hand to ensure alignment, then tighten them. Reconnect the light, swing the door up past the stops, and re-attach the damper arm.
Frequently Asked Questions (FAQ)
Can I just replace the broken latch or damper instead of the whole glove box?
Generally, no. The latch, handle, and damper mechanism are typically integrated into the glove box door and housing. These small components are not sold separately by Genesis, so a complete assembly is usually required for the repair.
My glove box rattles. How can I fix it without replacing it?
For minor rattles, you can try lining the contact points where the door meets the dash with thin, self-adhesive felt tape. Also, check that the rubber bumpers are in place and that the latch is engaging securely. Sometimes, simply ensuring the glove box is not overfilled can solve the problem.
How do I find the correct color-matched glove box for my G70?
The best way is to use the part number from your original glove box if possible. Alternatively, you can contact a Genesis dealership parts department with your VIN, and they can provide the correct part number for your specific interior color. When buying used, look for part numbers ending in specific codes like 'NNB' for black and visually compare the part to your interior.
Is there a TSB for the glove box on the 2019-2021 G70?
No, there are no official Technical Service Bulletins (TSBs) or recalls specifically for the glove box assembly itself. However, there is a TSB for the 2019 G70 concerning the HVAC blower motor wiring, which is located behind the glove box. There is also a major safety recall for the ABS module on these vehicles.
Helpful Videos
Technical Specifications
OEM Part Numbers: 84510-G9000-NNB (Black) 84510-G9000-RJS (Grey) 84510G9000NNB 84510G9000RJS
The assembly includes the main box, the outer door, the latch mechanism, and the soft-opening damper. It is secured by several Phillips head screws.
