2013-2021 Nissan NV200 Fuse Box: Solving Electrical Problems and No-Start Issues
This guide covers common failures, recalls, and replacement specifics for the underhood fuse box in your Nissan NV200, including whether it needs programming.
- The underhood fuse box (IPDM) on the 2013-2021 NV200 does NOT require programming, making a used replacement a viable DIY-friendly option.
- A 'crank no-start' condition is a primary symptom of a failing IPDM, often due to an internal fuel pump relay failure.
- A major recall (NHTSA #25V676) exists for a wiring issue that can blow the fuel pump fuse and cause stalling; check if this applies to your vehicle before replacing parts.
- When buying a used unit, you must match the part number exactly and transfer all fuses and relays from your old box to the new one.
Symptoms of a Failing NV200 Fuse Box (IPDM)
A failing Intelligent Power Distribution Module (IPDM) can cause a wide range of confusing electrical problems. Because it controls so many different components, symptoms can seem random and unrelated. Here are some of the most common signs that your NV200's IPDM may be failing:
- Engine cranks but will not start: This is one of the most frequent symptoms. The IPDM contains the relay for the fuel pump. If this internal relay fails, the fuel pump won't receive power, and the engine will crank without ever starting.
- Complete loss of electrical power / No crank: In some cases, a major failure within the IPDM or its main fusible links can lead to a total loss of power, mimicking a dead battery. 🎬 Watch this walkthrough on solving a no-start electrical issue. The vehicle may not crank at all, and interior lights or accessories won't work.
- Intermittent stalling: The engine may stall unexpectedly while driving if the IPDM intermittently cuts power to the fuel pump or ignition system. This can be related to a recall issue where a wiring harness shorts out the fuel pump fuse.
- Malfunctioning lights or accessories: You might notice headlights, wipers, or the horn not working correctly. For example, headlights might not turn on, or the cooling fans might run constantly at full speed even when the engine is cold.
- Multiple, unrelated warning lights: A failing IPDM can cause communication errors across the vehicle's network, leading to various warning lights appearing on the dashboard.
- Clicking or buzzing noises: You may hear unusual clicking sounds from the fuse box area as internal relays attempt to activate but fail.
Known Issues, Recalls, and Technical Service Bulletins (TSBs)
There are a few key issues related to the electrical system and fuse box on the 2013-2021 NV200 that owners should be aware of.
Recalls
- NHTSA Recall No. 25V676 (Nissan ID PMA56): This major recall affects 2013-2021 NV200 vans. The Fuel Tank Temperature (FTT) sensor harness may have been routed incorrectly, causing it to rub, short circuit, and blow the fuel pump fuse. This can cause the engine to stall, increasing the risk of a crash. Dealers will inspect and reroute the harness or replace the fuel pump assembly free of charge. 🎬 Watch this video for more details on the fuel pump recall.
- NHTSA Recall (2013 Models): An earlier recall for some 2013 NV200s involved the wiring harness that connects the fusible link to the battery fuse terminal. The harness could wear through, short circuit, and blow the main fuse, causing the engine to stall.
Technical Service Bulletins (TSBs)
Nissan has issued several TSBs related to electrical issues, though not all point directly to IPDM failure. TSBs like NTB13-107G address situations where the vehicle key is not detected and the engine won't start, which can sometimes be misdiagnosed as an IPDM problem. Other TSBs cover fuel gauge inaccuracies and EVAP system DTCs. It's important to rule out these other potential causes before condemning the fuse box.
Pro Tip: Before replacing the IPDM for a no-start condition, check for the recalls mentioned above. Also, perform the IPDM's self-test. To do this, turn the ignition on (engine off), then press and release the driver's door switch 10 times within 10 seconds. Turn the ignition off, then on again. The horn should honk, and the IPDM will cycle various components like the wipers, lights, and fans, confirming if the module can command them to work.
🎬 See a demonstration of how to perform this IPDM self-test.Does the NV200 Fuse Box Need to Be Programmed?
No, the underhood fuse box (IPDM) on the 2013-2021 Nissan NV200 does not require any programming or flashing after installation. It is a plug-and-play component. This is a major advantage for DIY mechanics and buyers of used parts, as it means no expensive trip to the dealership is required for software configuration. You can swap a compatible used unit, and the vehicle will function correctly.
Buying a Used 2013-2021 NV200 Fuse Box
Buying a used OEM fuse box is a cost-effective way to solve electrical issues, especially since new units can be pricey and programming isn't a concern. Here’s what to look for:
- Match the Part Number: This is the most critical step. While the fuse boxes look similar, there can be internal differences. Check the part number on your original unit and match it exactly. Known part numbers include 24381C9900, 243823LM0A, and 243873LM3A, which may refer to the main housing, cover, or bracket assembly. Always confirm the number on the main assembly itself.
- Inspect for Corrosion: Carefully examine the connectors and terminals for any signs of green or white corrosion. Water intrusion is a common cause of IPDM failure, so any corrosion is a major red flag.
- Check for Physical Damage: Look for melted plastic around the fuse or relay sockets, cracked housing, or broken connector tabs. This indicates a previous short circuit or rough handling.
- Transfer Your Fuses and Relays: Used fuse boxes are almost always sold as a bare housing. You will need to carefully remove all the fuses and relays from your old fuse box and install them into the replacement unit. Take a clear photo of your original fuse box before you start to ensure everything goes back in the correct spot.
Cost to Replace an NV200 Fuse Box
The cost can vary significantly depending on whether you buy new or used and if you do the work yourself.
| Part Type | Estimated Cost |
|---|---|
| New OEM | $200 - $350+ (for individual components like the bracket or housing) |
| New Aftermarket | Not commonly available |
| Used OEM | $100 - $200 |
| Shop Labor | $100 - $200 |
Frequently Asked Questions (FAQ)
Can a bad fuse box cause a Nissan NV200 to not start?
Yes, absolutely. This is one of the most common symptoms. The fuse box (IPDM) controls the fuel pump relay. If the relay or its internal circuit fails, the engine will crank but will not get fuel, resulting in a no-start condition.
Is the fuse box the same as the IPDM on an NV200?
Yes. While it looks like a traditional fuse box, the underhood unit on the NV200 is an Intelligent Power Distribution Module (IPDM). It's an active electronic module that controls power distribution, rather than just passively holding fuses.
Do I need to visit the dealer after replacing the fuse box?
No. The IPDM for the 2013-2021 Nissan NV200 is a plug-and-play part and does not require any programming or dealer intervention after replacement. You will, however, need to transfer your old fuses and relays to the new unit.
Where is the fuse box located on a 2013-2021 Nissan NV200?
The main underhood fuse box (IPDM) is located in the engine compartment, typically on the driver's side near the battery. There is also a secondary interior fuse panel, usually located inside the cabin to the left of the steering column.
Helpful Videos
Technical Specifications
OEM Part Numbers: 24381C9900 243823LM0A 243873LM3A
Intelligent Power Distribution Module (IPDM) with integrated relays and control logic.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
