2009-2013 Subaru Forester Front End Damage: A Guide to Parts and Swaps

Assessing Damage After a Collision

The most common reason for replacing a front end assembly is collision damage. Even a minor impact can damage multiple components, making a complete used assembly a cost-effective solution. After an accident, it's crucial to look beyond the visible cosmetic damage to identify all broken parts.

• Bumper Cover: Check for cracks, deep gouges, and broken mounting tabs, especially where the bumper meets the fenders. Modern bumper covers are designed to flex, but can hide underlying damage.
• Reinforcement Bar: This is the heavy steel beam behind the plastic cover. Look for any signs of bending, kinking, or rust. A compromised reinforcement bar will not protect you properly in a future collision.
• Energy Absorber: This is a large piece of foam or plastic honeycomb between the cover and the reinforcement bar. It's a one-time use part; if it's compressed or cracked, it needs to be replaced.
• Headlights: Inspect the lenses for cracks, but more importantly, check all the plastic mounting tabs. It's very common for these tabs to snap off, causing the headlight to become loose.
• Radiator Support: This is the frame that the radiator, condenser, and headlights mount to. Look for cracks (if plastic) or bends (if metal). A bent radiator support will make it impossible to align the hood, fenders, and bumper correctly.
• Fenders and Hood: Check for bends, creases, and alignment issues. A gap that is wider at one end than the other between the hood and fender indicates a potential shift in the underlying structure.

Key Variations and Compatibility (2009-2013)

Not all front end assemblies for the 2009-2013 Forester are the same. Sourcing the wrong one is a common and costly mistake. The two main factors to consider are the vehicle's submodel (Turbo vs. Non-Turbo) and the model year.

Turbo (XT) vs. Non-Turbo (X, Premium, Limited)

The most significant difference is between the turbocharged XT models and the naturally aspirated versions.

• Hood: The Forester XT has a prominent hood scoop to feed air to the intercooler. The non-turbo models have a standard, flat hood. A hood from an XT will not fit correctly on a non-turbo model without modification, and vice-versa.
• Brakes: Forester XT models are equipped with larger front brakes than non-turbo models. While this doesn't affect the body panels, it's a crucial distinction when sourcing other front-end mechanical parts.
• Bumper: While the primary bumper cover part number (57704SC000) is often listed for all trims, there can be subtle differences in the lower grille texture or design. Always verify fog light provisions match your vehicle.

Model Year Changes (2011 Facelift)

The Subaru Forester received a minor facelift for the 2011 model year, which ran through 2013. This primarily affected the front grille design. While the core bumper and fenders remained the same, using a 2009-2010 grille on a 2011-2013 model (or vice-versa) will result in a mismatched look. For a perfect factory appearance, it's best to source an assembly from the correct year range (2009-2010 or 2011-2013).

Buying a Used Front End Assembly: Inspection Checklist

Purchasing a used OEM assembly is an excellent way to save money while retaining factory fit and quality, which is often superior to new aftermarket parts. Here’s what to inspect before you buy:

1. Verify the Source Vehicle: Get the VIN of the donor car. Confirm its model year and trim level (XT, X, etc.) to ensure compatibility with your Forester.
2. Check for Hidden Repairs: Look at the back of the bumper cover and fenders. Signs of plastic welding (melted/discolored areas) or thick body filler indicate a previous repair that may not last.
3. Inspect All Mounting Points: Carefully check every tab, clip-point, and bolt-hole on the bumper, grille, and especially the headlights. Broken tabs are a major red flag and often difficult to repair properly.
4. Examine the Reinforcement Bar: Do not accept an assembly with a bent or damaged steel reinforcement bar. This is a critical safety component.
5. Headlight Lens Condition: Check for yellowing, hazing, or deep scratches on the headlight lenses. While minor hazing can sometimes be polished out, heavy oxidation may require professional restoration or replacement.
6. Completeness: A 'complete' assembly should include the bumper cover, reinforcement, energy absorber, grille, and headlights. Confirm if smaller items like fog lights, tow hook covers, and side brackets are included. Getting these small parts separately can be a hassle.
7. Paint Condition: While a perfect color match is rare, look for an assembly with good paint that can either be used as-is or easily prepped for a new paint job. OEM bumpers come unprimed from the dealer, requiring full prep work.

Known Issues, Recalls, and TSBs

While the front end assembly itself is generally robust, there are some related issues and recalls for the 2009-2013 Forester platform.

• Recall WRJ-22 (NHTSA 22V838000): Affects 2009-2013 Foresters. The front seat belt assembly force-limiter may not operate correctly, increasing injury risk in a crash. Dealers will inspect and replace the assembly if needed.
• Takata Airbag Recalls: Multiple, urgent recalls were issued for the passenger-side frontal airbag inflator, which can rupture and cause serious injury or death. It is critical to ensure this recall has been performed. Do not allow passengers in the front seat until the repair is complete.
• Secondary Air Injection Pump Relay: On turbocharged (XT) models, a faulty relay can cause the pump to run continuously and overheat, creating a fire risk.
• Cosmetic Strut Mount Rust: A Technical Service Bulletin (TSB) was issued for surface rust on the front strut mounts in the engine bay. While Subaru states this is cosmetic and doesn't affect performance, it can be an eyesore. An updated strut mount cap (Part No. 20326FL001) was released to improve sealing.
• Wiring Harness Connector Corrosion: A TSB notes that moisture brought in by occupants' feet can cause corrosion in wiring harness connectors in the footwell area, leading to various electrical issues.

Cost of Replacement Parts (2009-2013 Forester)

Prices can vary based on location, supplier, and part condition. This table provides an estimated range.
