2014-2016 BMW S1000RR Foot Peg Set: Damage Inspection and Replacement Guide
Your complete guide to inspecting, identifying, and replacing damaged or broken OEM foot peg assemblies on the K46 generation S1000RR.
- Replacement is almost always due to crash/tip-over damage, not from normal wear and tear.
- The left (shifter) and right (brake) side mounting brackets are different parts; verify OEM part numbers 46717728307 (Left) and 46717728308 (Right) before buying.
- When buying used, the most critical inspection is checking for hairline cracks and ensuring the bracket is not bent by testing it on a flat surface.
- Never try to repair a bent or cracked aluminum bracket; it must be replaced to ensure safety.
Primary Causes for Replacement
Unlike many other vehicle parts that wear out over time, the foot peg assemblies on an S1000RR are almost exclusively replaced due to physical damage. The most common cause is a low-side crash or even a simple stationary tip-over. Because the footpegs stick out from the side of the motorcycle, they are one of the first parts to make contact with the ground. This can cause the peg to bend or snap, or more significantly, bend or crack the main mounting bracket (the footrest plate).
Symptoms of a Damaged Foot Peg Set
Diagnosing a faulty foot peg set is usually a straightforward visual inspection. There are no associated fault codes or electronic symptoms.
- Visible Damage: This is the most obvious symptom. Look for bent or cracked aluminum on the main bracket, a scraped or broken footpeg, and damage to the heel guard.
- Loose or Wobbly Feeling: A footpeg that feels loose under your boot can indicate a worn pivot or, more seriously, a cracked mounting bracket.
- Difficulty with Controls: On the left side, a bent bracket can cause the gear shift lever to bind or have excessive play, leading to missed shifts. On the right side, it can affect the feel and travel of the rear brake pedal.
- Improper Fitment: If a previous owner dropped the bike, the bracket may be slightly bent, causing it to sit at an odd angle or making it difficult to align the mounting bolts with the frame.
Warning: Never attempt to straighten a bent or cracked aluminum footrest plate. Aluminum weakens significantly when bent and can fail without warning if straightened and put back into service. A cracked bracket must be replaced immediately.
Known Issues, Recalls, and TSBs
For the 2014-2016 model years, there are no specific recalls or Technical Service Bulletins (TSBs) from BMW or the NHTSA related to the foot peg assemblies themselves. The primary issues are related to crash damage. Some owners on forums have noted that the stock footpegs can get uncomfortably hot from engine heat, but this is a design characteristic rather than a failure.
A recall (NHTSA Campaign Number: 16V948000) was issued for some 2016-2017 S1000RR models for a bolt on the rear suspension deflection lever that could loosen, but this is unrelated to the foot peg assembly. Another recall for 2011-2014 models concerned a fuel pump flange leak (NHTSA 21V-060).
Buying a Used Foot Peg Set: What to Check
A used OEM foot peg assembly is an excellent, cost-effective replacement for a damaged unit. Because they don't wear out, a non-damaged used part is as good as a new one. However, careful inspection is critical.
- Check for Cracks: Meticulously inspect the entire bracket, especially around the two main mounting holes and where the footpeg itself attaches. Hairline cracks can be hard to see, so clean the part and inspect it in good light.
- Verify Flatness: Lay the bracket on a known flat surface (like a piece of glass or a workbench). It should sit perfectly flat with no rocking. Any wobble indicates it has been bent in a crash.
- Inspect the Peg Pivot: If the footpeg is included, check its pivot. It should fold and unfold smoothly without excessive side-to-side play.
- Examine Lever Pivots: The mounting points for the brake or shift lever should be perfectly round and free of damage.
- Confirm Part Numbers: The left and right sides are different parts. Ensure you are buying the correct side for your needs.
Identifying the Correct Part Number
The main mounting brackets, or footrest plates, are side-specific. Do not assume they are interchangeable. The provided OEM part number 7728308 is an incomplete number.
| Position | Part Name | BMW Part Number |
|---|---|---|
| Right (Brake Side) | Footpeg Plate, Right | 46717728308 |
| Left (Shifter Side) | Footrest plate, left | 46717728307 |
Individual components like the peg itself, heel guard, and levers have their own separate part numbers.
Cost Comparison for S1000RR Foot Peg Assemblies
Prices can vary, but this provides a general expectation for a single side assembly (bracket).
| Part Type | Estimated Cost (Per Side) | Notes |
|---|---|---|
| New OEM | $320 - $420 | Highest cost, but guaranteed fit and finish. |
| Used OEM | $75 - $150 | Excellent value. Inspect carefully for damage as outlined above. |
| New Aftermarket (Full Rearset Kit) | $400 - $900+ | Often sold as a complete kit for both sides. Offers adjustability for track use but may increase vibration. Brands include Vortex, Bonamici, Attack Performance. | 🎬 See this aftermarket rearset installation walkthrough
| Shop Labor | $75 - $150 | Typically 0.5-1.0 hour of labor per side. |
Replacement Overview & Difficulty
Replacing a foot peg assembly is a relatively simple task for a DIY mechanic.
- Difficulty: 2 out of 5
- Tools Required: Torx bit set (T30, T40, T45), torque wrench.
- Procedure: The main bracket is held to the frame by two large Torx bolts. Before removing them, you must first disconnect the brake light switch and the brake or shift linkage from the assembly. When reinstalling, it's crucial to use a thread-locking compound and tighten the bolts to the correct torque specification.
Pro Tip: The two main mounting bolts (Part No. M8X25-10.9-SI) should be torqued to 20 Nm (approximately 15 ft-lbs). Always clean the old thread locker from the frame threads before installing the new bolts.
Frequently Asked Questions (FAQ)
Can I install aftermarket footpegs on the OEM bracket?
Yes, many companies sell just the footpeg which can be mounted to the stock BMW footrest plate. However, if you want to change the peg's position (lower, higher, or further back), you will need a full adjustable aftermarket rearset kit.
What is the difference between a 'road' and 'race' shift pattern?
A standard 'road' shift pattern is one down, five up. A 'race' or 'GP' shift pattern is the reverse: one up, five down. Many aftermarket rearsets allow you to switch between the two. The OEM setup is for road shift only.
Do I need to bleed my brakes to replace the right-side footrest plate?
No. You can typically unbolt the rear brake master cylinder from the footrest plate and hang it to the side without disconnecting the hydraulic line. This avoids the need to bleed the brake system.
Are the passenger footpegs the same as the rider pegs?
No, the passenger foot peg assemblies are completely different parts and mount to the subframe. They are often removed by owners for weight savings and a cleaner look.
🎬 Watch: How to remove the passenger foot pegsHelpful Videos
Technical Specifications
OEM Part Numbers: 46717728308 (Footpeg Plate, Right) 46717728307 (Footrest plate, left)
Mounting Bolt Torque: 20 Nm (15 ft-lbs)
