2012-2015 Range Rover Evoque Wheel Arch Moulding: Fading, Clips & Part Number Guide
Your definitive guide to identifying common wheel arch moulding problems, avoiding facelift incompatibility, and choosing a quality used replacement for your Evoque.
- Compatibility is critical: These mouldings only fit 2012-2015 pre-facelift Evoque models and will not fit 2016 or newer vehicles.
- When buying used, the most important check is the condition of the mounting tabs on the back of the part; broken tabs will prevent a secure fit.
- Always plan to replace the plastic mounting clips (Part No. LR027255) during installation, as old clips are brittle and likely to break.
- Verify if your vehicle has the optional park assist system, which requires a front moulding with a hole for the sensor.
Symptoms of a Failing Wheel Arch Moulding
Failure of a wheel arch moulding is almost always a visual or audible issue. Because it is a cosmetic and protective part, problems are typically easy to spot and are caused by impacts, long-term sun exposure, or broken mounting hardware.
Loose or Rattling Moulding
The most common symptom is looseness, which can produce a rattling or vibrating noise from a corner of the vehicle, especially at higher speeds. This is usually caused by broken, missing, or degraded plastic mounting clips that can no longer hold the moulding securely against the body. You may see a visible gap between the trim and the vehicle's body, indicating that the clips have failed.
Fading and Discoloration
The original black plastic mouldings are susceptible to fading from prolonged exposure to UV rays. This can cause the trim to turn from a deep black to a chalky, light gray color. In some cases, this can appear as blotchy or striped discoloration, sometimes called "tiger striping." While this is primarily a cosmetic issue, it can make an otherwise well-kept Evoque look aged.
Cracks and Physical Damage
Impacts from shopping carts, other car doors, or road debris can cause the plastic moulding to crack, scuff, or break. While the moulding is designed to absorb these minor impacts to protect the metal fender, the damage can be unsightly and may compromise the part's structural integrity, leading to looseness.
Part Number Confusion: The OEM part number BJ32-16C628 does NOT refer to the wheel arch moulding. It is the part number for the fender side vent grille. This article focuses on the more commonly replaced wheel arch mouldings. Ensure you are ordering the correct part for your needs.
Key Compatibility Warnings for 2012-2015 Evoque
Buying the correct moulding for your Evoque requires careful attention to the model year and optional features.
Pre-Facelift vs. Facelift Models
Warning: The wheel arch mouldings for 2012-2015 Evoque models are NOT compatible with the facelifted 2016-2019 models or the second-generation 2020+ models. The body panels and mounting points are different. You must purchase a part specified for the 2012-2015 year range.
Parking Sensor Variations
Some Evoque models were equipped with an automated or perpendicular park assist system, which includes an extra parking sensor located in the front wheel arch mouldings. If your vehicle has this feature, you must buy a replacement moulding that has the corresponding sensor hole. A moulding without the hole will not work without modification.
Buying a Used 2012-2015 Evoque Wheel Arch Moulding
A used OEM moulding is often the best value, providing the same fit and quality as a new part. However, careful inspection is key to getting a good part.
What to Inspect Before You Buy
- Mounting Tabs and Clip Slots: This is the most critical inspection point. Turn the moulding over and carefully check every mounting tab and the slots where the clips slide in. If these are cracked, broken, or missing, the moulding will not attach securely to the vehicle. A part with perfect cosmetics but broken tabs is worthless.
- Check for Cracks and Warping: Inspect the entire surface for cracks, especially around the edges. Lay the part on a flat surface to ensure it is not warped or deformed from heat or a previous impact.
- Assess Fading: Check the level of UV damage. A slightly faded part can often be restored with trim detailing products, 🎬 Watch: How to restore faded plastic trim in seconds but a heavily discolored, chalky part may never return to a deep black. Compare it to your vehicle's other mouldings to ensure a close match.
- Verify Part Numbers: Whenever possible, match the part number to your original part. Front mouldings are side-specific (left vs. right). Common part numbers for models without park assist sensors include LR036053 (Front Left) and LR036051 (Front Right).
Pro Tip: Always plan on purchasing a new set of mounting clips. The original clips become brittle with age and often break during removal. Using new clips, such as part number LR027255, ensures the replacement moulding fits tightly and prevents future rattles.
Replacement Overview and Difficulty
- Difficulty: 2/5 (Straightforward)
- Estimated Time: 0.5 - 1 hour per side
- DIY Feasible: Yes
Replacing the wheel arch moulding is a job most DIYers can handle with basic tools. The process involves removing any fasteners in the wheel well liner and then carefully prying the old moulding away from the body using plastic trim removal tools to avoid scratching the paint. The new part is aligned and snapped into place by pressing firmly over each clip location.
Cost Comparison
| Part Source | Estimated Price Range (per side) |
|---|---|
| New OEM | $190 - $320 |
| New Aftermarket | $40 - $125 |
| Used OEM | $75 - $200 |
| Shop Labor | $75 - $150 |
Recalls and Technical Service Bulletins (TSBs)
As of mid-2026, there are no specific recalls or TSBs from the NHTSA related to the wheel arch mouldings on the 2012-2015 Range Rover Evoque. However, TSB SSM72167 was issued for peeling, fading, or discoloration on the front radiator grille, indicating that similar cosmetic issues with exterior trim were acknowledged by the manufacturer.
Frequently Asked Questions (FAQ)
Can I restore my faded wheel arch moulding instead of replacing it?
Yes, in many cases you can. For light to moderate fading, a quality plastic trim restorer product can bring back the black finish for several months. For a longer-lasting solution, a ceramic trim coating can be applied after a thorough cleaning, which can protect the plastic for years. 🎬 See how to easily fix faded car trim Using a heat gun is another method, but it carries a high risk of melting or damaging the plastic's texture if not done carefully.
Do I need to buy new clips for installation?
Yes, it is highly recommended. The plastic clips that hold the moulding in place (part number LR027255) become brittle over time and almost always break when the old moulding is removed. Using new clips is essential for a secure, rattle-free fit.
Will this moulding fit my 2017 Range Rover Evoque?
No. This part is only for the pre-facelift 2012-2015 models. The 2016 model year introduced a facelift with different body styling, and the mouldings are not interchangeable. You must buy a part specifically listed for the 2016-2019 model years.
Are the front and rear, or left and right, mouldings the same?
No, they are all different. Each of the four wheel arch mouldings (front left, front right, rear left, rear right) has a unique shape and part number. You must purchase the correct part for the specific corner of the vehicle you are repairing.
Helpful Videos
Technical Specifications
OEM Part Numbers: LR036051 LR036053 LR027255
Material: Polypropylene Plastic
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
