1995-2000 Cirrus, Sebring & Stratus 2.5L V6 Harmonic Balancer: Vibration, Wobble, and Replacement

Symptoms of a Failing Harmonic Balancer

When the rubber layer on the harmonic balancer starts to dry out and crack, it can no longer absorb vibrations effectively. This leads to a set of common symptoms. 🎬 Watch: 5 common signs of a bad harmonic balancer Ignoring these can lead to catastrophic failure where the outer ring separates from the hub, potentially causing extensive damage to other engine components.

• Increased Engine Vibration: You may feel a new or unusual vibration throughout the car, especially at idle or when the engine is under load. This is the most common symptom.
• Visible Wobble: With the engine running, you may be able to see the balancer and accessory belt pulleys wobbling at the front of the engine. Do not place hands or tools near the moving parts.
• Chirping or Squealing Noises: As the outer ring begins to separate or slip, it can cause the serpentine belt to misalign, resulting in a loud chirping or squealing sound.
🎬 Watch: Real example of belt squeak and pulley wobble
• Shredded Accessory Belts: A severely wobbling balancer can quickly destroy the serpentine belts, leading to a loss of power steering, alternator function (dead battery), and air conditioning.
• Timing Mark Drifting: The outer ring of the balancer has timing marks used for engine diagnostics. If the ring slips, these marks will no longer be accurate, making it difficult to set ignition timing correctly.
• Check Engine Light: In severe cases, the wobble can be detected by the crankshaft position sensor, leading to erratic readings and potentially triggering misfire codes like P0300 or a specific crankshaft position sensor code (P0335).

Known Issues for Cirrus, Sebring, and Stratus (1995-2000)

The 1995-2000 Chrysler Cirrus, 1996-2000 Chrysler Sebring, and 1995-2000 Dodge Stratus share a platform and, in this case, the Mitsubishi-designed 2.5L 6G73 V6 engine. While there are no specific NHTSA recalls or widespread Technical Service Bulletins (TSBs) for harmonic balancer failure on these models, the issue is a common point of failure due to age. The bonded rubber simply deteriorates after decades of heat cycles 🎬 See this video on fixing the discontinued Sebring V6 pulley and exposure to the elements.

Buying a Used Harmonic Balancer: What to Inspect

Because new OEM balancers are discontinued, a quality used OEM part is often a better choice than a low-quality aftermarket alternative. The original factory parts generally feature a higher quality rubber compound. Here’s what to look for when inspecting a used harmonic balancer:

1. Inspect the Rubber Ring: This is the most critical step. Look for any signs of cracking, dry rot, bulging, or missing chunks of rubber. Use a flashlight and look all the way around the circumference. Any significant deterioration means the part is no good.
2. Check for Ring Slippage: Look for witness marks, paint lines, or rust marks that show the outer ring has rotated relative to the inner hub. If the keyway on the inner hub doesn't align with the TDC (Top Dead Center) mark on the outer ring, the part has failed and is useless.
3. Examine the Keyway: The inner hub has a slot called a keyway that aligns it on the crankshaft. Inspect this slot for any signs of damage, cracking, or deformation. A damaged keyway indicates the balancer may have come loose on its previous engine.
4. Inspect the Pulley Grooves: Run your finger through the serpentine belt grooves on the outer ring. They should be smooth and free of chips, deep rust, or damage that could shred a new belt.
5. Check for Wobble or Damage: Lay the balancer on a flat surface. It should sit perfectly flat. Any signs that it has been dropped or is bent are red flags.

Replacement Overview & Difficulty

• Difficulty: 4 out of 5
• Estimated Time: 2-3 hours
• DIY Feasible: For advanced mechanics only.

Replacing the harmonic balancer on the transverse 2.5L V6 is a challenging job due to tight access. It requires supporting the engine, removing the passenger-side engine mount, and using special tools.

Key Steps & Torque Specs

1. Disconnect the battery. Remove the accessory drive belts.
2. Support the engine from below with a jack and wood block.
3. Remove the passenger-side engine mount and bracket to gain access to the front of the engine.
4. Remove the large center crankshaft bolt. This is extremely tight and may require a special holding tool to keep the engine from turning.
5. Use a proper harmonic balancer puller to remove the balancer. A standard three-jaw puller that only grabs the outer ring can cause the rubber to separate, destroying the part. Use a puller that bolts into the threaded holes in the face of the balancer.
6. Install the new balancer using an installation tool, which presses it onto the crankshaft snout without damaging the threads. Never use a hammer.
7. Reinstall the crankshaft bolt and washer. Apply clean engine oil to the bolt threads and under the washer head.
8. Torque the crankshaft bolt to 134 ft-lbs (182 Nm). Use a holding tool to prevent the engine from rotating while torquing.

Cost Comparison: New vs. Used

Labor is the most significant part of the replacement cost. Since the OEM part is discontinued, your options are aftermarket or used OEM.

Compatible Part Numbers

The primary OEM part number for this application has been discontinued but is useful for cross-reference.

• OEM (Mopar): MD324796
• Aftermarket (Dorman): 594-133, 594-186
