2017 Subaru WRX ECM: Programming, Part Numbers, and Failure Guide
This guide covers the critical programming requirements, known issues, and replacement procedures for the Engine Control Module (ECM) in the 2017 Subaru WRX.
- Programming is mandatory. A replacement ECM, new or used, will not start the car until it is programmed to the vehicle's immobilizer by a dealer or qualified shop.
- Only use an ECM from a 2017 WRX with a 2.0L engine and a manual transmission.
- Match the OEM part number exactly. The main numbers are 22765AK380 and the updated 22765AK381.
- A failing ECM can cause a wide variety of symptoms, but always check the battery and charging system first to rule out simpler issues.
Symptoms of a Failing 2017 WRX ECM
A faulty Engine Control Module can cause a wide range of issues, many of which can be mistaken for other problems. 🎬 Watch this guide on common failing ECM symptoms Always perform a thorough diagnosis before condemning the ECM.
- Check Engine Light: This is the most common symptom. A failing ECM can trigger a variety of codes, sometimes for components that aren't actually bad. Codes in the P0600-P0606 range, such as P0606 (ECM/PCM Processor Fault), are strong indicators of an internal module failure. 🎬 See how to diagnose and fix a P0606 code
- Engine Performance Issues: You might experience a loss of power, poor acceleration, rough idling, engine hesitation, or a decrease in fuel economy.
- No-Start or Stalling: The engine may crank but not start, or it might stall unexpectedly while driving. This can be a significant safety hazard.
- Multiple, Unrelated Fault Codes: A classic sign of ECM failure is when the scanner shows numerous fault codes for different sensors and systems all at once. This often points to the central computer rather than individual part failures.
- Spark Knock (Pinging): Some early 2017 models could experience a spark knock sound. Subaru issued a TSB with updated software to fix this, which involved reprogramming the ECM.
- DTC P2610 (ECM/PCM Engine Off Timer Performance): A Technical Service Bulletin (TSB) was released for this specific code, which could be caused by an electrostatic surge affecting the ECM's internal timer. The fix was a redesigned ECM.
Pro Tip: Many electrical issues on a WRX, including a dashboard with multiple warning lights, can be caused by a weak or failing battery. Always test the battery and charging system before suspecting a bad ECM.
Known Issues, TSBs, and Recalls
While there are no major recalls specifically for the 2017 WRX ECM, several Technical Service Bulletins (TSBs) and one voluntary emissions recall are relevant.
- TSB 11-176-17 (Spark Knock): Addressed customer concerns of an engine "ping" or spark knock sound. The fix was a software update for the ECM. The updated ECM part number for manual transmission models is 22765AK381.
- TSB 11-191-19R (DTC P2610): Announced a new ECM designed to fix an issue where an electrostatic surge could trigger a P2610 trouble code. The updated part for a 2017 WRX with a manual transmission is 22765AK383.
- Voluntary Emissions Recall (WRA-25): For certain 2017 WRX models, Subaru initiated a recall to replace the rear catalyst and, for manual transmission vehicles, reprogram the ECU to ensure emissions standards were met.
- Recalls: As of early 2026, there are no open recalls from the National Highway Traffic Safety Administration (NHTSA) for the ECM on the 2017 Subaru WRX. The primary recalls for this model year relate to Takata airbags.
Buying a Used 2017 WRX ECM
Purchasing a used OEM Engine Control Module is a cost-effective solution, but it requires careful attention to detail to ensure compatibility and function. A used OEM module is often a better choice than a new aftermarket unit due to guaranteed factory compatibility once programmed.
Warning: This part is NOT plug-and-play. A replacement ECM, whether new or used, must be programmed to your vehicle's VIN and immobilizer system. Failure to do so will result in a no-start condition.
- Match the Part Number: The most critical step is to match the OEM part number exactly. For the 2017 WRX with a 2.0L engine and manual transmission, the primary part numbers are 22765AK380 and 22765AK381. Part number 22765AK381 was an updated version to address spark knock issues. Both have been superseded by newer numbers like 22765AK386. Always confirm the number on your original module before purchasing a replacement.
- Verify Vehicle Specifications: This ECM is only for models with a 2.0L engine and a manual transmission. The ECM for the automatic (CVT) transmission has a different part number, such as 22765AK390 or 22765AK391.
- Physical Inspection: When you receive the used module, inspect it carefully. Look for any signs of corrosion on the casing or pins, which could indicate water damage. Ensure the connectors are clean and all pins are straight and undamaged.
- Plan for Programming: Before you buy, have a plan for programming. This is not a DIY-friendly job for most people. You will need to have the module programmed by a Subaru dealership or a qualified independent shop with the correct J2534 pass-thru tools and software. Some specialized services may offer to "clone" your original ECM's data to the replacement unit, which can make it plug-and-play.
Cost Comparison
| Part Type | Estimated Cost |
|---|---|
| New OEM | $690 - $1,025 |
| Used OEM | $150 - $300 |
| Shop Labor (Replacement & Programming) | $150 - $300 |
Frequently Asked Questions (FAQ)
Does a replacement 2017 WRX ECM need to be programmed?
Yes, absolutely. The ECM is linked to your vehicle's immobilizer system and VIN. A replacement module must be programmed by a Subaru dealer or a well-equipped independent shop using specialized tools. If you install it without programming, the car will not start.
Can I use an ECM from a WRX with an automatic transmission in my manual WRX?
No. The ECM is specific to the transmission type. The part numbers for manual and automatic (CVT) transmission models are different and they are not interchangeable. You must use an ECM from a manual transmission WRX.
Where is the ECM located on a 2017 Subaru WRX?
The ECM is located in the engine bay on the passenger side, near the firewall and under a protective cover.
🎬 Watch this complete Subaru ECU replacement tutorialCan a locksmith program a new or used Subaru ECM?
It depends on the locksmith. Some advanced automotive locksmiths have the equipment and subscriptions needed to program keys and modules, but many do not. It is more reliable to go to a Subaru dealership or a specialized Subaru repair shop. The process involves registering the new module with the car's immobilizer system.
What's the difference between part numbers 22765AK380 and 22765AK381?
Part number 22765AK381 is a software-updated version of 22765AK380. Subaru released it to address complaints of spark knock or engine pinging. While both will work, 22765AK381 or a later superseded part is preferable.
Helpful Videos
![How to Change ECU [Engine Control Unit Swap // Subaru]](https://img.youtube.com/vi/-EmwuYWWbUE/mqdefault.jpg)
Technical Specifications
OEM Part Numbers: 22765AK380 22765AK381 22765AK386
Fits 2017 Subaru WRX with 2.0L Turbo (FA20DIT) engine and 6-speed manual transmission.
