2011-12 Caliber, 200, Avenger, Compass & Patriot ECM Failure: A Diagnosis & Replacement Guide

Symptoms of a Failing ECM

A faulty ECM can cause a variety of confusing symptoms because it controls so many different engine and vehicle functions. Often, these issues can be intermittent, making diagnosis difficult. Here are 🎬 Watch: 7 common symptoms of a failing engine control module. the most common signs that the ECM in your Chrysler 200, Dodge Avenger, Dodge Caliber, Jeep Compass, or Jeep Patriot may be failing:

• Engine Stalls or Shuts Off Randomly: The engine may stall while driving or idling for no apparent reason. This is a significant safety concern.
• Crank, No Start: The engine turns over but refuses to start. This can be caused by the ECM not firing the ignition coils or fuel injectors.
• Starts and Stalls Immediately: A classic symptom of an anti-theft (SKIM) issue, often triggered by an unprogrammed ECM. The engine will start, run for about two seconds, and then shut off.
• Poor Engine Performance: You may notice a sudden drop in fuel economy, sluggish acceleration, or engine hesitation.
• Check Engine Light and Multiple Unrelated Codes: A failing ECM can trigger the Check Engine Light and store a confusing mix of trouble codes, especially communication errors (U-codes) or internal module failure codes (P06xx series).
• Erratic Transmission Shifting: Since the ECM communicates with the transmission controller, a faulty module can lead to harsh or incorrect shifting.

Known Issues, Recalls, and Service Bulletins

While there are no direct recalls for the ECM itself on these models, several major safety recalls and service campaigns exist that owners should be aware of. Many of these issues can present symptoms similar to ECM failure or require a dealer to reprogram vehicle modules.

NHTSA Recall 16V-668 (Chrysler S61) - Airbag & Seatbelt Failure

This is a critical safety recall that affects all vehicles covered in this guide. A defect in the Occupant Restraint Control (ORC) module can cause a short circuit, which may prevent the frontal airbags, side airbags, and seatbelt pretensioners from deploying in a crash. The remedy is to have a dealer replace the ORC module. This is unrelated to the ECM but is a vital repair for any owner of these vehicles.

Customer Satisfaction Notification V51 - PCM Reprogram

Chrysler issued a service campaign to reprogram the Powertrain Control Module (PCM) on certain 2011-2012 Dodge Caliber and 2011-2014 Chrysler 200/Dodge Avenger models with the 2.4L engine. This software update was intended to address unspecified performance or drivability concerns. If your vehicle never had this update performed, it may be beneficial.

Related Issue: Totally Integrated Power Module (TIPM)

Many Chrysler, Dodge, and Jeep vehicles from this era are notorious for problems with the TIPM, which is the main fuse and relay box. A faulty TIPM can cause many of the same electrical and starting issues as a bad ECM, such as a no-start condition or stalling. It's important to properly diagnose the issue, as replacing the wrong module will not solve the problem.

CRITICAL: VIN Programming and Anti-Theft (SKIM) Requirements

This is the most important part of replacing the ECM in these vehicles. The ECM is tied into the vehicle’s security system, called the Sentry Key Immobilizer Module (SKIM). The ECM, SKIM, and the transponder chip in your ignition key must all be electronically matched for the vehicle to run.

When you install a new or used ECM, it does not have your vehicle's unique Vehicle Identification Number (VIN) or security data stored in it. The SKIM system will detect this mismatch, assume the vehicle is being stolen, and activate the engine immobilizer. This is 🎬 See how the Chrysler SKIM security system works and affects programming. what causes the common "start-and-stall" symptom.

To install this ECM correctly, it must be programmed with a professional-grade scan tool. The process involves:

1. Writing your vehicle's 17-digit VIN to the replacement ECM.
2. Performing a "SKIM Relearn" or "ECU Initialization" procedure to sync the new ECM with the existing security module and keys.

This procedure can be performed by a Chrysler/Dodge/Jeep dealership or a well-equipped independent repair shop. Many mobile mechanics and locksmiths also have the necessary tools. It is not a job that can be done without these specialized tools.

Buying a Used Engine Control Module

A used OEM ECM is an excellent, cost-effective alternative to a brand-new unit, provided you take the right precautions. Here’s what to look for:

• Match the Part Number Exactly: The hardware must be identical. The primary OEM part number for these vehicles is 05150607AC. You may also see other compatible numbers like 5150607AC, 68070206AD, or P05150607AC. Verify the number on your original module before ordering.
• Consider Pre-Programmed Units: Many online sellers offer used or remanufactured ECMs that are "plug-and-play." You provide them with your VIN when you order, and they program the module before shipping it to you. This is often the easiest and most reliable option for a DIY installation.
• Physical Inspection: When buying a non-programmed unit, inspect it for physical damage. Look for corrosion on the pins, cracks in the casing, or any signs that the module has been opened, which could indicate a failed repair attempt.
• Seller Reputation: Buy from a reputable recycler or parts seller that offers a warranty. This protects you in case you receive a defective unit.

Replacement Location

The ECM is located in the engine compartment. On the Jeep Compass and Patriot, and Dodge Caliber, it is typically mounted to the firewall or on the driver's side fender well, near the battery. On the Chrysler 200 and Dodge Avenger, it is in a similar location in the engine bay. It is a silver or black metal box with three large multi-pin electrical connectors. The physical replacement is straightforward: disconnect the negative battery terminal, unplug the three connectors, and unbolt the module from its bracket.

Cost Comparison
