2016-2024 Ford Edge & Maserati Window/Lock Switch: Decoding Part Numbers & Failures
This guide covers the common failure symptoms, replacement costs, and critical compatibility details for the shared master window and door lock switch in these Ford and Maserati models.
- For the 2016 Ford Edge, you must verify the vehicle's manufacturing date; this part only fits models built on or after May 5, 2016.
- A window that goes down but not up is a classic symptom of a worn-out switch, not a bad motor.
- To diagnose, listen for a 'click' inside the door when pressing the button. No sound points to a bad switch; a click or hum points to a bad motor.
- Always match the OEM part number from your old switch exactly to ensure all features (like power-folding mirrors or auto rear windows) will work correctly.
Symptoms of a Failing Master Switch
When the master window and lock switch begins to fail, it can cause a variety of frustrating issues. Because the unit controls multiple components, symptoms can be diverse and sometimes misleading. Here are the most common signs of failure:
One or More Windows Stop Working
The most frequent symptom is when a single window, or multiple windows, become unresponsive from the master switch. You might find that the passenger window can still be operated by its own switch, but not from the driver's door. This almost always points to a fault within the master switch assembly itself.
Window Goes Down But Won't Come Up
This classic sign of switch failure is extremely common. The internal electrical contacts for the 'up' command wear out faster than the 'down' contacts, often because the window motor works harder against gravity to lift the glass. If you can lower a window but can't raise it from the same switch, the switch is the most likely culprit.
Intermittent Operation
You may need to press a button multiple times before it works. This is often caused by corrosion or wear on the internal contacts. The switch might work perfectly one day and not at all the next. This can also be affected by moisture or temperature changes.
Complete Failure of All Controls
If none of the windows, locks, or mirrors controlled by the switch are working, the problem could be the switch assembly's main power connection or a blown fuse. Before replacing the switch, it's wise to check the fuse box for the power window circuit. For the Ford Edge, these are typically located in the passenger cabin fuse box.
🎬 Watch: How to find the power window fuseDoor Locks or Mirrors Malfunction
Since the door lock and power mirror controls are integrated, their failure can also signal a problem with the master switch assembly. If the doors don't lock/unlock with the button or the mirrors won't adjust, but other functions work, the fault lies within that specific part of the switch's circuit board.
Pro Tip: Listen for a sound. When you press a window button, listen carefully at that window's door. If you hear a faint click or humming sound, the switch is likely sending power, and the problem is probably the window motor or regulator. If you hear complete silence, the switch itself (or a fuse) is the most probable cause.
Known Issues, TSBs, and Recalls
There are no major recalls or widespread Technical Service Bulletins (TSBs) related to the master window switch for the Ford Edge or the Maserati Ghibli, Levante, and Quattroporte. Failure of this part is typically due to normal wear and tear over time. However, there is a critical compatibility detail for the Ford Edge.
Ford Edge Compatibility Warning
Warning: For 2016 Ford Edge models, there was a mid-year change. This switch assembly is only compatible with vehicles manufactured on or after May 5, 2016. Additionally, Ford used different switches depending on whether the vehicle was equipped with the 'one-touch up/down' feature for the rear windows. It is absolutely essential to match the part number from your original switch before purchasing a replacement.
Buying a Used Door Lock Switch: What to Check
A used OEM switch is often a high-quality, cost-effective alternative to an expensive new dealer part or a cheap aftermarket unit that may have a poor feel and incorrect backlighting. Here’s what to inspect when buying a recycled master switch:
- Verify the Part Number: This is the most important step. Remove your existing switch panel and find the OEM part number printed on it. Match it exactly to the used part you plan to buy. This is especially critical for the 2016 Ford Edge due to the mid-year change.
- Check Button Feel: Physically press every button on the switch. They should move smoothly without sticking and provide a solid 'click' or tactile feedback. Spongy or sticky buttons are a red flag for internal wear or liquid damage.
- Inspect for Liquid Damage: Look closely at the housing and the electrical connector pins. Any signs of white or greenish chalky corrosion indicate that liquid was spilled on the switch, which can cause intermittent electrical problems.
- Match All Functions: Ensure the replacement switch has all the same buttons as your original. This includes power-folding mirrors, the correct number of window switches, and the window lock button. A switch from a lower trim level will not operate features it doesn't have a button for.
- Why Used OEM is a Good Choice: Original Equipment Manufacturer (OEM) parts are built to the automaker's standards. A used OEM switch will have the correct button texture, fit perfectly in the door panel, and the button backlighting will match the rest of your car's interior lights—details where aftermarket parts often fall short.
Replacement Difficulty
- Difficulty Rating: 1 out of 5
- Estimated Time: 15-30 minutes
- DIY Feasible: Yes
Replacing the master switch is one of the easiest interior repairs. In most cases, the switch assembly can be carefully pried up from the door panel using a plastic trim removal tool. Once lifted, you simply disconnect one or two electrical connectors, plug in the new switch, and snap the assembly back into place. 🎬 Watch: Ford Edge door window switch replacement No special tools or programming are required.
Cost Comparison
| Part Type | Estimated Cost |
|---|---|
| New OEM (Dealer) | $70 - $120 (Ford), $250+ (Maserati) |
| New Aftermarket | $30 - $80 |
| Used OEM | $40 - $90 |
| Shop Labor | $50 - $150 |
OEM Part Numbers
Always verify the part number on your specific vehicle's switch before ordering. The following are common part numbers for these models:
- Ford: GT4T-14540-BAW, GT4Z-14529-AA
- Motorcraft: SW-7924
- Maserati: 670010305, 670025406, 670097037
Frequently Asked Questions (FAQ)
Why did only the driver's window button stop working?
The driver's window switch is used far more than any other, causing its internal contacts to wear out first. It's very common for one function to fail while the others continue to work perfectly.
Do I need to reprogram the car after installing a new switch?
No, the switch itself does not require programming. However, you may need to re-initialize the 'auto up/down' feature for the windows. This is typically done by rolling the window all the way down and holding the button for a few seconds, then rolling it all the way up and holding the button again for a few seconds.
🎬 See this guide on resetting Ford auto windowsCan I use a Ford Edge switch in my Maserati Ghibli?
While the vehicles share a platform and some components, it is not recommended to swap switches between brands unless you can verify the part numbers are identical. The internal electronics, pin layouts, and communication protocols with the BCM may be different, even if the switch looks physically similar.
How can I be sure it's the switch and not the window motor?
The easiest test is to listen. If you press the switch and hear a click or a humming noise from inside the door, the switch is likely working and the motor is the problem. If you hear nothing, the switch is the most likely point of failure.
Helpful Videos
Technical Specifications
OEM Part Numbers: GT4T-14540-BAW GT4Z-14529-AA SW-7924 670010305 670025406 670097037
Driver's door master control switch for windows, locks, and mirrors.
