2000-2004 Acura RL Door Lock & Window Switch: A Buyer's and DIY Guide
Your definitive guide to diagnosing, replacing, and finding the right used master window and lock switch for your first-generation Acura RL.
- The correct part for a 2000-2004 RL is from the 35750-SZ3-A0x series; parts from 2005+ models (35750-SJA series) will not fit.
- Failure symptoms commonly include unresponsive window or door lock buttons on the driver's master switch assembly.
- Replacement is a very simple DIY job that requires no special tools and takes less than 30 minutes.
- A used OEM switch is a cost-effective and reliable option, costing significantly less than a new OEM part and often offering better fit than aftermarket alternatives.
Symptoms of a Failing Door Lock & Window Switch
When the master switch begins to fail, the symptoms are usually easy to spot. Because the unit houses multiple switches and circuits, you may experience one or more of the following issues:
- Intermittent or Inoperable Window Controls: You may find that you can't operate one or more windows from the driver's master switch. Often, the driver's window will still work, but control over passenger windows is lost. In some cases, a passenger window can be operated by its own switch but not from the driver's door. 🎬 Watch: How to diagnose a bad switch vs motor
- Unresponsive Power Door Locks: The button that locks and unlocks all doors may stop working entirely or only work intermittently. You might hear a click from a relay, but the locks themselves won't actuate.
- Failure of the 'Auto' Down Feature: The driver's window 'Auto' down function may stop working, requiring you to hold the button down to fully open the window.
- Window Lock Button Malfunction: The switch that prevents passengers from operating their windows may become stuck or unresponsive.
Pro Tip: If window problems appear after the battery has been disconnected or replaced, a simple reset procedure may be all that's needed. Go to each individual door, roll the window all the way down while holding the switch, and then roll it all the way up, continuing to hold the switch for 2-5 seconds after it closes. This often re-establishes communication with the master switch.
Buying a Used 2000-2004 RL Door Lock Switch
For a vehicle of this age, a used OEM switch is often the most practical and economical choice. New OEM switches can be expensive, and aftermarket parts may not have the same quality, fit, or feel as the original. Here’s what to look for when buying a used unit.
Part Number Verification is Critical
The first-generation Acura RL was produced until the 2004 model year. The second-generation began with the 2005 model. This is a crucial distinction for this part.
- For 2000-2004 Acura RL (Chassis Code: KA9): You need a switch from the 35750-SZ3-A0x series. Part numbers like 35750-SZ3-A01, 35750-SZ3-A02, up to 35750-SZ3-A05 are correct for this generation.
- For 2005+ Acura RL (Chassis Code: KB1): These vehicles use a completely different switch from the 35750-SJA-A0x series. These parts are not interchangeable and will not fit or work in a 2000-2004 model.
Warning: Always verify the part number on your original switch before ordering a replacement. Many online listings can be confusing. The 'SZ3' code is the key identifier for the 2000-2004 generation.
What to Inspect Before You Buy
- Check the Buttons: Ensure all buttons are physically present and have a solid, tactile click. Buttons that are loose, broken, or missing their covers are a red flag.
- Examine the Connectors: Look at the electrical connector ports on the underside of the switch. The pins should be clean, straight, and free of any green or white corrosion, which would indicate water damage.
- Verify the Trim Color: These switches came in a trim color to match the interior, typically a dark silver or charcoal. While functionally compatible, a switch from a car with a different interior color may not match your door panel perfectly.
Replacement Guide
Replacing the master window switch is a beginner-friendly job that can be done in under 30 minutes with basic tools.
- Difficulty: 1/5
- Estimated Time: 15-20 minutes
- Tools Needed: Plastic trim removal tool or a flat-head screwdriver with the tip wrapped in tape to prevent scratching.
Step-by-Step Installation
- Pry Up the Switch Panel: Insert your trim tool at the front or rear edge of the switch panel assembly and gently pry upwards. It is held in by clips and will pop out.
- Disconnect Electrical Connectors: Once the panel is loose, lift it up to expose the wiring. There will be several electrical connectors plugged into the bottom of the switch. Press the release tab on each connector and pull it straight out.
- Remove Switch from Panel (If Necessary): On some models, the switch is screwed into the door panel trim piece from underneath. If so, remove these screws to separate the old switch from the trim.
- Install the New Switch: Secure the new switch to the trim panel with the screws, then plug in all the electrical connectors. Make sure each one clicks firmly into place.
- Test and Reinstall: Before snapping the panel back into the door, turn the ignition on and test all window and lock functions. Once confirmed, align the panel with the opening in the door and press down firmly until the clips snap back into place.
Known Issues, Recalls, and TSBs
For the 2000-2004 model years, there are no specific recalls or Technical Service Bulletins (TSBs) issued by Acura or the NHTSA for the master window switch or power door locks. Most issues are related to normal wear and tear of the switch's internal contacts over time. Several recalls were issued for this generation RL, primarily concerning airbags and a brake stop switch, but none pertain to the window/lock control unit.
Cost Comparison
| Part Type | Estimated Price Range |
|---|---|
| New OEM (Acura) | $570 - $825 |
| New Aftermarket (Dorman, etc.) | $110 - $150 |
| Used OEM (Recycled) | $40 - $90 |
| Shop Labor Cost | $50 - $100 |
Frequently Asked Questions (FAQ)
Can I replace just one broken button on the switch?
No, the individual buttons are not sold separately. The entire master switch assembly must be replaced as a single unit.
Why do my passenger windows work from their own doors but not from the driver's master switch?
This is a classic symptom of a failing master switch. The internal circuitry that sends signals to the other doors has likely failed, even though the local switches are still functional. Before replacing the switch, always check that the window lock-out button isn't engaged by mistake.
Do I need to disconnect the battery before replacing the switch?
While the replacement is a simple plug-and-play job, it is always best practice to disconnect the negative battery terminal before working on any electrical components in your vehicle. This prevents any risk of short circuits.
Will a switch from a 2005 RL fit my 2003 RL?
No. The 2005 Acura RL is a different generation with a completely redesigned interior and electrical system. You must use a switch from the 2000-2004 model years, specifically one with the part number prefix 35750-SZ3.
Helpful Videos
Technical Specifications
OEM Part Numbers: 35750-SZ3-A01 35750-SZ3-A02 35750-SZ3-A03 35750-SZ3-A04 35750-SZ3-A05
Fits 4-door models. Driver's side (Front Left) position. Direct plug-and-play electrical connectors.
