2023-2026 Cadillac LYRIQ Front Door Hinge: Fixing Sag, Noises, and Weak Door Checks

Symptoms of Failure

Problems with the front doors on a Cadillac LYRIQ can typically be traced to either the main hinges or the door check strap. It's important to distinguish between the two.

Symptoms of a Worn Door Hinge

• Sagging Door: This is the most definitive sign of a worn hinge. The door will appear to droop when open and you may need to lift it slightly to get it to latch properly. A sagging door often scrapes the sill plate.
• Popping or Grinding Noises: Loud pops, clicks, or grinding sounds coming from the hinge area when the door moves indicate metal-on-metal contact from worn-out pins and bushings.
• Excessive Door Movement: With the door open, grab the handle end and try to lift it up and down. More than a tiny amount of vertical play suggests the hinge pin or knuckle is worn out.
• Uneven Gaps: When the door is closed, look at the gap between the door and the fender or rear door. If the gap is wider at the top and tight at the bottom, the top hinge is likely worn.
• Wind Noise or Water Leaks: A misaligned door due to a bad hinge won't seal properly against the weatherstripping, leading to increased wind noise at speed or water entry during rain.

Symptoms of a Failing Door Check

• Door Won't Stay Open: The door swings shut on its own, even on a slight incline. The detents in the check strap are too weak to hold the door's weight.
• Clicking or Popping from the Check Strap: A distinct clicking sound that comes from the check strap area (between the hinges) as it moves in and out of the door.

Known Issues for the 2023-2026 Cadillac LYRIQ

Weak Front Door Detents

A common complaint among 2023-2026 LYRIQ owners is that the front doors do not stay open securely, especially when the vehicle is parked on even a slight grade. Owners report that the heavy doors can easily overwhelm the detents in the door check, causing the door to swing closed unexpectedly. This is not a sign of hinge failure, 🎬 See this simple fix for a weak door check but rather an issue with the strength of the door check mechanism itself. As of mid-2026, GM has not issued a recall or a specific TSB to address this, but it is a widely discussed topic in owner forums.

Recalls and Technical Service Bulletins (TSBs)

As of June 2026, there are no specific safety recalls or TSBs issued by General Motors or the NHTSA for the front door hinges on the 2023-2026 Cadillac LYRIQ. The vehicle has been subject to numerous other recalls and TSBs for software, seat belt anchors, and other components, but the hinges themselves have not been identified as a widespread defect.

Buying a Used Door Hinge, Front

A used OEM hinge is often a better choice than a new, unproven aftermarket part, as the material quality and dimensions are guaranteed to meet factory standards. Since most used hinges come from collision vehicles, careful inspection is critical.

Inspection Checklist for a Used Hinge:

• Check for Bends or Twists: Lay the hinge on a perfectly flat surface. It should sit flush with no rocking or gaps. Any amount of twisting indicates it was stressed in an accident and will make door alignment impossible.
• Inspect the Pivot Pin: The hinge should pivot smoothly but firmly, without binding or excessive looseness. Wiggle the two halves of the hinge; there should be minimal play at the pin.
• Examine the Mounting Holes: The bolt holes should be perfectly round. Elongated or cracked holes are a major red flag, indicating the hinge was subjected to extreme force during an impact.
• Look for Corrosion: Surface rust can often be cleaned and painted, but deep, flaking rust in the pivot area means the hinge's structural integrity is compromised.

Replacement Overview & Difficulty

• Difficulty: 4 out of 5
• Estimated Time: 2.0 - 3.0 hours per hinge
• DIY Feasible: Not recommended for beginners.

Replacing a front door hinge on a LYRIQ is a challenging job. The doors are very heavy, and supporting them properly is critical to avoid injury or damage. Accessing the hinge bolts often requires removing the front fender, which involves carefully detaching trim pieces and multiple fasteners.

The most difficult part of the job is aligning the door after the new hinge is installed. This requires patience and small, incremental adjustments to achieve even gaps and proper latching. A helper is essential for this procedure.

Cost Comparison

Prices can vary by supplier and location. The following is an estimate to help you understand the potential costs.

OEM Part Numbers

The LYRIQ uses different part numbers for upper, lower, left, and right hinges. The initial part numbers may be superseded over time. Always verify the correct part number for your specific vehicle's VIN with a dealer or parts specialist. Some known part numbers associated with LYRIQ front door hinges include:

• 85644415
• 85644416
• 13581568 (often listed as an aftermarket replacement)

Note: Some online databases may incorrectly list hood hinge part numbers for door hinge applications. Double-check fitment before ordering.
