2013-2019 Cadillac ATS Console Armrest: Latch Failure, Lid Replacement, and Color Matching
This guide covers the common failure points of the Cadillac ATS center console armrest, how to buy a quality used replacement, and what you need to know about color and fitment.
- The armrest lid fits all Cadillac ATS models from 2013 through 2019; the initial data specifying 2013-only is incorrect.
- The most common failure is a broken plastic latch, which prevents the lid from staying closed.
- Verify the interior color before buying a used part; Jet Black, Light Platinum, Caramel, and Morello Red were available.
- Replacement is an easy DIY job, requiring only a screwdriver and about 15-30 minutes.
Common Symptoms of a Failing ATS Armrest
The console armrest is a high-contact part, leading to several common wear-and-tear issues. Most problems are cosmetic or related to the latch and do not affect the vehicle's drivability.
- Broken Latch: The most frequent problem is a failed latch mechanism. The plastic latch or the corresponding striker can break, preventing the armrest from staying securely closed. It may pop open during acceleration or when going over bumps.
- Worn or Peeling Surface: The leather or synthetic leather surface can peel, crack, or delaminate, especially on the driver's side where it experiences the most contact. This is often caused by heat, sun exposure, and oils from skin.
- Loose or Wobbly Hinge: The hinge connecting the lid to the console base can become loose or crack, causing the entire armrest to feel unstable or misaligned when opened or closed.
- Sagging or Deformed Padding: Over time, the foam padding underneath the cover can compress or deform, creating a sagging or uneven appearance.
Buying a Used 2013-2019 Cadillac ATS Armrest
A used OEM armrest is often the best value, providing a perfect fit and color match compared to aftermarket alternatives, which are not widely available for this specific part. Here’s what to look for when buying a recycled part.
1. Verify Compatibility and Year Range
Warning: The center console armrest lid is consistent across all Cadillac ATS models from 2013 to 2019. Initial information suggesting it only fits 2013 models is incorrect. The part fits the entire first generation of the ATS.
The primary part you are replacing is the lid and hinge assembly. This does not include the entire center console, the shifter, or side trim panels. The core design remained the same for all trims and engine types (2.5L, 2.0L Turbo, 3.6L) and for both automatic and manual transmission consoles.
2. Inspect Key Failure Points
- Check the Latch: This is the most critical inspection point. Ask for clear photos of the latching tongue on the lid and the striker point inside the console (if included). If buying in person, test it to ensure it clicks shut and holds firmly. A separate latch striker is available under part number 23235298, but it's best to get an armrest with a fully intact latch.
- Examine the Surface: Look closely at all photos for signs of peeling, cracking, or deep scratches in the leather/vinyl. Pay special attention to the edges and the area where an elbow would typically rest.
- Test the Hinge: The hinge should be free of cracks and allow the lid to open and close smoothly without excessive side-to-side play.
3. Confirm the Interior Color
The 2013 Cadillac ATS was offered with several interior color schemes. While 'Jet Black' is the most common, other options existed. Always verify the color of the used part matches your vehicle's interior.
- Jet Black: The most common color.
- Caramel with Jet Black Accents 🎬 Watch: See the Caramel Tan interior in detail
- Light Platinum with Jet Black Accents
- Morello Red with Jet Black Accents
The part number may not always specify the color, so a visual match using high-quality photos is essential. If in doubt, ask the seller to confirm the color or provide the VIN of the vehicle it was removed from.
| Part | Common OEM Part Numbers | Fitment Years |
|---|---|---|
| Console Armrest Lid (Assembly) | 23130336, 22945414 | 2013-2019 |
| Console Lid Latch/Striker Only | 23235298 (replaces 22795482) | 2015-2019 (verify for 13-14) |
Cost Comparison for a Replacement Armrest
Prices can vary based on condition and color. A complete armrest lid assembly is the typical replacement part.
| Part Type | Estimated Cost | Notes |
|---|---|---|
| New OEM | $250 - $400+ | Ordered from a Cadillac dealership. Guarantees perfect color and condition. |
| New Aftermarket | $50 - $100 (Cover Only) | Aftermarket options are typically limited to replacement leather/vinyl covers that must be installed on the original armrest, which requires significant labor. Complete aftermarket lids are not common. |
| Used OEM | $70 - $150 | The most cost-effective option for a complete, ready-to-install part. Prices depend on condition and color. |
| Shop Labor | $50 - $100 | Replacement is simple and typically takes less than 30 minutes. Most shops will charge for a minimum of 0.5 hours of labor. |
Installation Guide (Difficulty: 1/5)
Replacing the console armrest is a very simple DIY task that requires basic tools and can be completed in under 30 minutes.
Pro Tip: Before starting, place a towel over the console opening to prevent screws or tools from falling inside.
- Open the Armrest: Fully open the console lid to access the hinge mechanism at the back.
- Remove Mounting Screws: Locate the screws that attach the hinge to the console base. There are typically 2 to 4 Phillips head or small Torx screws.
- Detach the Old Armrest: Once the screws are removed, the entire lid and hinge assembly can be lifted off the console base.
- Install the New Armrest: Position the new armrest, align the hinge with the screw holes on the console base, and reinstall the mounting screws. Do not overtighten.
- Test for Function: Open and close the new armrest several times to ensure it operates smoothly and latches securely.
Known Issues, TSBs, and Recalls
There are no specific recalls or Technical Service Bulletins (TSBs) from GM or the NHTSA related to the center console armrest of the 2013-2019 Cadillac ATS. Any failures are considered normal wear and tear. The most significant interior-related issue for this generation is the delamination of the CUE infotainment screen, which is a separate component.
Frequently Asked Questions (FAQ)
Will an armrest from a 2018 ATS fit my 2013 ATS?
Yes, the console armrest lid is interchangeable across all model years of the first-generation Cadillac ATS (2013-2019). The key is to match the interior color, not the year.
Does the replacement armrest include the USB ports or power outlet?
No. The USB ports, power outlets, and any associated wiring are located within the console storage bin itself, not in the armrest lid. You will not be replacing these components when swapping the armrest.
My latch is broken, but the rest of the armrest is fine. Can I just replace the latch?
Possibly. GM offers a replacement latch/striker (part number 23235298), but it is listed for 2015-2019 models. While it may fit earlier years, it's often easier and more reliable to replace the entire used armrest assembly, which includes a pre-installed latch.
Can I just replace the peeling leather cover instead of the whole armrest?
Yes, aftermarket leather or vinyl covers are available. However, this is a more involved repair that requires removing the old cover, likely scraping off old glue and staples, and then carefully stretching and adhering the new cover. For most people, replacing the complete lid assembly is a much faster and simpler job.
🎬 Watch: How to replace just the armrest coverHelpful Videos
Technical Specifications
OEM Part Numbers: 23130336 22945414 23235298
Fits 2013, 2014, 2015, 2016, 2017, 2018, 2019 Cadillac ATS. Available in multiple colors including Jet Black, Light Platinum, and Caramel.
