2011-2023 Dodge Charger Third Brake Light: Solving Leaks & Camera vs. Non-Camera Parts
The most common problems with the Charger's high-mount stop light are water leaks and total failure, but the biggest trap for buyers is choosing between the two different versions of the part.
- The single most critical factor is verifying if your Charger needs the light assembly WITH or WITHOUT the integrated backup camera; they are not interchangeable.
- The foam gasket is a common failure point that causes water to leak into the trunk. Always plan to replace the gasket when replacing the light.
- This is a sealed LED unit. Individual LEDs cannot be replaced, so the entire assembly must be swapped if the light fails.
- A non-functioning third brake light is a safety hazard that will cause a failed vehicle inspection and can lead to a traffic ticket.
Symptoms of Failure
A failing center brake light on a Dodge Charger typically presents one of two ways: electrical failure or a physical leak. Both can cause significant issues if not addressed.
1. Light Failure or "Brake Lamp Out" Warning
The most obvious symptom is the light simply not working. Because this is a sealed LED unit, you may notice individual LEDs flickering or going out, creating a broken or dim appearance before the entire bar fails. When the Body Control Module (BCM) detects a problem with the circuit, it will trigger a "Brake Lamp Out" or similar warning message on your dashboard. This is an immediate safety concern and will cause your vehicle to fail a state safety inspection.
2. Water Leaking Into the Trunk
A very common and frustrating issue is the failure of the foam gasket that seals the light assembly to the trunk lid. Over time, this gasket becomes compressed, brittle, and deteriorates, allowing water to seep past it. You may notice a damp or musty smell in the trunk, water stains on the trunk liner, or even standing water in the spare tire well after it rains or you wash your car.
Warning: A leaking third brake light gasket is a well-known issue on many Chrysler vehicles. If left unaddressed, the water intrusion can cause mold, rust, and damage to other components in the trunk.
Known Issues, TSBs, and Recalls
While there are no specific recalls for the center high mount stop light itself on the 2011-2023 Charger, the water leak from the gasket is a widely documented problem among owners. Many owners have successfully solved the leak by replacing the original foam gasket with a higher-quality aftermarket EPDM rubber gasket 🎬 Watch: How to fix a leaking 3rd brake light or by carefully applying a bead of clear, waterproof silicone around the top and sides of the light housing during installation.
A recall (NHTSA 16V-739) was issued for 2011-2014 Dodge Charger police vehicles for a failing alternator that could lead to the loss of various electrical systems, including body controllers that operate the lights, but this was not directly related to the brake light assembly itself.
CRITICAL: Camera vs. Non-Camera Versions
This is the most important detail when buying a replacement light. Two distinct versions of this part exist for the 2011-2023 Dodge Charger:
- Without Backup Camera: A simple light assembly.
- With Backup Camera: The housing is designed with an integrated opening and mounting points for the factory rearview camera.
Warning: These two versions are NOT interchangeable. You must order the correct part for your vehicle's specific options. Before purchasing, visually inspect your current light to see if it has the small, circular lens of the backup camera integrated into it. Ordering the wrong one will result in either a part that won't fit or a loss of your backup camera function.
Buying a Used Center High Mount Stop Light
A used OEM third brake light can be an excellent value, but careful inspection is key. Here’s what to check before you buy:
1. Verify the Camera Type
This is the first and most important step. Confirm whether you need the version with or without the integrated backup camera. Ask the seller for clear pictures if you are unsure.
2. Inspect the Gasket
Assume the gasket on any used part is bad. Look for signs that it is compressed, cracked, or crumbling. Plan on replacing it. High-quality aftermarket gaskets are available and are often superior to the original foam. Do not reuse an old, flat gasket; it will leak.
3. Check the Lens and Housing
Look for cracks, deep scratches, or hazing on the red lens. Check the black plastic housing for broken mounting tabs or signs of heat warping. Any cracks will allow moisture inside, causing the LEDs to fail prematurely.
4. Look for Internal Moisture
Check for any condensation or water marks on the *inside* of the lens. This is a red flag that the seal has already failed and the internal electronics may have been compromised.
Cost Comparison
| Part Type | Estimated Price Range |
|---|---|
| New OEM (Mopar) | $135 - $225 |
| New Aftermarket (Dorman, etc.) | $90 - $150 |
| Used OEM | $50 - $100 |
| Shop Labor to Install | $50 - $100 |
Replacement Procedure
Replacing the center brake light on a 2011-2023 Charger is a straightforward DIY job. The difficulty is low and it can typically be completed in under 30 minutes.
🎬 See this 2011-2014 Dodge Charger brake light replacement guidePro Tip: Access to the light is from inside the car, not from the trunk. You will need to carefully pull down the rear of the headliner to access the mounting nuts and electrical connector.
- Lower the Rear Headliner: In the back seat, carefully pull down on the rear edge of the headliner. It is held in by several clips. You only need to lower it enough to get your hands and a small tool underneath.
- Disconnect the Electrical Connector: Locate the electrical plug going into the light assembly. Press the release tab and unplug it. You may need a small pick tool to release the locking tab.
- Remove Mounting Nuts: There are two 10mm nuts holding the light assembly in place. Use a socket with an extension to remove them. Be careful not to drop them into the headliner.
- Remove the Old Light: From the outside, carefully lift the old light assembly off the trunk lid. You may need to clean the area of any old gasket residue.
- Install the New Light: Install a new gasket on the replacement light. Position the new light, feed the connector through the hole, and secure it with the 10mm nuts. Do not overtighten.
- Reconnect and Test: Plug the electrical connector back in. Have a helper press the brake pedal to confirm the light works before snapping the headliner back into place. 🎬 Watch: Step-by-step Dodge Charger 3rd brake light installation
Frequently Asked Questions
Can I just replace the bulb or LEDs inside the assembly?
No, this is a sealed LED unit. The individual LEDs are not designed to be serviced or replaced. If the light fails, the entire assembly must be replaced.
My light works, but my trunk is wet. What's the problem?
The foam gasket that seals the light to the trunk has failed. This is a very common problem. You must replace the gasket to stop the leak. Simply tightening the light will not work and may crack the housing.
What is the best way to fix the water leak?
The best permanent solution is to replace the old foam gasket with a new, high-quality EPDM rubber gasket. As a belt-and-suspenders approach, some owners also apply a thin layer of clear waterproof silicone sealant around the top and sides of the light's perimeter (leaving the bottom open to allow any potential moisture to escape) after installing the new gasket.
Will a light from a 2012 Charger fit my 2020 Charger?
Yes, the light assembly is physically the same for the entire 2011-2023 model year range. The only difference you must account for is whether your car has the optional backup camera integrated into the light housing.
Helpful Videos
Technical Specifications
OEM Part Numbers: 57010604AB 57010604AC 57010604AD 57010604AE 57010604AF 57010604AG 57010604AH 57010604AI 57010604AJ 57010605AJ 68213149AC 68213149AD 68213149AE 68402348AA 68402348AB
Sealed LED light assembly. Available in two versions: with or without integrated backup camera mount.
