2009-2010 Acura TSX Backup Camera: Fixing a Black Screen & Buying Used

Symptoms of a Failing 2009-2010 TSX Backup Camera

When the backup camera on a 2009-2010 Acura TSX begins to fail, it typically presents one or more distinct symptoms. These issues are often due to internal electronic failure or water intrusion into the camera housing over time.

Black or Blue Screen

The most common symptom is a completely black or blue screen when you put the car in reverse. The navigation display acknowledges the command to switch to the camera view, but no image is transmitted from the camera itself. This usually points directly to a failed camera unit, assuming the display works correctly for navigation and audio functions.

Intermittent or Flickering Image

The camera may work sometimes but not others, or the image might flicker while you are backing up. This can be frustrating to diagnose and may point to a loose connection or a failing electronic component within the camera that is sensitive to temperature or vibration. In some cases, turning the car off and on again may temporarily restore function.

Blurry, Foggy, or Distorted Image

If the image on the screen appears foggy, blurry, or has water spots, it's a clear sign that the camera's weather seals have failed. Moisture has likely entered the camera housing, condensing on the inside of the lens. This not only obstructs the view but will eventually lead to corrosion and complete failure of the internal electronics.

Diagnosing the Problem: Is It Really the Camera?

Before spending money on a replacement, it's important to confirm the camera itself is the problem. Other issues can mimic a camera failure.

• Check the Fuse: A blown fuse can cause the camera system to stop working. Forum users suggest checking the 10A fuse at location 15 under the hood, labeled "Back Up". If the reverse lights and mirror tilt-down feature also stop working, a bad fuse or reverse switch is a likely culprit.
• Check the Display: If your navigation and audio displays are also malfunctioning, the problem is likely with the head unit, not the camera. If the screen works for all other functions and only fails to show the reverse image, the camera is the primary suspect.
• Inspect Wiring: While less common, wiring can be damaged, especially in the flexible rubber conduit between the trunk and the trunk lid. Open the trunk and inspect this area for any visible signs of cracking or frayed wires.

Known Issues, TSBs, and Recalls

As of mid-2024, there are no specific recalls or Technical Service Bulletins (TSBs) from Acura or the NHTSA directly addressing the failure of the backup camera on the 2009-2010 TSX. However, numerous owner complaints on forums like Acurazine confirm that camera failure is a common problem. The main recalls for this vehicle generation concern airbag inflators and power steering hoses.

Buyer's Guide: Shopping for a Used 2009-2010 TSX Backup Camera

This is the most important section for anyone needing to replace their camera. Follow these guidelines to get the right part and avoid common pitfalls.

Why Choose a Used OEM Camera?

For this specific part, a quality used Original Equipment Manufacturer (OEM) camera is often a better choice than a new aftermarket one. Aftermarket cameras can have issues with image quality, viewing angle, and most importantly, they may not be plug-and-play. Many cheap aftermarket options require cutting and splicing wires or are designed to mount near the license plate light, not in the factory location. A used OEM camera ensures a perfect fit, correct connector, and proper integration with the factory navigation screen.

Physical Inspection Checklist

When buying a used camera, inspect it carefully:

• Lens Clarity: The lens should be clear and free of deep scratches or hazing.
• No Water Intrusion: Look for any signs of moisture or a water line inside the lens. This is a major red flag.
• Connector Pins: Check the electrical connector. The pins should be straight, clean, and free of corrosion.
• Intact Housing: Ensure the plastic housing and mounting points are not cracked or broken.

Cost Comparison: New vs. Used vs. Aftermarket

Prices can vary, but here is a general breakdown of what to expect:

Replacement Guide

Difficulty & Tools

• Difficulty Rating: 2 out of 5 (Easy)
• Estimated Time: 30-45 minutes
• Tools Needed: Plastic trim removal tool, 10mm socket or wrench.

Step-by-Step Installation

1. Open the trunk.
2. Using a trim removal tool, carefully pop out the plastic clips holding the trunk lid liner in place. Remove the liner to expose the back of the trunk lid.
3. Locate the backup camera. It is mounted in the center of the trunk lid's chrome trim piece.
4. Disconnect the electrical harness from the camera. There is a small tab you'll need to press to release the connector.
5. The camera is typically held in place by two 10mm nuts. Remove these nuts.
6. Carefully remove the old camera from the trunk lid.
7. Install the new camera, secure it with the two nuts, and reconnect the electrical harness.
8. Before reinstalling the trunk liner 🎬 Watch this Acura TSX backup camera installation guide, turn the car on and put it in reverse to test the new camera.
9. Once you've confirmed it works, reinstall the trunk liner and its clips.

Frequently Asked Questions (FAQ)

Part Numbers and Specifications

• OEM Part Number: 39530-TL0-G01
• Alternate Part Numbers: 39530TL0G01, AC1960115
• Connector Type: Factory OEM plug, direct fit
• Vehicle Fitment: 2009-2010 Acura TSX Sedan (with Navigation)
