2021-2022 Chevrolet Trax Back Glass: Decoding Privacy vs. Solar Tints
This guide details the critical differences in back glass options for the 2021-2022 Chevy Trax, ensuring you purchase the correct part with the right features.
- The most critical factor is matching the glass tint: RPO code AKO is for dark 'Privacy' glass and AKP is for lighter 'Solar-Absorbing' glass.
- When buying used, meticulously inspect the defroster grid lines and electrical connectors for any damage, as they cannot be easily repaired.
- Replacement is a job for professionals or highly experienced DIYers due to the use of urethane adhesive and the risk of improper sealing.
- There are no major recalls or widespread reports of spontaneously shattering back glass for the 2021-2022 Trax.
Key Differences: Privacy Glass (AKO) vs. Solar-Absorbing Glass (AKP)
The single most important factor when replacing the back glass on a 2021-2022 Chevrolet Trax is identifying the type of factory tint your vehicle has. Using the wrong glass can result in a mismatched appearance and potentially different heat rejection properties. These options are identified by Regular Production Option (RPO) codes, which can be found on a sticker in the driver's door jamb or glove box.
- RPO Code AKO: Deep-Tinted Privacy Glass. This is the darkest tint available from the factory. It is designed primarily to provide privacy for passengers and cargo. The tint is integral to the glass itself. Part number 42778327 is specified for models with this privacy glass.
- RPO Code AKP: Solar-Absorbing Glass. This glass has a lighter tint than privacy glass and is designed to reduce the amount of solar heat entering the cabin, which can help keep the interior cooler. It still offers some UV protection but its primary function is heat management rather than privacy.
Pro Tip: If you cannot find your RPO code sticker, a simple visual comparison can help. Park your vehicle next to another Trax if possible. Privacy glass (AKO) will be noticeably darker, similar to a typical aftermarket tint. Solar-absorbing glass (AKP) will have a more subtle, lighter tint.
Symptoms of a Failing Back Glass
Aside from obvious breakage, there are a few other symptoms that indicate your back glass may need attention or replacement.
- Complete Shattering: Tempered glass can shatter completely from a significant impact or a small chip that spreads due to thermal stress (like using the defroster in cold weather). While there are no widespread recalls for spontaneously shattering back glass on the 2021-2022 Trax, it can happen to any tempered glass.
- Rear Defroster Not Working: If some lines on the defroster grid don't clear frost or fog, it means those specific lines are broken. If the entire defroster doesn't work, the issue is more likely a fuse, relay, or a problem with the electrical connectors at the edge of the glass.
- Water Leaks: A leak around the back glass is usually due to a failed or improperly installed urethane seal, not the glass itself. This requires removal and re-sealing of the glass.
- Scratches or Distortion: Deep scratches can compromise the integrity of the glass and may damage the defroster grid lines.
Warning: A shattered back glass should be addressed immediately. It compromises vehicle security, exposes the interior to weather, and can allow exhaust fumes to enter the cabin while driving.
Buying a Used 2021-2022 Trax Back Glass
Purchasing a used OEM back glass is an excellent way to save money while ensuring a perfect fit and tint match. However, careful inspection is crucial.
What to Check Before You Buy:
- Verify Compatibility: First and foremost, confirm the glass is from a 2021-2022 Trax and matches your vehicle's tint option (AKO or AKP). All back glass for these years should be heated for the defroster and have a hole for the rear wiper.
- Inspect the Defroster Grid: Carefully examine the orange or brown horizontal lines of the defroster grid. Look for any scratches or breaks in the lines. A single broken line will cause that section of the defroster to fail.
- Check the Electrical Connectors: Ensure the main electrical tabs (usually on the sides of the glass) where the defroster connects are intact and not damaged. These can be easily broken during removal from the donor vehicle.
- Examine for Scratches and Chips: Run your hand over the entire surface of the glass, inside and out. Pay close attention to the edges, as a small chip near the edge can turn into a large crack with temperature changes or body flex.
- Look for the 'Bug': Check the small black printed label in one of the corners of the glass (often called the 'bug' or DOT mark). This contains manufacturing information and confirms it is OEM safety-certified glass.
Known Issues, TSBs, and Recalls
The 2021-2022 Chevrolet Trax has very few complaints and no specific recalls related to the back glass. The National Highway Traffic Safety Administration (NHTSA) has not issued any recalls for shattering rear glass for this model.
- TSB PI0754D/F: General Motors has issued a technical service bulletin regarding spots or 'quench marks' on tempered glass. This bulletin clarifies that these are a normal characteristic of the glass manufacturing process and not a defect.
- TSB 21-NA-152: This bulletin provides dealers with information on glass ultraviolet (UV) ray protection and tint percentages, which can be useful for identifying different glass types.
Cost of Replacement
The cost to replace the back glass on a 2021-2022 Trax can vary significantly based on the type of glass and labor rates.
| Part/Service | Estimated Cost |
|---|---|
| New OEM Back Glass (GM Part #42778327) | $450 - $650 |
| New Aftermarket Back Glass | $200 - $350 |
| Used OEM Back Glass | $150 - $250 |
| Shop Labor (Professional Installation) | $200 - $400 |
Frequently Asked Questions (FAQ)
What is the installation difficulty for a back glass?
On a scale of 1 to 5, this is a 4. It is not recommended for beginners. The process involves removing interior trim panels, carefully cutting the old urethane seal without damaging the paint, cleaning the frame, applying new primer and urethane adhesive, and setting the new glass correctly. The urethane requires a specific cure time before the vehicle can be safely driven.
Can I use a back glass from a Buick Encore?
While the Chevrolet Trax and Buick Encore from this era share the same platform, part numbers for the back glass are generally different. To ensure proper fitment, tint match, and feature compatibility, it is strongly recommended to use a glass specifically listed for the 2021-2022 Trax.
How long after installation can I drive the car?
This depends on the specific urethane adhesive used by the installer. Most professional glass shops will advise a Safe Drive-Away Time (SDAT) of at least 1 to 3 hours. It's best to follow the specific instructions from your installer to ensure the adhesive has cured enough to meet safety standards.
Is a small scratch on a used back glass okay?
A light surface scratch that you can't feel with your fingernail is usually just a cosmetic issue. However, a deep scratch can create a stress point in the tempered glass, making it more susceptible to shattering from temperature changes or impacts. If the scratch is over a defroster line, that line will no longer function.
Helpful Videos
Technical Specifications
OEM Part Numbers: 42609143 42770096 42778327 42778329
Material: Tempered Safety Glass. Features: Heated (Rear Defroster), Rear Wiper Mount, Factory Tint (AKO Privacy or AKP Solar-Absorbing).
