1992-1996 Mitsubishi Diamante Air Bag: SRS Light and Replacement Guide
Understanding the critical safety warnings, replacement requirements, and costs associated with the SRS system in the first-generation Mitsubishi Diamante.
- If the SRS warning light is on, the entire airbag system is disabled and will not protect you in a crash.
- Replacement of any SRS component is NOT a DIY job. Airbags are hazardous pyrotechnic devices that require professional installation.
- A faulty clock spring is a common issue that causes the SRS light and also makes the horn and steering wheel controls fail.
- After an airbag deployment, the SRS Control Module must be professionally reset or replaced for the system to work again.
Understanding the SRS Warning Light
The most common sign of a problem with the air bag system is an illuminated Supplemental Restraint System (SRS) warning light on your dashboard. This light indicates that the Airbag Control Module has detected a fault somewhere in the system. When the SRS light is on, the entire air bag system is disabled to prevent accidental deployment. This means that in the event of a crash, the air bags will not deploy, and the seatbelt pretensioners may not function, significantly increasing the risk of serious injury. Ignoring the light is not safe.
Warning: Do not drive a vehicle with the SRS warning light illuminated. The safety systems are inactive, leaving occupants without airbag protection in a collision. The vehicle may also fail state safety inspections.
Known Issues, TSBs, and Recalls
While there have been no major recalls for airbag inflators on the 1992-1996 Mitsubishi Diamante, such as the widespread Takata recalls which affected later models, some specific issues and service bulletins are relevant.
- Technical Service Bulletin (TSB-96-52B-006): Issued in December 1996, this bulletin corrected information in the official service manual's SRS troubleshooting chart for all 1992-96 Diamante models. This indicates that even dealerships needed updated information to correctly diagnose these early SRS systems.
- Wiring Harness Shorts: There have been reports of airbags failing to deploy in some Diamante models, potentially caused by a shorted airbag wiring harness. Diagnosing this requires a specialized scan tool to read fault codes from the Airbag Control Module. 🎬 Watch: How to diagnose and fix Mitsubishi airbag light issues.
- NHTSA Recall 96V143002: This recall was for incorrect bilingual English/Spanish air bag warning labels on the sun visor and dashboard, not for a defect in the airbag itself.
Symptoms of a Failing Air Bag System
Beyond the primary warning light, other symptoms can point to a fault in the SRS, often related to a component called the clock spring.
- SRS Air Bag Light is On: The most direct indicator of a fault. The system has detected an issue and has shut itself down.
- Horn and Steering Wheel Controls Don't Work: The clock spring is a spiral-wound cable inside the steering column that maintains the electrical connection for the driver's airbag, horn, and steering wheel-mounted controls. If the clock spring breaks, these other functions will often fail along with the airbag circuit, triggering the SRS light. 🎬 See this walkthrough on how to replace a clock spring.
- Visible Damage: Any visible damage, cracks, or tears on the airbag cover itself warrants an immediate inspection by a professional.
CRITICAL SAFETY WARNING: PROFESSIONAL INSTALLATION IS REQUIRED
Air bags are pyrotechnic devices containing explosive materials. They are classified as hazardous materials for shipping and handling. Attempting to remove, handle, or install an airbag without proper training and equipment can result in accidental deployment, causing serious injury or death. Furthermore, improper installation can cause the airbag to fail during a crash. There are also significant legal liabilities associated with the improper installation of safety restraint systems. Do not attempt to replace an airbag yourself.
Buying a Used Air Bag for Your Diamante
Given the age of the 1992-1996 Diamante, new OEM airbags are extremely difficult to find and likely discontinued. A used OEM airbag from a reputable auto recycler is often the only viable option. Here’s what to look for:
- Source Vehicle History: Only purchase an airbag from a vehicle that has not been in a flood or fire. Water and heat can damage the chemical inflator and electrical components.
- Inspect the Part: Physically inspect the airbag module. The cover should be free of cracks, tears, or discoloration. The electrical connectors should be clean, straight, and free of corrosion. Never purchase an airbag that shows any signs of being deployed or tampered with.
- Verify Part Numbers: Match the OEM part number exactly. Airbags are specific to vehicle make, model, and year. Even if a part looks similar, the deployment charge and connector could be different. The provided OEM part numbers have been associated with the driver's side airbag.
- Reputable Supplier: Purchase from a trusted, professional auto recycler who understands how to handle, store, and ship SRS components safely.
Related SRS Components
An airbag fault isn't always the bag itself. The issue often lies with a related component.
- Clock Spring: As mentioned, this is a common failure point. If your horn or steering wheel controls have also failed, the clock spring is a likely culprit.
- Airbag Control Module (SRS Module): This is the brain of the system. If the vehicle has been in an accident where the airbags deployed, this module stores crash data and locks itself. After a deployment, the module MUST be professionally reset or replaced for the new airbags to function. Simply clearing codes with a basic scanner will not work.
- Crash Sensors: Located in the front or sides of the vehicle, these sensors detect the rapid deceleration of an impact. Corrosion or damage to these sensors can trigger the SRS light.
Cost Breakdown for Air Bag System Repairs
Costs can vary widely depending on which part of the SRS has failed. The prices below are estimates and do not include diagnostic fees.
| Part / Service | Estimated Cost |
|---|---|
| New OEM Air Bag Module | $350+ (Extremely rare/likely unavailable) |
| Used OEM Driver's Air Bag | $100 - $200 |
| New Clock Spring (Part Only) | ~$242 |
| Airbag Control Module (Part Only) | ~$559 |
| Shop Labor: Clock Spring Replacement | $122 - $179 |
| Shop Labor: Airbag Control Module Replacement | $183 - $269 |
| SRS Module Reset Service | $50 - $100 (mail-in service) |
Frequently Asked Questions
Is it legal to install a used airbag myself?
While it may not be illegal to purchase a used airbag, installing it yourself carries immense risk and legal liability. Many states have strict laws against installing non-functional or counterfeit airbags. Due to the hazardous nature of the components, professional installation is required to ensure safety and proper function.
Will a used airbag be safe?
A used OEM airbag can be safe if it is sourced correctly. It must come from a reputable recycler, have a known vehicle history (no flood/fire), show no signs of damage or prior deployment, and be an exact part number match. Cheap, untraceable airbags from online marketplaces pose a significant safety risk.
Why is my SRS light still on after replacing a part?
The Airbag Control Module stores "hard codes" that cannot be cleared with a standard OBD2 scanner. After a repair, the SRS module must be reset using a specialized diagnostic tool. 🎬 Watch: How to reset the SRS light with or without a scanner. If the airbags have deployed, the module itself has likely stored permanent crash data and must be professionally reset or replaced.
My horn doesn't work and my airbag light is on. Are these related?
Yes, this is a classic symptom of a failed clock spring. The clock spring is a rotating electrical connector in the steering column that connects the steering wheel components (airbag, horn, cruise control) to the rest of the car. When it fails, all of those functions can be lost, and the SRS light will come on.
Helpful Videos
Technical Specifications
OEM Part Numbers: MB891556 MB948613 MB963104 MB963106 MR706172 MR714623
These part numbers have been identified as corresponding to the driver's side airbag module for the 1992-1993 Mitsubishi Diamante. Compatibility for 1994-1996 may differ. Always verify the part number from your specific vehicle before ordering a replacement.
We Have This Part in Stock
The information in this article is provided for general reference and educational purposes only. Vehicle specifications, procedures, and part compatibility can vary by production date, trim level, and region. Always consult your vehicle's factory service manual and verify part numbers before purchasing or performing repairs. Safety-critical components such as airbags, seat belts, and braking systems should be installed by a qualified professional.
