2019-2021 Ram 2500 & 2019 Ram 3500 ABS Module: Warning Lights, Recalls, and Replacement Guide

Symptoms of a Failing ABS Control Module

When the ABS control module in your 2019-2021 Ram 2500 or 2019 Ram 3500 begins to fail, your truck will typically provide clear warnings. The most common sign is the illumination of multiple warning lights on your dashboard.

• ABS Warning Light: This is the most direct indicator of a problem within the anti-lock braking system.
• Traction Control/ESC Light: Since the ABS module controls these systems, its failure will disable them and trigger their respective warning lights.
• "Service Antilock Brake System" Message: A message may appear in your instrument cluster, explicitly telling you the system needs attention.
• Unusual Brake Pedal Behavior: In some cases, a faulty module can cause the brake pedal to feel unresponsive or, conversely, cause the ABS to activate unexpectedly during normal braking.

You may also experience a complete loss of communication with the module, which can be identified with an advanced OBD-II scanner. This often results in specific diagnostic trouble codes (DTCs).

Common Diagnostic Trouble Codes (DTCs)

While a variety of codes can point to an ABS issue, some are more directly linked to module failure:

• C2200: This code often indicates an internal failure within the ABS module itself.
🎬 Watch: Diagnosing a RAM ABS module with code C2200
• U0121: This code signifies a loss of communication with the ABS module, meaning other computers in the truck can no longer receive data from it.

Known Issues, Recalls, and Technical Service Bulletins (TSBs)

Owners of these Ram trucks should be aware of a significant recall and several service bulletins related to the ABS control module.

NHTSA Recall 22V140 (FCA US LLC Recall Z20)

Stellantis (FCA) issued a recall for certain 2019-2022 Ram 2500 and 2019-2022 Ram 3500 Chassis Cab models (with a GVWR under 10,000 lbs). The issue involves software in the ABS control module that could prevent the Electronic Stability Control (ESC) warning light from illuminating correctly if a problem occurs. This failure to warn the driver increases the risk of a crash. The remedy is a free software update for the ABS control module performed by a dealer.

Technical Service Bulletins (TSBs)

Manufacturers issue TSBs to help technicians diagnose and repair common problems. For these trucks, TSB #08-061-20 was released to address situations where the Malfunction Indicator Lamp (MIL) might illuminate due to software issues. The fix involves reprogramming the ABS module with the latest software.

Programming and Calibration Requirements

The ABS module is tied to your truck's Vehicle Identification Number (VIN) and its specific configuration (tire size, axle ratio, etc.). Failure to program a replacement module will result in a VIN mismatch error (like DTC C2202) and the system will not function correctly.

The programming process involves several steps:

1. Module Initialization: The new module's VIN must be configured to match your truck's VIN.
2. ECU Initialization: The module must be introduced to the vehicle's electronic control unit network.
3. Configuration: Parameters like tire size must be set correctly.
4. Calibration: Procedures like an acceleration sensor calibration may be required.

While a Ram dealership is the most straightforward option for programming, some independent shops with advanced diagnostic tools may have the capability. Advanced DIYers have also reported success using tools like AlfaOBD with a compatible OBD-II interface to perform the initialization and calibration procedures at home.

Replacement Information

The ABS control module is the electronic component bolted to the hydraulic control unit (HCU). In many cases, you can replace just the electronic module without opening the hydraulic brake lines, which saves significant time and avoids the need to bleed the entire brake system. The module is typically held on by four to six Torx screws.

Location: The ABS module and HCU assembly is located in the engine bay, typically on the driver's side frame rail, below the master cylinder.

Buying a Used ABS Control Module

A used OEM ABS control module can be a cost-effective and reliable alternative to an expensive new part. Here’s what to look for:

• Match Part Numbers Exactly: There are many different part numbers for these modules. It is critical to match the OEM part number from your original module to the used one you are purchasing. Part numbers like 68453770AC and 68477878AF are common, but always verify your specific number.
• Inspect for Physical Damage: Check the connectors for any signs of corrosion, bent pins, or damage to the plastic housing. Avoid any units that show signs of water intrusion or physical impact.
• Source from a Reputable Supplier: Purchase from a seller that offers a warranty and has a good reputation. This provides protection in case the part is defective.
• Factor in Programming Costs: Remember that even a perfectly functional used module will require programming. Contact your local dealer or a trusted independent shop to get a quote for this service before you buy the part.
