2013-2014 Nissan NV200 ABS Module: Cargo Van Fitment, Programming, and Replacement
This guide covers the critical details for diagnosing and replacing the ABS control module in the 2013-2014 Nissan NV200, including the crucial Cargo-only compatibility warning.
- This module (47660-3LM0A, 47660-3LM6A) fits 2013-2014 Nissan NV200 CARGO VANS ONLY and is not interchangeable with Taxi models.
- A used replacement module will likely require programming/calibration by a dealer or a well-equipped independent shop to sync with your vehicle.
- Failure disables ABS and traction control, meaning your wheels can lock up during hard braking, increasing the risk of a skid.
- Before replacing the module, ensure a technician has ruled out simpler issues like fuses or faulty wheel speed sensors, per Nissan TSB NTB10-145B.
Symptoms of a Failing ABS Module
When the ABS module in a 2013-2014 NV200 begins to fail, it will typically provide several clear warnings. Ignoring these can compromise your vehicle's safety systems.
- ABS Warning Light: The most common symptom is an illuminated ABS warning light on your dashboard. This indicates the system has detected a fault and has likely disabled the anti-lock function.
- Traction/Stability Control Light: The 'VDC' or 'SLIP' light may also turn on, as the traction and stability control systems rely on the same 🎬 Watch: How to diagnose Nissan ABS, VDC, and SLIP lights sensors and hardware as the ABS.
- Wheels Locking Up: With the ABS system disabled, your wheels can lock up during hard braking, especially on wet or loose surfaces. This can cause the vehicle to skid and result in a loss of steering control.
- Unusual Brake Pedal Behavior: The brake pedal may feel harder to press than usual, or it may feel unresponsive. In some cases, the ABS may activate incorrectly at low speeds, causing a pulsing sensation in the pedal during normal braking.
- Pump Motor Constantly Running: You might hear the ABS pump motor running continuously, even when the brakes are not being applied. This points to an internal electrical fault in the module.
Common Diagnostic Trouble Codes (DTCs)
A professional scan tool is required to read ABS codes. Common codes related to Nissan ABS module issues include:
- C1111: ABS motor electrical failure.
- C1114: ABS valve relay error.
- U1000 / U0121: Lost communication with the ABS module. This is a strong indicator that the electronic portion of the module has failed.
Pro Tip: A clicking or clunking noise from the engine bay the first time you reach about 16 MPH is normal. This is the ABS system performing a self-check and does not indicate a problem, according to Nissan TSB NTB10-077.
Known Issues, Recalls, and Bulletins
While there are no specific safety recalls for the ABS control module itself on the 2013-2014 NV200, there are critical compatibility issues and service bulletins to be aware of.
Warning: Cargo Van ONLY Compatibility
The ABS control modules listed for the 2013-2014 NV200 (OEM part numbers 47660-3LM0A and 47660-3LM6A) fit Cargo Van models ONLY. They are NOT compatible with NV200 Taxi or passenger van models. Taxi models have different part numbers and are calibrated for different passenger loads and vehicle dynamics. Always confirm your vehicle's trim package before purchasing.
Technical Service Bulletins (TSBs)
Nissan has issued TSB NTB10-145B, which provides diagnostic procedures for the U1000 CAN communication code. It advises technicians to perform a full diagnosis before condemning and replacing the ABS actuator control unit, as wiring or other issues could be the root cause.
Buying a Used 2013-2014 NV200 ABS Module
Due to the high cost of a new module from the dealer, a quality used OEM part is often the most cost-effective solution. Here’s what to look for:
- Verify the Part Number: The most critical step is to match the OEM part number from your original module to the replacement part. The known part numbers are 47660-3LM0A and 47660-3LM6A. Do not install a module with a different part number, even if it looks identical.
- Confirm Vehicle Type: Double-check that the donor vehicle was a 2013 or 2014 Nissan NV200 Cargo van. Modules from Taxi models will not work correctly.
- Inspect the Connector: Ask for clear photos of the electrical connector pins on the used module. Look for any signs of corrosion, bent pins, or damage to the plastic housing. Corrosion is a known cause of ABS module problems.
- Mileage Isn't a Major Factor: Unlike mechanical parts, the mileage of the donor vehicle is less important than the module's functional condition. An electronic module from a 100,000-mile vehicle can work just as well as one from a 30,000-mile vehicle, provided it was not damaged.
Programming and Calibration Requirements
This is the most important consideration after installation. While some simpler Nissan systems can be plug-and-play, it is safest to assume that a used ABS module from a different vehicle will require calibration to work correctly with your specific van.
- What needs to be done? After installing a replacement module, a procedure is often needed to calibrate the Steering Angle Sensor and G-Sensor to the new module. Without this step, the ABS and VDC lights may remain on, and the system will not function.
- Who can perform the calibration? A Nissan dealership can always perform this service using their proprietary CONSULT scan tool. However, many independent repair shops now have advanced, professional-grade scan tools (like certain Autel or Foxwell models) that can perform these Nissan-specific calibrations. Always ask the shop if they have the capability to program/calibrate a Nissan ABS module before beginning the repair.
- What about repaired modules? If you send your original module to a repair service (like XeMODeX), the repaired unit is often plug-and-play because it retains its original programming and calibration for your vehicle's VIN. This can sometimes be a simpler, though potentially more expensive, option than buying used.
Cost of Replacement
The cost to fix a faulty ABS module can vary significantly depending on the path you choose.
| Part or Service | Estimated Cost |
|---|---|
| New OEM Module | $1,000 - $1,500+ (if available) |
| Used OEM Module | $100 - $250 |
| Repair Service (Your Module) | $350 - $450 |
| Shop Labor (Installation) | $150 - $250 |
| Shop Labor (Programming/Calibration) | $100 - $180 |
Frequently Asked Questions (FAQ)
Does a used ABS module for an NV200 need to be programmed?
Most likely, yes. When you install a used module from another vehicle, it will need to be calibrated to your van's systems, such as the Steering Angle Sensor. This requires a dealer-level or advanced professional scan tool. You should plan for this step and cost when replacing the module.
Will this ABS module fit my 2014 NV200 Taxi?
No. The part numbers 47660-3LM0A and 47660-3LM6A are specifically for the Cargo Van model. The Taxi version uses a different ABS module with unique programming. Installing the wrong module will result in system errors and unsafe operation.
Can I drive my NV200 with a bad ABS module?
Yes, but with significant risks. When the ABS module fails, your vehicle will revert to standard, non-ABS braking. This means your wheels can lock up during a panic stop, increasing the risk of skidding and losing control. Your traction and stability control will also be disabled. Drive with extreme caution and get the module replaced as soon as possible.
What tools are needed to replace the ABS module?
The replacement requires standard mechanic's tools (sockets, wrenches) to remove the unit, as well as flare nut wrenches for the brake lines to prevent stripping them. The most critical part of the job is bleeding the brakes afterward. This often requires a pressure bleeder and a scan tool that can cycle the ABS pump to purge all air from the 🎬 Watch: How to bleed ABS and brakes on Nissan vehicles hydraulic unit. For this reason, the job is often best left to a professional shop.
Helpful Videos
Technical Specifications
OEM Part Numbers: 47660-3LM0A 47660-3LM6A 476603LM6A
Fits 2013-2014 Nissan NV200 Cargo Van models only. Integrated electronic control unit, hydraulic pump, and valve body.
