Cadillac ATS & CTS ABS Module Failure (2013-2017): A Guide to UGN Codes and Programming

Symptoms of a Failing ABS Module

A problem with the ABS module in a Cadillac ATS or CTS will almost always trigger dashboard warnings. Because the module is central to several systems, one electronic fault can disable multiple safety features at once.

• ABS, Traction Control, and StabiliTrak Lights: This is the most common symptom. One or all of these warning lights will illuminate on the instrument cluster and typically stay on.
• Unresponsive or Hard Brake Pedal: In some cases, the brake pedal may feel unusually hard to press or seem less responsive.
• Wheels Locking Up: The main job of ABS is to prevent wheels from skidding. If the module has failed, this function is lost, and the wheels may lock up during a hard stop, especially on wet or slick roads.
• Speedometer Malfunctions: The ABS module processes and shares wheel speed data with other computers in the car. A faulty module can sometimes cause an erratic or non-functional speedometer.
• Diagnostic Trouble Codes (DTCs): A professional scan tool is required to read ABS codes (they will not show up on a basic OBD-II engine code reader). Common codes point to internal module failure (such as C1210) or a loss of communication with the module (U0121).

Known Issues, Recalls, and Bulletins

While there are no widespread recalls specifically for the ABS control module on the 2013-2017 Cadillac ATS and 2014-2016 Cadillac CTS, several related service bulletins and recalls exist that are important for owners to be aware of.

• TSB for ABS/StabiliTrak Lights: General Motors has issued multiple Technical Service Bulletins (TSBs), such as #PIC5428G, that guide technicians in diagnosing ABS, Traction Control, and StabiliTrak lights. Often, the cause is identified as debris on a wheel speed sensor or a faulty sensor, 🎬 Watch: How to diagnose and fix ABS and StabiliTrak lights not the module itself.
• Brake Pedal Bracket Recall (2015 models): Some 2015 ATS and CTS models were recalled because a brake pedal bracket could fracture, potentially leading to a complete loss of braking. This is unrelated to the electronics but is a critical safety issue for this model year.

The Critical Compatibility Check: RPO Code UGN

The single most important factor when purchasing a replacement ABS module for these vehicles is matching it to the car's factory options. GM uses different modules for vehicles with and without its advanced safety systems. Failure to match the module will result in it not working.

What is RPO Code UGN?

UGN is the Regular Production Option (RPO) code for the Pre-Crash System, also marketed as Forward Collision Alert, Collision Avoidance, or Enhanced Automatic Emergency Braking. Vehicles equipped with this feature (which often includes Adaptive Cruise Control) use a different ABS module than base model cars. There are also specific modules for high-performance V-Series models.

How to Find Your RPO Codes

To ensure you buy the correct part, you must check the RPO codes for your specific vehicle. Look for a silver sticker labeled "Service Parts Identification."

• Location: In the Cadillac ATS and CTS, this sticker is most commonly found in the trunk, under the floor cover in the spare tire well. 🎬 Watch: Locate your Cadillac's options and paint code tag It may also be in the glove box.
• What to Look For: Scan the list of three-digit codes for "UGN". If you see UGN on your sticker, you must purchase an ABS module specifically listed as compatible with option code UGN. If you do not have UGN, you need the standard base module.

Programming & Calibration: A Required Step

A replacement ABS control module is NOT a plug-and-play part. Whether the part is new, used, or remanufactured, it absolutely must be programmed to your vehicle’s Vehicle Identification Number (VIN).

Programming is required to configure the module for your car's specific options (like engine size, tire size, and safety features) and allow it to communicate with the other computers on the vehicle's data network. Without programming, the ABS and StabiliTrak lights will remain on, and the systems will not function.

Who Can Program the Module?

• GM Dealership: A dealer is a guaranteed option, as they have the required tools and subscriptions.
• Independent Repair Shop: Many independent shops can perform this service, provided they have a professional-grade scan tool and an active subscription to GM's Techline Connect / SPS2 (Service Programming System) software.
• DIY: While technically possible for an advanced DIYer to purchase a single-VIN subscription from ACDelco for about $45 and use a compatible J2534 pass-thru device, it is a complex process. For most owners, taking the vehicle to a professional is the most reliable option.

After installation and programming, the technician must also perform an automated brake bleed procedure using the scan tool to purge all air from the hydraulic unit.

Buying a Used ABS Control Module

A used OEM module is an excellent, cost-effective alternative to an expensive new part, especially since even new parts require programming. However, there are a few things to keep in mind.

• Match the Part Number AND Options: Double-check that the part number on the used module matches your original. Most importantly, confirm whether it is for a vehicle with or without the UGN option code, as needed for your car.
• Inspect the Connectors: Check the electrical connector pins for any signs of corrosion, which could indicate water damage. Ensure the connector housing isn't cracked or broken.
• Check the Hydraulic Block: The module is bolted to an aluminum hydraulic block with brake lines attached. Inspect the block for any cracks, severe corrosion, or damage from the donor vehicle's accident.
• Buy from Reputable Sellers: Purchase from a seller who offers a warranty and guarantees the part is functional. Be aware that even a perfectly good used module will be condemned as "defective" if the installer does not have the correct tools to program it.

Cost Comparison

Prices can vary significantly based on your vehicle's options and the part source. Programming costs are in addition to the part and installation labor.
